Eaton Heavy-Duty Watertight Oiltight Selector Switch 120V LED Standard Actuator NEMA 4X Green 30.5mm

Eaton Heavy-Duty Watertight Oiltight Selector Switch

Professional Industrial Control Switch with LED Illumination

The Eaton Heavy-Duty Watertight Oiltight Selector Switch delivers exceptional electrical control performance for demanding industrial and commercial applications. This 120V LED illuminated selector switch with NEMA 4X rating provides reliable switching control designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Heavy-Duty Environmental Protection

• NEMA 4X Watertight and Oiltight Construction - Superior protection against water, oil, corrosion, and harsh environmental conditions for reliable operation in demanding industrial applications
• CSA Certified and CE Marked Compliance - Meets rigorous safety and performance standards for professional electrical installations and international applications
• 30.5mm Compact Design - Space-efficient mounting profile ideal for control panels, machinery, and equipment installations where space is premium
• Heavy-Duty Construction - Robust design engineered for frequent operation and long service life in industrial control applications

LED Illumination and Control

• 120V Full Voltage LED Illumination - Bright, energy-efficient LED indication provides clear visual status feedback for operators and maintenance personnel
• Green Plastic Lens - High-visibility green indication lens offers excellent visibility in various lighting conditions and industrial environments
• Standard Actuator Operation - Reliable switching mechanism designed for precise control and consistent performance in critical applications

Technical Specifications

Operating Voltage: 120V AC, LED Type: Full voltage LED illumination, NEMA Rating: NEMA 4X watertight and oiltight, Series: 10250T, Actuator: Standard actuator, Lens Material: Plastic, Lens Color: Green, Style: 30.5mm, Dimensions: 3.2" H x 2.1" W x 0.24" D, Weight: 0.4 lb, Certifications: CSA Certified, Compliances: CE Marked, Environmental Protection: Heavy-duty watertight and oiltight construction

Installation & Usage

1. Verify power is disconnected and follow proper lockout/tagout procedures before installation
2. Mount switch in appropriate NEMA 4X rated enclosure or panel cutout using proper mounting hardware
3. Connect 120V AC supply to LED illumination terminals following wiring diagram and local electrical codes
4. Connect control circuit wiring to selector switch contacts per application requirements
5. Verify proper actuator operation and LED illumination function before energizing connected equipment
6. Test environmental seal integrity and ensure proper NEMA 4X protection is maintained

Professional Applications

Ideal for:

• Industrial Control Panels - Machine control, process equipment, and automation systems requiring reliable switching with visual indication
• Manufacturing Equipment - Production machinery, conveyor systems, and processing equipment control applications
• Marine and Offshore Applications - Shipboard electrical systems, offshore platforms, and marine equipment requiring watertight protection
• Food Processing Facilities - Washdown environments, food production equipment, and sanitary applications requiring oiltight construction
• Chemical and Petrochemical Plants - Process control systems, pump stations, and equipment requiring corrosion-resistant switching
• Water Treatment Systems - Pump controls, valve actuators, and treatment equipment in wet environments
• Outdoor Electrical Equipment - Weather-exposed control applications requiring NEMA 4X environmental protection
• Heavy Industry Applications - Steel mills, mining equipment, and heavy machinery control systems

Heavy-Duty Design Advantage

Eaton's heavy-duty watertight and oiltight construction provides superior environmental protection compared to standard selector switches. The NEMA 4X rating ensures reliable operation in the presence of water, oil, corrosion, and harsh chemicals, while the LED illumination offers long-life, energy-efficient indication that outperforms traditional incandescent pilot lights in demanding industrial applications.

Why Choose Eaton Quality?

With over a century of electrical innovation and manufacturing excellence, Eaton delivers the quality, reliability, and performance that electrical professionals demand. Our heavy-duty selector switches are engineered to meet the rigorous requirements of industrial applications, backed by comprehensive CSA certification and CE marking for global compliance. Trusted by electricians, electrical contractors, and facility professionals worldwide, Eaton continues to lead in intelligent power management solutions that keep critical systems operating safely and efficiently.
