Eaton R9 Series Rotary Disconnect Switch, 200A, Three-Pole, Non-Fusible

Eaton R9 Series Rotary Disconnect Switch, 200A, Three-Pole, Non-Fusible

(No reviews yet) Write a Review

Model: R9D3200U

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,022.40
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton R9 Series Rotary Disconnect Switch, 200A, Three-Pole, Non-Fusible

The Eaton R9 Series Rotary Disconnect Switch is a 200A, three-pole, non-fusible switch body engineered for reliable manual disconnection of power in industrial and commercial electrical systems. Rated 600V and CSA Certified, this switch body provides a rugged, compact footprint for use as the core switching element within enclosed disconnect assemblies. As part of Eaton's trusted R9 series, it is built to deliver dependable, code-compliant power control for demanding applications.

Key Features

  • Amperage Rating: 200A switch body rated for heavy-duty power switching applications.
  • Configuration: Three-pole design supports disconnection of three-phase power circuits.
  • Fuse Configuration: Non-fusible switch body for installations where separate overcurrent protection is provided elsewhere in the system.
  • Voltage Rating: 600V rating suits industrial and commercial power distribution systems.
  • Series: Part of the Eaton R9 series of rotary disconnect switch bodies.
  • Compact Footprint: 12.5 in wide x 9.5 in deep x 5.5 in high switch body dimensions for space-efficient enclosure integration.

Certifications & Compliance

  • CSA Certified

Technical Specifications

  • Product Width: 12.5 in
  • Product Length/Depth: 9.5 in
  • Product Height: 5.5 in
  • Number of Poles: Three-pole
  • Amperage Rating: 200A
  • Voltage Rating: 600 V
  • Fuse Configuration: Non-fusible
  • Series: R9
  • Certifications: CSA Certified
  • Warranty: Eaton Selling Policy 25-000, one (1) year from date of installation or eighteen (18) months from date of shipment, whichever occurs first.

Typical Applications

  • Industrial Power Distribution Systems
  • Motor Control and Protection Panels
  • Commercial Electrical Switchgear Assemblies
  • Panelboard and Switchboard Installations
  • Renovation and New Construction Electrical Projects

Why Eaton?

Eaton's R9 series rotary disconnect switch bodies combine a non-fusible, three-pole design with a CSA Certified 600V rating for dependable performance in critical power control applications. Backed by Eaton's manufacturer warranty and built for durable, code-compliant operation, this switch body is a solid choice for electrical professionals specifying reliable disconnect solutions.

Manufacturer Resources

Product Specs

Product Width:
12.5 in
Number of poles:
Three-pole
Amperage Rating:
200A
Product Category:
Switch Body
Voltage Rating:
600V
Fuse configuration:
Non-fusible
Series:
R9
Product Length/Depth:
9.5 in
Product Height:
5.5 in
Certifications:
CSA Certified
Product Type:
Disconnect Switch
Department:
Electrical
Configuration:
Three-Pole
Listing:
CSA Certified
Product Group:
Disconnect Switches

Eaton R9D3200U – Frequently Asked Questions

1) Does the Eaton R9D3200U disconnect switch include fuses or fuse clips?
No. The R9 Series 200A switch, model R9D3200U, is a non-fusible three-pole switch body, so there are no fuse clips and no overcurrent protection built in. Your overcurrent device has to live somewhere else in the circuit, typically upstream breakers in the panelboard or switchboard feeding it. If the design calls for fused disconnection at the point of isolation, this is the wrong body and you want a fusible switch instead.
2) Is the Eaton R9 200A rotary switch a complete disconnect, or do I need an enclosure?
It is a switch body only, not a packaged enclosed disconnect. The R9D3200U is the core switching element intended to be mounted inside an enclosed disconnect assembly, panelboard, switchboard, or motor control panel. You supply the enclosure, the operating handle and shaft arrangement, and any line and load terminations the assembly needs. If you want a bolt-to-the-wall unit that arrives ready to wire, order an enclosed safety switch rather than a bare body.
3) Will an Eaton R9 200A switch body fit inside my enclosure?
Plan the cavity around 12.5 x 9.5 x 5.5 inches: the R9 200A body is listed at 12.5 in wide, 9.5 in deep, and 5.5 in high. Lay that out against your backpan before you commit, and leave room behind it for the rotary shaft and the bending space your conductors need at 200A. On a 200A three-phase feeder those cable bends usually drive the enclosure size more than the switch does.
4) Can I use the Eaton R9 200A switch on a 480V or 600V three-phase system?
Yes. The R9 200A body carries a 600V rating and is a three-pole device, so it switches all three ungrounded conductors of a three-phase system at 600V, 480V, or 208/240V. Neutral and ground are not switched by a three-pole body; if you need the neutral broken too, you need a four-pole arrangement.
5) Is the Eaton R9D3200U approved for use on a Canadian job?
The R9 200A three-pole switch body is CSA Certified, which is the listing Canadian authorities having jurisdiction look for under the CEC. That certification applies to the switch body itself; the enclosed assembly it goes into has its own approval requirements, so check how the panel builder has certified the finished assembly.
6) Can this Eaton R9 switch be used as a motor disconnect?
It is used in motor control and protection panels as the manual disconnecting means, and the three-pole 600V, 200A body suits three-phase motor feeders. Because it is non-fusible, motor branch circuit short-circuit and ground-fault protection has to be provided separately by the breaker or fuses ahead of it, and overload protection by the starter. It is a disconnecting and isolation device, not a protective one.
7) What do I order to match an existing Eaton R9 disconnect in the panel?
Match on catalog number: this one is R9D3200U, the 200A three-pole non-fusible body in Eaton's R9 series. Amperage, pole count, and fuse configuration all have to line up for the body to drop into the same shaft and mounting arrangement, so confirm the existing unit is a 200A three-pole non-fusible before ordering a like-for-like replacement.
