Product Specs
- Amperage Rating:
- 32A
- Circuit Breaker Type:
- EG
- Frame Size:
- EG-frame
- Frequency Rating:
- 50/60 Hz
- Interrupt Rating:
- 25 kAIC at 240 Vac, 18 kAIC at 480 Vac
- Notes:
- Not UL Listed
- Number Of Poles:
- Four-pole
- Series:
- Series G
- Special Features:
- Not UL rated
- Terminals:
- Line and load
- Trip Type:
- Adjustable thermal, fixed magnetic
- Voltage Rating:
- 600Y/347 Vac
- Department:
- Electrical
- Product Group:
- Electrical Components
- Product Subgroup:
- Circuit Breakers
- Product Type:
- Complete breaker
- Product Length:
- 2.99 IN
- Product Details:
- Complete breaker
- Product Height:
- 5.5 IN
- Product Weight:
- 4 LB
- Product Width:
- 4 IN
B-LINE EGB4032AFG – Frequently Asked Questions
1) Is the Eaton Series G EGB4032AFG UL Listed?
No. The EGB4032AFG is not UL Listed, and that is stated on the breaker's data as a special feature. If your inspector, spec, or facility standard requires a UL Listed molded case breaker, this one will not satisfy it. It is commonly the right choice for export, OEM, or IEC-standard equipment builds where a UL Listing is not the governing requirement.
2) How many poles does the EGB4032AFG have, and can I use it for a three-phase four-wire circuit?
It is a four-pole breaker, so it switches three phases plus the neutral or a fourth conductor. For a standard three-phase, three-wire load you would want a three-pole version of the EG frame instead; the four-pole is for four-wire systems where the neutral must be switched as well.
3) Can the trip setting on the EGB4032AFG be adjusted in the field?
Partly. The thermal (overload) element is adjustable, so you can dial the long-time setting down from the 32A rating to suit the conductor or motor you are protecting. The magnetic (instantaneous, short-circuit) element is fixed and cannot be changed. If your application needs an adjustable instantaneous pickup for coordination, you need an electronic-trip breaker rather than this thermal-magnetic unit.
4) Will a 32A EG-frame breaker fit the panel space I have?
The EG-frame body measures 5.5 by 4 by 2.99 inches (height, width, length as published) and weighs 4 lb. Confirm your enclosure or DIN/panel mounting area against those numbers, since a four-pole frame is wider than the two- and three-pole versions of the same series.
5) Does the EGB4032AFG come with terminals, or do I have to order lugs separately?
Line and load terminals are included, and it ships as a complete breaker rather than a trip unit or frame-only assembly. Verify terminal wire range against your conductor size for the 32A rating before install.
6) Can this breaker be used on a 50 Hz system overseas?
Yes. The Series G EG breaker is rated 50/60 Hz, so it works on both North American 60 Hz and 50 Hz systems. Combined with the 600Y/347 Vac rating, it suits export panels and equipment built for international supply.
7) What exact part number should I order for the 32A four-pole Eaton Series G breaker?
Order Eaton Series G EGB4032AFG. That is the complete four-pole, 32A EG-frame molded case breaker with adjustable thermal and fixed magnetic trip. Adjacent EG-frame catalogue numbers change the pole count and amperage, so match the full designation rather than just the series.
