Eaton R9 Series Rotary Disconn...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$304.90
Eaton R9 Series Rotary Disconnect Switch, 60A, Non-Fusible, Three-Pole, 600V, C Frame

Eaton R9 Series Rotary Disconnect Switch, 60A, Non-Fusible, Three-Pole, 600V, C Frame

(No reviews yet) Write a Review

Model: R9C3030U

In Stock (leaves warehouse same day if ordered before 3pm ET)

$304.90
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton R9 Series Rotary Disconnect Switch, 60A, Non-Fusible, Three-Pole, 600V, C Frame

The Eaton R9 Series Rotary Disconnect Switch is a 60A, non-fusible, three-pole switch body engineered for dependable power isolation in industrial, commercial, and OEM electrical systems. Rated for 600V, this C frame switch body provides safe, positive on/off load-break control for equipment disconnects, motor control centers, panelboards, and switchboard assemblies. Built on Eaton's established R9 platform, it delivers consistent three-pole switching performance in installations where overcurrent protection is handled by separate fusing or upstream breakers, giving electricians and panel builders a compact, code-ready disconnect solution for demanding applications.

Key Features

  • Amperage Rating: 60A rotary disconnect switch body rated for reliable circuit isolation and load-break switching.
  • Voltage Rating: 600V rated construction suitable for demanding industrial and commercial power distribution systems.
  • Three-Pole Configuration: Three-pole switching design supports balanced multi-phase disconnect control for three-phase equipment and feeders.
  • Non-Fusible Design: Switch body configuration without integral fuse holders, ideal for installations where overcurrent protection is provided separately.
  • C Frame Switch Body: R9 Series C frame construction sized for compact enclosure, panelboard, and control cabinet installations.
  • R9 Series Platform: Part of Eaton's R9 Series rotary disconnect switch line, engineered for consistent, dependable switching performance.
  • Rotary Operation: Rotary switch mechanism provides clear, positive on/off indication for safe lockout/tagout procedures.

Technical Specifications

  • Voltage Rating: 600V
  • Series: R9
  • Product Type: Disconnect Switch
  • Number of Poles: Three-pole
  • Fuse Configuration: Non-fusible
  • Product Category: Switch Body

Typical Applications

  • Industrial Motor Control Centers
  • Panelboard and Switchboard Disconnects
  • Three-Phase Power Isolation and Lockout/Tagout Points
  • Commercial Electrical Equipment Rooms
  • OEM Control Panel and Enclosure Assemblies
  • New Construction and Retrofit Disconnect Upgrades

Why Eaton?

Eaton's R9 Series rotary disconnect switches are engineered for dependable, code-compliant performance in demanding electrical environments. With a 600V rating, three-pole non-fusible switch body, and compact C frame construction, this R9 Series unit is built to deliver consistent, positive load-break switching for professional electrical installations that require a trusted, code-ready disconnect solution from a recognized electrical manufacturer.

Manufacturer Resources

Product Specs

Product Width:
3.07 in
Voltage Rating:
600V
Product Length/Depth:
2.52 in
Product Height:
5.62 in
Number of poles:
Three-pole
Product Category:
Switch Body
Fuse configuration:
Non-fusible
Series:
R9
Product Type:
Disconnect Switch
Department:
Electrical
Configuration:
Three-Pole
Amperage Rating:
60A
Product Group:
Disconnect Switches

Eaton R9C3030U – Frequently Asked Questions

1) Does the Eaton R9C rotary disconnect switch include fuses or fuse holders?
No. The R9C is a non-fusible switch body, so there are no integral fuse holders. Overcurrent protection has to come from separate fusing or an upstream breaker. If your design relies on the disconnect itself to carry the fuses, this is the wrong part for that opening.
2) What amperage ratings does the Eaton R9C three-pole disconnect switch come in?
Three ratings across the C frame three-pole line: 30 amp (R9C3030U), 60 amp (R9C3060U), and 100 amp (R9C3100U). All are 600V rated, three-pole, non-fusible bodies, so you size on load current and keep the same frame and footprint.
3) Will the Eaton R9C disconnect switch body fit inside my control enclosure?
The C frame body measures 5.62 x 3.07 x 2.52 inches (height, width, length/depth). Lay that against your backplate and door clearance before you commit, particularly depth behind the operator if the enclosure is shallow.
4) Can I use the Eaton R9C on a 480V three-phase motor circuit?
Yes. The switch body is rated 600V and is three-pole, which covers 208, 240, and 480 volt three-phase feeders and motor circuits. It switches all three phases together for a single positive on/off.
5) Is the R9C a complete disconnect or do I need to order more parts to finish it?
What you are buying is the switch body itself. A rotary disconnect assembly normally also needs an operating handle and shaft to reach the enclosure door, and the enclosure if you are not mounting it inside existing gear. Plan the handle and shaft alongside the body so the assembly is complete when you get to the panel.
6) Is the Eaton R9C rotary switch suitable as a lockout/tagout isolation point?
That is one of its intended uses. The rotary mechanism gives a clear, positive on/off position for lockout/tagout at three-phase isolation points, equipment disconnects, and motor control centers.
7) I need a single-phase disconnect. Is the R9C three-pole switch right for that?
Not really. The R9C bodies are three-pole switching units built for balanced multi-phase disconnect duty. For a single-phase or two-wire load you want a two-pole switch body instead, otherwise you are paying for a pole you will not land a conductor on.
8) Can the Eaton R9C be used for equipment disconnects in a panelboard or switchboard assembly?
Yes, that is the design intent. The C frame body is sized for panelboard, switchboard, control cabinet, and OEM enclosure assemblies, and it works in new construction or as a retrofit disconnect upgrade where the existing overcurrent protection stays upstream.
