Eaton Enhanced visible blade single-throw safety switch, Corrosion resistant, 800 A, NEMA 4X, 304 stainless steel, Class L, Two-pole, Three-wire, 240 V, Max Hp: 100, 250 hp (3PH @ Std fuse/time delay), (4)#1/0-(4)750 kcmil Cu/Al
Manufacturer Resources
Product Specs
- Amperage Rating:
- 800A
- Catalog Notes:
- Heavy Duty Safety Switch (HDSS)
- Certifications:
- UL Listed
- Enclosure:
- NEMA 4X
- Enclosure Material:
- 304 stainless steel
- Fuse Class Provision:
- Class L
- Fuse Configuration:
- Fusible with neutral
- Hp Rating Max:
- 100, 250 hp (3PH @ Std fuse/time delay)
- Number Of Poles:
- Two-pole
- Number Of Wires:
- 3
- Product Height:
- 71.75 in
- Product Length Depth:
- 12.75 in
- Product Weight:
- 210 lb
- Product Width:
- 24.9 in
- Special Features:
- Corrosion resistant
- Type:
- Heavy duty fusible safety switch
- Voltage Rating:
- 240V
- Product Group:
- Electrical
