Product Specs
- Amperage Rating:
- 160A
- Circuit Breaker Type:
- JG
- Frame Size:
- JG-frame
- Frequency Rating:
- 50/60 Hz
- Interrupt Rating:
- 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, 18 kAIC at 600 Vac
- Mounting Hardware:
- Metric
- Number Of Poles:
- Three-pole
- Series:
- Series G
- Special Features:
- Not UL rated
- Terminals:
- Line and load
- Trip Type:
- Electronic LSI
- Voltage Rating:
- 600 Vac
- Department:
- Electrical
- Product Group:
- Electrical Components
- Product Subgroup:
- Circuit Breakers
- Product Type:
- Complete breaker
- Product Length:
- 3.57 IN
- Product Details:
- Complete breaker
- Performance Rating:
- 80% rated
- Product Height:
- 4.13 IN
- Product Weight:
- 6 LB
- Product Width:
- 4.13 IN
B-LINE JGS316032G – Frequently Asked Questions
1) What is the interrupting capacity of the JGS316032G at 480V?
Interrupting ratings run 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac. If your available fault current at the 480 volt switchboard exceeds 35 kA, this frame does not meet the study on its own and you need a higher AIC breaker or a series-rated combination.
2) Does the JGS316032G have adjustable trip settings?
It uses an electronic LSI trip unit, so you get adjustable long time, short time, and instantaneous protection. That lets you coordinate with upstream and downstream devices rather than living with a fixed thermal-magnetic curve, which matters on a feeder where selective coordination is part of the spec.
3) Does the JGS316032G come with line and load lugs, or do I order them separately?
Line and load terminals are included, and the unit ships as a complete breaker rather than a frame or trip unit alone. Mounting hardware is metric, so plan for metric fasteners and metric hole spacing in the enclosure or panel you are landing it in.
4) What are the dimensions and weight of the JGS316032G so I can check my enclosure space?
The breaker measures 4.13 x 3.57 x 4.13 inches (height, length, width) and weighs 6 pounds. Allow clearance beyond that footprint for the line and load terminal lugs and cable bending radius, which are not part of the body dimensions.
5) Will this breaker work on a 50 Hz system overseas?
Yes, the JGS316032G is rated 50/60 Hz, so it works on both 50 Hz and 60 Hz distribution. Combined with metric mounting hardware and the JG frame, it is set up for IEC-style gear as much as North American equipment, though note it is not a UL rated device.
