Eaton Molded Case Circuit Breaker 35A Three-Pole 480Y/277V Series C G-Frame Fixed Thermal-Magnetic

Eaton Molded Case Circuit Breaker 35A Three-Pole 480Y/277V Series C G-Frame Fixed Thermal-Magnetic

Professional Electrical Power Protection & Distribution Equipment

The Eaton Series C Molded Case Circuit Breaker delivers exceptional electrical power protection and control performance for commercial and industrial electrical systems. This 35 ampere three-pole circuit breaker with 480Y/277 Vac and 125/250 Vdc ratings provides reliable electrical protection designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Advanced Circuit Protection Performance

• 35 Ampere Rating with Three-Pole Configuration - Provides comprehensive electrical protection for three-phase commercial and industrial power distribution systems with reliable current capacity
• Dual Voltage Capability 480Y/277 Vac and 125/250 Vdc - Versatile voltage ratings accommodate both AC and DC applications for maximum installation flexibility in diverse electrical environments
• Fixed Thermal-Magnetic Trip Technology - Combines thermal overload protection with magnetic short-circuit protection for comprehensive electrical fault detection and system safety
• Series C G-Frame Construction - Robust molded case design engineered for reliable performance in demanding commercial and industrial electrical applications

Professional Installation & Protection

• Complete Molded Case Design - Ready-to-install circuit breaker with integrated protection mechanisms for streamlined electrical panel installation
• 50/60 Hz Frequency Rating - Compatible with standard North American electrical systems for versatile commercial and industrial applications
• Three-Pole Configuration - Simultaneous protection for all three phases ensuring balanced electrical system protection and reliable power distribution

Technical Specifications

Amperage Rating: 35A, Voltage Rating: 480Y/277 Vac, 125/250 Vdc, Number of Poles: Three-pole, Frame: G-frame, Series: Series C, Trip Type: Fixed thermal, Fixed magnetic, Frequency Rating: 50/60 Hz, Construction: Complete molded case circuit breaker

Installation & Usage

1. Verify electrical system compatibility with 35A three-pole requirements and 480Y/277V or 125/250V DC specifications
2. Ensure proper electrical panel space and mounting provisions for G-frame molded case circuit breaker installation
3. Connect three-phase conductors to appropriate terminals following NEC guidelines and manufacturer specifications
4. Verify proper grounding and bonding connections for electrical safety and code compliance
5. Test circuit breaker operation including thermal and magnetic trip functions before energizing electrical system
6. Label circuit breaker clearly for identification and maintenance purposes in electrical distribution panel

Professional Applications

Ideal for:

• Commercial Electrical Systems - Office buildings, retail facilities, and commercial properties requiring reliable three-phase power protection
• Industrial Power Distribution - Manufacturing facilities, processing plants, and industrial operations with 480V three-phase electrical systems
• Motor Control Centers - Protection for three-phase motors and industrial equipment in motor control applications
• Electrical Distribution Panels - Main and sub-panel installations requiring robust circuit protection for commercial and industrial loads
• HVAC System Protection - Three-phase heating, ventilation, and air conditioning equipment electrical protection
• Lighting Control Systems - Commercial and industrial lighting circuits requiring reliable electrical protection and control
• Power Distribution Equipment - Switchgear, load centers, and electrical distribution systems in commercial and industrial facilities
• Electrical Safety Systems - Critical electrical protection for facilities requiring dependable power management and fault protection

Fixed Thermal-Magnetic Protection Advantage

The fixed thermal-magnetic trip technology provides dual-mode protection combining thermal elements for overload conditions and magnetic elements for short-circuit faults. This proven protection method ensures reliable electrical system safety with consistent trip characteristics, making it ideal for applications requiring dependable circuit protection without adjustment complexity.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton delivers the reliability and performance that electrical professionals trust. Our molded case circuit breakers meet rigorous UL and CSA standards, providing the electrical safety and dependable operation that electricians, electrical contractors, and facility professionals rely on for critical power protection applications worldwide.
