Spec Sheet
Product Specs
- Amperage Rating:
- 15A
- Circuit Breaker Type:
- EG
- Frame Size:
- EG-frame
- Frequency Rating:
- 50/60 Hz
- Interrupt Rating:
- 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, 35 kAIC at 600Y/347 Vac
- Number Of Poles:
- Three-pole
- Series:
- Series G
- Terminals:
- Line and load
- Trip Type:
- Fixed thermal, fixed magnetic
- Voltage Rating:
- 600Y/347 Vac
- Product Subgroup:
- circuit breaker
- Department:
- Electrical
- Product Group:
- Electrical Components
- Product Type:
- Complete breaker
- Product Length:
- 2.99 IN
- Product Details:
- Complete breaker
- Product Height:
- 5.5 IN
- Product Weight:
- 3 LB
- Product Width:
- 3 IN
- Compliances:
- CE Marked
- Frame:
- EG
- Certifications:
- IEC Rated
B-LINE EGH3015FFG – Frequently Asked Questions
1) Will the Eaton EGH3015FFG work on a 480V three-phase panel?
Yes. The EGH3015FFG is a three-pole EG-frame breaker rated up to 600Y/347 Vac, so 480V three-phase is within its rating. Interrupting capacity steps down as voltage rises: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 35 kAIC at 600Y/347 Vac. Match the 65 kAIC figure against the available fault current at your 480V panel.
2) Is the EGH3015FFG a complete breaker or just a trip unit I have to build up?
It ships as a complete breaker with line and load terminals included, so there is no separate trip unit or terminal kit to order. The 15A EG-frame three-pole assembly is ready to land conductors on both ends.
3) Can the trip settings on the Eaton EGH3015FFG be adjusted in the field?
No. This breaker uses a fixed thermal, fixed magnetic trip, so neither the long-time nor the instantaneous pickup can be dialled in. It protects at its fixed 15A rating. If your coordination study calls for adjustable settings, you need an electronic-trip breaker instead.
4) What space do I need in the panel or enclosure for the EGH3015FFG?
The breaker measures 5.5 in height, 2.99 in length, 3 in width, and weighs 3 lb. Use those figures when checking gutter space and mounting depth in an existing EG-frame cutout.
5) Does the EGH prefix mean a different interrupting rating than other Series G EG-frame breakers?
Yes. Within Eaton's Series G molded case line the letter after EG denotes the interrupting class, and the H on the EGH3015FFG corresponds to 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 35 kAIC at 600Y/347 Vac. Lower-class EG-frame breakers of the same 15A, three-pole configuration will not carry those numbers, so order by the full catalog number EGH3015FFG rather than by amperage and pole count alone.
6) Is a 15A EG-frame breaker usable on 50 Hz equipment overseas?
Yes, the EGH3015FFG carries a 50/60 Hz frequency rating, so it is suitable for either 50 Hz or 60 Hz systems within its voltage and interrupting ratings.
7) Where can I get the full Eaton spec sheet for the EGH3015FFG?
Eaton publishes a dedicated spec sheet for the EGH3015FFG, and it is linked directly from the product description. It backs up the 15A, three-pole, EG-frame Series G ratings listed in the specs.
