Eaton CH Series GFCI Circuit B...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$199.87
$159.00
Eaton GFCI circuit breaker,Plug-in circuit breaker,45 A,10 kAIC,Two-pole,120/240 V,CH,Common,GFI,5 mA

Eaton CH Series GFCI Circuit Breaker 45A Two-Pole 120/240V 10kAIC Plug-In Ground Fault Protection System

(No reviews yet) Write a Review

Model: CHN220GF

In Stock (leaves warehouse same day if ordered before 3pm ET)

$199.87
$159.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CH Series GFCI Circuit Breaker 45A Two-Pole 120/240V 10kAIC Plug-In Ground Fault Protection System

Professional Ground Fault Circuit Interrupter Protection for Electrical Safety

The Eaton CH Series GFCI Circuit Breaker delivers reliable ground fault protection with 45A capacity and two-pole configuration for 120/240V applications. This plug-in circuit breaker features 10kAIC interrupt rating and 5mA ground fault protection sensitivity, providing professional-grade electrical safety for residential and commercial installations. UL 489 certified construction ensures dependable performance in critical electrical protection applications.

Professional Features & Benefits

  • 45A Two-Pole Configuration: Handles substantial electrical loads while providing comprehensive ground fault protection across both poles for enhanced safety coverage.
  • 10kAIC Interrupt Rating: Delivers robust fault current interruption capability, ensuring reliable protection even under high fault current conditions.
  • 5mA Ground Fault Sensitivity: Provides precise ground fault detection at professional sensitivity levels for optimal safety without nuisance tripping.
  • CH Series Compatibility: Integrates seamlessly with Eaton CH electrical panels for consistent system performance and reliable connections.
  • Plug-In Design: Enables straightforward installation and replacement with secure panel connections and professional mounting.
  • UL 489 Certification: Meets rigorous safety and performance standards for molded case circuit breakers, ensuring code compliance and reliable operation.
  • GFI Indicator: Provides clear visual indication of ground fault protection status for easy system monitoring and maintenance.

Technical Specifications

  • Certifications: UL 489
  • Indicators: GFI
  • Interrupt Rating: 10 kAIC
  • Main Circuit Breaker: CH
  • Number Of Poles: Two-pole
  • Product Details: Plug-in circuit breaker
  • Product Weight: .8 lb
  • Protection: 5 mA
  • Trip Type: Common
  • Voltage Rating: 120/240 V

Professional Applications

  • Residential Electrical Panels requiring ground fault protection for high-amperage circuits
  • Commercial Facilities with equipment requiring GFCI protection at 45A capacity
  • Industrial Applications where ground fault safety is critical for worker protection
  • Professional Workshops and Service Areas with heavy electrical equipment
  • Outdoor Electrical Installations requiring weather-resistant ground fault protection
  • Multi-Unit Properties with centralized electrical distribution and safety requirements

Why Choose Eaton Quality?

Eaton CH Series circuit breakers provide proven reliability with UL 489 certification and professional-grade construction. The lightweight .8 lb design combines with robust 10kAIC interrupt rating to deliver dependable ground fault protection. Common trip type ensures coordinated protection across both poles, while the plug-in design facilitates professional installation and maintenance in CH panel systems.

Manufacturer Resources

Product Specs

Certifications:
UL 489
Indicators:
GFI
Interrupt Rating:
10 kAIC
Main Circuit Breaker:
CH
Number Of Poles:
Two-pole
Product Details:
Plug-in circuit breaker
Product Weight:
.8 lb
Protection:
5 mA
Trip Type:
Common
Voltage Rating:
120/240 V
Department:
Electrical
Product Group:
Circuit Breakers
Product Type:
Circuit Breaker
Product Subgroup:
Electrical

Eaton CHN220GF – Frequently Asked Questions

1) Will an Eaton CHN GFCI breaker fit my Eaton BR panel?
No. The CHN-series GFCI breakers are CH-type plug-in breakers and belong in Eaton CH loadcenters and panelboards. Eaton's BR type is a different footprint and the two are not interchangeable, so a CH breaker will not seat correctly in a BR panel. Check the panel label or the breaker you are pulling out: CH panels take CH, BR panels take BR.
2) What amp ratings does the Eaton CHN two-pole GFCI breaker come in?
Nine ratings, all two-pole: 15A (CHN215GF), 20A (CHN220GF), 25A (CHN225GF), 30A (CHN230GF), 35A (CHN235GF), 40A (CHN240GF), 45A (CHN245GF), 50A (CHN250GF) and 60A (CHN260GF). Pick the rating that matches the wire size and the load you are protecting, not the largest one that fits.
3) Is this a people-protection GFCI or an equipment ground fault breaker?
It trips at 5 mA, which is Class A personnel protection, the same sensitivity as a GFCI receptacle. Equipment ground fault protection devices trip around 30 mA and do not satisfy code where personnel GFCI is required. So a CHN GFCI breaker is the right choice for spa, pool equipment, outdoor and similar circuits calling for GFCI protection of people.
4) Does a two-pole CHN GFCI breaker need a neutral run back to the panel?
The GFCI sensing circuit needs the load neutral brought to the breaker's neutral terminal, plus the pigtail landed on the panel neutral bar. That is how it compares current on both legs and neutral. For a straight 240V load with no neutral, such as many spa heaters or well pumps, you still land the pigtail on the neutral bar and leave the load neutral terminal empty. If you are feeding a 120/240V load, the neutral goes to the breaker, not the bar.
5) If one leg faults, do both poles open on this Eaton GFCI breaker?
Yes, the trip type is common, so an overload, short or ground fault on either pole opens both poles together. That matters on a 240V load like a water heater or spa, where leaving one leg energized would be a shock hazard during service.
6) How do I tell whether a CHN GFCI breaker tripped on a ground fault or an overload?
There's a GFI indicator on the breaker. When the trip was caused by a ground fault, the indicator shows it, so a maintenance tech can tell a wiring or equipment ground fault apart from a plain overload before resetting. That saves a lot of guessing on repeat trips at a spa panel or an outdoor circuit.
7) Are these Eaton CHN GFCI breakers UL listed for use as branch circuit protection?
They are UL 489 listed, which is the standard for molded case circuit breakers used as branch circuit and feeder overcurrent protection. That is the listing an inspector looks for on a breaker installed in a loadcenter, as opposed to UL 1077 supplementary protectors, which cannot be used for branch circuit protection.
8) Can I use one two-pole CHN GFCI breaker instead of two single-pole GFCIs for a spa circuit?
For a single 240V or 120/240V spa or equipment circuit, the two-pole CHN GFCI is the correct device: one breaker, both legs protected, common trip, 5 mA sensitivity. Two single-pole GFCI breakers are for two separate 120V circuits, not for one multiwire or 240V load. Match the amperage to the equipment nameplate; ratings run 15A through 60A.
9) How many spaces does a two-pole CHN GFCI breaker take in a CH panel?
Two full-size spaces, since it is a two-pole plug-in breaker that straddles both bus legs. Count that against your remaining panel capacity before you order, because CH GFCI breakers are wider bodied than a standard single-pole and will not fit where only one space is open.
