Eaton Enhanced visible blade single-throw safety switch, Corrosion resistant, visible blade, 6 blade, 100 A, NEMA 4X, Cartridge, Six-pole, Six-wire, 600 V, Max Hp: 15-30, 25-60, 30-75 hp (3PH @240, 480, 600 V), 600 V, #14-#1/0 Cu/Al
Manufacturer Resources
Product Specs
- Amperage Rating:
- 100A
- Application:
- Heavy commercial and industrial
- Catalog Notes:
- Heavy Duty Safety Switch (HDSS), w/ Enhanced Visible Blade
- Certifications:
- UL Listed
- Enclosure:
- NEMA 4X
- Enclosure Material:
- 304 stainless steel
- Fuse Class Provision:
- Cartridge
- Fuse Configuration:
- Fusible without neutral
- Hp Rating Max:
- 15-30, 25-60, 30-75 hp (3PH @240, 480, 600 V)
- Nema Rating:
- NEMA 4X
- Number Of Poles:
- Six-pole
- Number Of Wires:
- 6
- Product Height:
- 9 in
- Product Length Depth:
- 29 in
- Product Weight:
- 39 lb
- Product Width:
- 17 in
- Series:
- K
- Special Features:
- Corrosion resistant, enhanced visible blade, 6 blade, upper viewing window
- Type:
- Heavy duty fusible safety switch
- Voltage Max:
- 600 V
- Voltage Rating:
- 600 V
