Eaton Thermal Magnetic Circuit Breaker Two-Pole 240V 10kAIC CH Series Common Trip

Eaton CH Series Two-Pole Thermal Magnetic Circuit Breaker 240V 10kAIC Common Trip

(No reviews yet) Write a Review

Model: CH280

In Stock (leaves warehouse same day if ordered before 3pm ET)

$140.30
$136.20
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CH Series Two-Pole Thermal Magnetic Circuit Breaker 240V 10kAIC Common Trip

Professional Circuit Protection for Residential & Commercial Applications

The Eaton CH Series Two-Pole Thermal Magnetic Circuit Breaker delivers reliable 240V circuit protection with 10kAIC interrupt rating and common trip functionality. This UL 489 certified breaker features thermal magnetic operation designed for Type CH Loadcenters, providing professional-grade electrical protection in a compact 3/4-inch standard design.

Professional Features & Benefits

  • 10kAIC Interrupt Rating: Provides robust fault current interruption capability for enhanced electrical system protection and safety.
  • Two-Pole Common Trip Design: Ensures simultaneous disconnection of both poles for complete circuit isolation and improved safety compliance.
  • 240V Voltage Rating: Supports standard residential and light commercial voltage requirements for versatile installation applications.
  • UL 489 Certification: Meets rigorous safety and performance standards for reliable operation in critical electrical systems.
  • CH Series Compatibility: Engineered specifically for Type CH Loadcenters ensuring proper fit and optimal electrical performance.
  • Thermal Magnetic Operation: Combines thermal overload and magnetic short-circuit protection for comprehensive circuit safeguarding.
  • 3/4-Inch Standard Profile: Compact design maximizes panel space utilization while maintaining full protection capabilities.

Technical Specifications

  • Certifications: UL 489
  • Circuit Breaker Type: CH
  • Interrupt Rating: 10 kAIC
  • Main Circuit Breaker: CH
  • Number Of Poles: Two-pole
  • Product Details: Type CH 3/4-Inch standard circuit breaker
  • Trip Type: Common breaker trip
  • Used With: Type CH Loadcenters
  • Voltage Rating: 120/240 V

Professional Applications

  • Residential Electrical Panels
  • Commercial Building Distribution
  • Light Industrial Facilities
  • Multi-Unit Properties
  • Professional Offices
  • Retail Establishments
  • Service Upgrade Projects

Why Choose Eaton Quality?

Eaton circuit breakers deliver proven reliability with UL 489 certification and robust 10kAIC interrupt rating. The CH Series design ensures long-term performance and compatibility with Type CH Loadcenters, providing professional-grade electrical protection you can trust for critical applications.

Manufacturer Resources

Spec Sheet

Product Specs

Certifications:
UL 489
Circuit Breaker Type:
CH
Interrupt Rating:
10 kAIC
Main Circuit Breaker:
CH
Number Of Poles:
Two-pole
Product Details:
Type CH 3/4-Inch standard circuit breaker
Trip Type:
Common breaker trip
Used With:
Type CH Loadcenters
Voltage Rating:
120/240 V
Department:
Electrical
Product Group:
Circuit Protection
Product Type:
Circuit Breaker
Product Subgroup:
Circuit Breakers

Eaton CH280 – Frequently Asked Questions

1) Will an Eaton CH2100 breaker fit in a Square D or Siemens panel?
No. The Eaton CH two-pole breakers are built for Type CH loadcenters only. The mounting rail and bus stab are specific to Eaton's CH bus, so they won't seat correctly in a Square D QO/Homeline or a Siemens panel. If your panel is an Eaton Type BR, that is a different breaker line too, and CH will not interchange with it. Check the label inside the panel door for "Type CH" before ordering.
2) Does a common trip two-pole breaker shut off both legs if only one leg faults?
Yes. Common trip means an overload or short on either pole opens both poles at once, so a 240 V load is fully de-energized rather than left with one hot leg live. That is what code requires for a 240 V two-wire circuit, and it's also what makes the breaker safe to use as a disconnect for equipment like a range, water heater, or compressor.
3) Does this Eaton breaker provide both overload and short-circuit protection, or do I need something else?
Both. It is a thermal magnetic breaker: the thermal element handles sustained overloads like an over-drawn appliance circuit, and the magnetic element trips fast on a bolted short. What it does not do is ground-fault or arc-fault detection, so where a GFCI or AFCI breaker is required by code you need the dedicated GFCI or AFCI version instead of this standard unit.
4) How much panel space does a two-pole Eaton CH breaker take up?
Each pole is a 3/4-inch standard CH frame, so a two-pole unit occupies two adjacent 3/4-inch spaces in the loadcenter. That narrower frame is why a CH panel fits more circuits in the same enclosure height than a 1-inch breaker panel. Count two consecutive open spaces on the same side of the bus before you install.
5) What amperages does the Eaton CH two-pole breaker come in?
Six ratings: 60A (CH260), 70A (CH270), 80A (CH280), 90A (CH290), 100A (CH2100) and 125A (CH2125). These are the larger two-pole sizes used for ranges, subfeeds, heat pumps, and feeder taps on 120/240 V single-phase service.
6) Can I use the CH2100 or CH2125 as a main breaker in a CH loadcenter?
Eaton lists this CH two-pole as suitable for main circuit breaker duty in Type CH loadcenters, which is why the 100A and 125A sizes are common choices for a main or a main-lug subpanel feed. The panel itself has to be rated for the breaker you install as the main, so size it to the loadcenter's bus rating, not above it.
7) Is the Eaton CH two-pole breaker UL listed for use in a commercial building panel?
It carries UL 489 certification, the standard for molded-case branch and feeder circuit breakers, so it is acceptable for residential, light commercial, and light industrial distribution at 120/240 V single phase. Institutional and MRO buyers standardizing a facility can specify the same CH frame across panels, which keeps one spare-breaker stock for the whole building.
8) Can I use this breaker on a 208V three-phase panel?
Not as specified. The CH two-pole is rated 120/240 V for single-phase service. Two poles landed across two legs of a 208Y/120 system is a different application and voltage rating than what this breaker is listed for, so for three-phase distribution you want a breaker rated for that system instead.
9) I'm replacing an old two-pole breaker in an existing Eaton CH panel. Do I need to match the amperage exactly?
Match the amperage to the circuit's wire size and the load, not just to whatever was in the slot, since a previous breaker may have been oversized. Then match the family: it has to be a CH frame breaker for a Type CH loadcenter. Available sizes in this two-pole group run 60A, 70A, 80A, 90A, 100A and 125A, each taking two 3/4-inch spaces.
