Eaton E58-30DPS280-HD-FC harsh...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,209.94
$1,159.94

Eaton E58-30DPS280-HD-FC harsh-duty sensor, E58 Tubular 30mm Photoelectric Sensor, 1.18 dia, dist. 11 In., PNP/NPN Open Collector, PNP: 100 mA, NPN: 100 mA at 30Vdc, 6.6 Ft (2m) Cable input, Latching short circuit, Background Suppression, 6.6 Ft. (2m

(No reviews yet) Write a Review

Model: E58-30DPS280-HD-FC
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,209.94
$1,159.94
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
Eaton harsh-duty sensor, E58 Tubular 30mm Photoelectric Sensor, 1.18 dia, dist. 11 In., PNP/NPN Open Collector, PNP: 100 mA, NPN: 100 mA at 30Vdc, 6.6 Ft (2m) Cable input, Latching short circuit, Background Suppression, 6.6 Ft. (2m)

Manufacturer Resources

Product Specs

Cable Type:
Polyvinyl Chloride (PVC)
Certifications:
UL Listed
Connection:
6.6 ft (2 m) cable
Contact Configuration:
PNP and NPN open collector
Contact Rating:
PNP: 100 mA, NPN: 100 mA at 30Vdc
Cord Length:
79.2 ft
Enclosure Material:
Stainless steel
Environmental Rating:
NEMA 1, NEMA 2, NEMA 3, NEMA 3R, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP69K
Input Voltage:
10-30 Vdc
Led Indicator:
Output status: red
Maximum Dc Current:
PNP: 100 mA, NPN: 100 mA
Operating Mode:
Background suppression
Operating Temperature Max:
131 °F
Operating Temperature Min:
-40 °F
Product Height:
4.36 in
Product Length Depth:
1.18 in
Product Weight:
.4563 lb
Product Width:
1.18 in
Protection:
Latching short circuit
Sensor Type:
Back ground suppression
Switch Type:
Photoelectric
Product Group:
Electrical
