Eaton 12155RD07 OEM Prism 18mm...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$299.53
$249.53
Eaton 12155RD07 OEM Prism 18mm tubular photoelectric sensor, Right Angle, Sensor distance: 20 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 10-30 Vdc input, Current Limited for loads > 32V AC/DC, Thru-beam, 8 In. (.2m), 4 Pin M12 Connector

Eaton 12155RD07 OEM Prism 18mm tubular photoelectric sensor, Right Angle, Sensor distance: 20 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 10-30 Vdc input, Current Limited for loads > 32V AC/DC, Thru-beam, 8 In. (.2m), 4 Pin M12 Connector

(No reviews yet) Write a Review

Model: 12155RD07
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$299.53
$249.53
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton 12155AL07 OEM Prism 18mm tubular photoelectric sensor, Forward Viewing, Sensor distance: 20 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 4 Pin M12 Connector, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Thru-beam, 8 In. (.2m)

Eaton 12155AL07 OEM Prism 18mm tubular photoelectric sensor, Forward Viewing, Sensor distance: 20 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 4 Pin M12 Connector, 10-30 Vdc input, Current Limited for loads >32V AC/DC, Thru-beam, 8 In. (.2m)

Model: EAT-12155AL07

Eaton OEM Prism 18mm tubular photoelectric sensor, Forward Viewing, Sensor distance: 20 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 4 Pin M12 Connector, 10-30 Vdc input, Current Limited for...

Eaton

$299.53
$249.53
Eaton OEM Prism 18mm tubular photoelectric sensor, Right Angle, Sensor distance: 20 Ft., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 10-30 Vdc input, Current Limited for loads > 32V AC/DC, Thru-beam, 8 In. (.2m), 4 Pin M12 Connector

Manufacturer Resources

Product Specs

Cable Type:
Polyvinyl Chloride (PVC)
Catalog Notes:
Synchronous design requires source and detector to be wired to each other
Certifications:
UL Recognized
Compliances:
CE Marked
Connection:
4-pin M12 connector
Contact Configuration:
Isolated solid state relay
Contact Rating:
80 mA at 132 Vac / 110 mA at 132Vdc
Cord Length:
8 in
Enclosure Material:
Cable jacket: PVC
Environmental Rating:
NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13
Input Voltage:
10-30 Vdc
Led Indicator:
Output status: red
Maximum Ac Current:
80 mA
Maximum Dc Current:
110 mA
Operating Mode:
Thru-beam
Operating Temperature Max:
131 °F
Operating Temperature Min:
-13 °F
Product Height:
2.55 in
Product Length Depth:
.47 in
Product Weight:
.1313 lb
Product Width:
.71 in
Protection:
Current limited for loads less than 32 Vac/dc
Sensor Type:
Through beam
Switch Type:
Photoelectric
Product Group:
Electrical
!
