Eaton 30.5mm Heavy-Duty Watertight/Oiltight LED Indicating Light, Red Lens

Eaton 30.5mm Heavy-Duty Watertight/Oiltight LED Indicating Light, Red Lens

(No reviews yet) Write a Review

Model: 10250T206N

In Stock (leaves warehouse same day if ordered before 3pm ET)

$188.61
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 30.5mm Heavy-Duty Watertight/Oiltight LED Indicating Light, Red Lens

The Eaton 30.5mm Heavy-Duty Watertight/Oiltight LED Indicating Light is a full-voltage pilot light built for harsh industrial environments where dust, moisture, and oil are a daily reality. Featuring a 24 Vac/dc LED light unit, a red plastic lens, and a NEMA 3 rating, this 10250T series indicating light delivers dependable visual status signaling on control panels, machine enclosures, and industrial equipment. Backed by UL Listing and CE Marked compliance, it is engineered to hold up to demanding plant-floor conditions while keeping operators informed at a glance.

Key Features

  • Mounting Style: 30.5mm panel-mount style for standard heavy-duty operator interface cutouts.
  • Durable Construction: Heavy-Duty Watertight/Oiltight type resists moisture and oil intrusion in industrial settings.
  • Light Unit Type: LED, full voltage, for consistent brightness and long service life without a separate transformer.
  • Light Unit Voltage: 24 Vac/dc input for compatibility with common low-voltage control circuits.
  • Lens Material & Color: Plastic lens in red for clear, high-visibility status indication.
  • Environmental Rating: NEMA 3 rating suited to outdoor and harsh-duty enclosure applications.
  • Actuator: Standard actuator configuration for straightforward panel integration.
  • Compact Footprint: Approximately 2 in wide x 2.1 in deep x 2 in high, fitting standard panel layouts.

Certifications & Compliance

  • UL Listed
  • CE Marked
  • NEMA 3 Rated

Technical Specifications

  • Warranty: 1 year
  • Product Type: Pushbutton
  • Department: Electrical

Typical Applications

  • Industrial Control Panels and Operator Interfaces
  • Machine Status and Fault Indication
  • Outdoor and Wet-Location Equipment Enclosures
  • Oil-Exposed Manufacturing and Processing Environments
  • Panel-Mount Pilot Light Retrofits
  • Heavy-Duty Industrial Automation Systems

Why Eaton?

Eaton's 10250T series heavy-duty watertight/oiltight indicating lights are built for professionals who need reliable visual signaling in tough industrial conditions. With UL Listed and CE Marked compliance, a rugged NEMA 3 rated housing, and a full-voltage LED light unit, this indicating light is designed for consistent, code-compliant performance across control panel and machine-interface applications.

Manufacturer Resources

Product Specs

Warranty:
1 year
Series:
10250T
Product Type:
Pilot Light
Department:
Electrical
Compliances:
CE Marked
Product Style:
30.5 mm
Product Material:
Plastic
Product Color:
Red
Voltage Rating:
24V AC/DC
Standards:
NEMA 3
Listing:
UL Listed
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices

Eaton 10250T206N – Frequently Asked Questions

1) What control voltage does this Eaton 10250T LED pilot light run on?
24 Vac or 24 Vdc. It is a full-voltage LED light unit, so it wires straight to a 24 V control circuit with no separate transformer or resistor. Feeding it 120 V will destroy it, so if your panel runs 120 V control power you need the 120 V version of the light unit.
2) Can this indicating light be used on an outdoor or washdown enclosure?
It carries a NEMA 3 rating and is a watertight/oiltight type, which covers outdoor and harsh-duty enclosures where rain, dust and oil are present. NEMA 3 is rain and windblown dust protection, not a high-pressure washdown rating, so for direct hose-down duty you want a device rated NEMA 4 or 4X.
3) Is the lens on this Eaton pilot light glass or plastic, and what color?
Red plastic lens. Plastic holds up to knocks better than glass on a machine-mounted panel, and red is the usual choice for fault, stop, or power-on indication depending on your legend. Color is fixed on this unit, so if you are building a stack of run/fault indicators you order a separate light for each color.
4) Which Eaton 10250T part numbers are available on this indicating light?
Four 10250T catalog numbers: 10250T197LRP24, 10250T206N, 10250T221L and 10250T231N. If you are matching what is already in an existing panel, order by the exact number stamped on the device you are replacing, since the family covers both watertight and oiltight configurations.
5) Will an LED unit like this last longer than the incandescent pilot lights in my old panel?
The light unit here is LED rather than incandescent, which is the main reason plants retrofit these: no filament to burn out and consistent brightness over service life. It is a direct panel-mount replacement for an existing 30.5 mm 10250T pilot light in the same voltage, which makes it a common swap on older control panels.
