Eaton 14151AL17 OEM Prism 18mm...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$297.27
$247.27
Eaton 14151AL17 OEM Prism 18mm tubular photoelectric sensor, Forward Viewing, dist 10 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Polarized Retroreflective

Eaton 14151AL17 OEM Prism 18mm tubular photoelectric sensor, Forward Viewing, dist 10 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Polarized Retroreflective

(No reviews yet) Write a Review

Model: 14151AL17
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$297.27
$247.27
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton 14151RL17B1 OEM Prism 18mm tubular photoelectric sensor, Right Angle, dist 10 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Polarized Retroreflective, 6.6 Ft (2m

Eaton 14151RL17B1 OEM Prism 18mm tubular photoelectric sensor, Right Angle, dist 10 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Polarized Retroreflective, 6.6 Ft (2m

Model: EAT-14151RL17B1

Eaton OEM Prism 18mm tubular photoelectric sensor, Right Angle, dist 10 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable, 10-30 Vdc input, Current Limited for loads >32V...

Eaton

$297.27
$247.27
Eaton OEM Prism 18mm tubular photoelectric sensor, Forward Viewing, dist 10 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Polarized Retroreflective

Manufacturer Resources

Product Specs

Cable Type:
Polyvinyl Chloride (PVC)
Catalog Notes:
For complete system; order sensor and retroreflector. Retroreflector not included
Certifications:
cUL Recognized
Compliances:
CE Marked
Connection:
6.6 ft (2 m) cable
Contact Configuration:
Isolated solid state relay
Contact Rating:
80 mA at 132 Vac / 110 mA at 132Vdc
Cord Length:
79.2 ft
Enclosure Material:
Lens: polycarbonate
Environmental Rating:
NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13
Input Voltage:
10-30 Vdc
Led Indicator:
Output status: red
Maximum Ac Current:
80 mA
Maximum Dc Current:
110 mA
Operating Mode:
Polarized retroreflective
Operating Temperature Max:
131 °F
Operating Temperature Min:
-13 °F
Product Height:
2.75 in
Product Length Depth:
.47 in
Product Weight:
.2875 lb
Product Width:
.71 in
Protection:
Current limited for loads less than 32 Vac/dc
Sensor Type:
Polarized retroreflective
Switch Type:
Photoelectric
Product Group:
Electrical
!
