Eaton Series C GHB G-Frame Molded Case Circuit Breaker, Single-Pole, 20A

(No reviews yet) Write a Review

Model: GHBGFEP1020

In Stock (leaves warehouse same day if ordered before 3pm ET)

$613.80
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Series C GHB G-Frame Molded Case Circuit Breaker, Single-Pole, 20A

The Eaton Series C GHB is a complete molded case circuit breaker built on the G-frame platform, rated 20A single-pole with a fixed thermal, fixed magnetic trip type. It carries a voltage rating of 480Y/277 Vac and 125/250 Vdc, an interrupt rating of 14 kAIC at 277 Vac, and is UL Listed for demanding commercial and industrial branch-circuit protection applications.

Key Features

  • Compact G-Frame Design: Measures 1 in wide, 4 in high, and 2.63 in deep for space-efficient panelboard installation.
  • Amperage Rating: 20A rated for reliable overcurrent protection in single-pole circuits.
  • Trip Type: Fixed thermal, fixed magnetic trip provides consistent, non-adjustable overload and short-circuit protection.
  • Voltage Rating: 480Y/277 Vac, 125/250 Vdc for versatile use across AC and DC distribution systems.
  • Interrupt Rating: 14 kAIC at 277 Vac ensures dependable fault-current interruption.
  • Frequency Rating: 50/60 Hz supports standard utility and industrial power systems.
  • Circuit Breaker Type: GHB, part of Eaton's Series C lineup of molded case circuit breakers.
  • Number of Poles: Single-pole configuration for dedicated branch-circuit protection.

Certifications & Compliance

  • UL Listed

Technical Specifications

  • Frame: G
  • Circuit breaker type: GHB

Typical Applications

  • Commercial and Industrial Electrical Panelboards
  • Branch-Circuit Overcurrent Protection
  • Load Center and Distribution Panel Upgrades
  • Renovation and New Construction Electrical Systems
  • Single-Pole 20A Circuit Applications

Why Eaton?

Eaton's Series C GHB molded case circuit breaker delivers dependable, UL Listed overcurrent protection built on the proven G-frame platform. With a fixed thermal, fixed magnetic trip and a 14 kAIC interrupt rating at 277 Vac, this breaker is engineered for consistent, code-compliant performance in professional electrical installations.

Manufacturer Resources

Product Specs

Product Width:
1 in
Voltage Rating:
480Y/277V
Amperage Rating:
20A
Product Length/Depth:
2.63 in
Frame:
G
Product Height:
4 in
Frequency rating:
50/60 Hz
Number of poles:
Single-pole
Series:
Series C
Interrupt rating:
14 kAIC at 277 Vac
Circuit breaker type:
GHB
Trip Type:
Fixed thermal, fixed magnetic
Certifications:
UL Listed
Product Type:
Circuit Breaker
Department:
Electrical
Configuration:
Single-Pole
Listing:
UL Listed
Product Group:
Circuit Breakers
