Eaton 11155AA14 Prism series Tubular photoelectric sensor, Photoelectric, 0.71 diameter, Forward Viewing, Sensor distance: 20 Ft., 6.6 Ft. (2m) Cable, 20–132 Vac/15-30 Vdc input, Thru-beam, 6.6 Ft. (2m)

Eaton 11155AA14 Prism series Tubular photoelectric sensor, Photoelectric, 0.71 diameter, Forward Viewing, Sensor distance: 20 Ft., 6.6 Ft. (2m) Cable, 20–132 Vac/15-30 Vdc input, Thru-beam, 6.6 Ft. (2m)

(No reviews yet) Write a Review

Model: 11155AA14
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$211.89
$161.89
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton 11100RSW6513 Comet 18mm tubular photoelectric sensor, Photoelectric, 0.71 diameter, Right Angle, Sensor distance: 20 Ft., Lens: Polycarbonate Cable, Jacket: PVC Body, 6.6 Ft. ( 2m ) Cable, 20-264 Vac/15-30 Vdc input, Thru-beam, 6.6 Ft. ( 2m )

Eaton 11100RSW6513 Comet 18mm tubular photoelectric sensor, Photoelectric, 0.71 diameter, Right Angle, Sensor distance: 20 Ft., Lens: Polycarbonate Cable, Jacket: PVC Body, 6.6 Ft. ( 2m ) Cable, 20-264 Vac/15-30 Vdc input, Thru-beam, 6.6 Ft. ( 2m )

Model: EAT-11100RSW6513

Eaton Comet 18mm tubular photoelectric sensor, Photoelectric, 0.71 diameter, Right Angle, Sensor distance: 20 Ft., Lens: Polycarbonate Cable, Jacket: PVC Body, 6.6 Ft. ( 2m ) Cable, 20-264 Vac/15-30...

Eaton

$360.21
$310.21
Eaton Prism series Tubular photoelectric sensor, Photoelectric, 0.71 diameter, Forward Viewing, Sensor distance: 20 Ft., 6.6 Ft. (2m) Cable, 20–132 Vac/15-30 Vdc input, Thru-beam, 6.6 Ft. (2m)

Manufacturer Resources

Product Specs

Cable Type:
Polyvinyl Chloride (PVC)
Catalog Notes:
Synchronous design requires source and detector to be wired to each other
Certifications:
UL Recognized
Compliances:
CE Marked
Connection:
6.6 ft (2 m) cable
Cord Length:
79.2 ft
Enclosure Material:
Body: structural polyurethane foam
Environmental Rating:
NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13
Input Voltage:
20-132 Vac, 15-30 Vdc
Led Indicator:
Power on: red
Operating Mode:
Thru-beam
Operating Temperature Max:
131 °F
Operating Temperature Min:
-13 °F
Product Height:
2.35 in
Product Length Depth:
.47 in
Product Weight:
.2 lb
Product Width:
.71 in
Sensor Type:
Through beam
Switch Type:
Photoelectric
!
