Eaton Glass Fiberoptic Forward Viewing Sensor Cable, Stainless Steel, NEMA 4X/6P/12/13, IP67

Eaton Glass Fiberoptic Forward Viewing Sensor Cable, Stainless Steel, NEMA 4X/6P/12/13, IP67

(No reviews yet) Write a Review

Model: E51KFH1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$204.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Glass Fiberoptic Forward Viewing Sensor Cable, Stainless Steel, NEMA 4X/6P/12/13, IP67

The Eaton Glass Fiberoptic Forward Viewing Sensor Cable is a fiber-optic sensing cable built with a stainless steel enclosure for durable performance in demanding industrial environments. Rated NEMA 3, 3S, 4, 4X, 6, 6P, 12, 13 and IP67, this cable is engineered for reliable forward-viewing fiberoptic sensing applications where dust, moisture, and washdown exposure are a concern. With an operating temperature range from -49°F to 480°F, it is suited for wide-ranging thermal environments across manufacturing and process facilities.

Key Features

  • Product Dimensions: .31 in width x 1.5 in length/depth x 36 in height for precise fit in sensing setups.
  • Durable Construction: Stainless steel enclosure material for corrosion resistance and long service life.
  • Sensor Type: Fiberoptic, forward viewing configuration for directional sensing applications.
  • Operating Mode: Fiber-optic operation for reliable signal transmission in industrial sensing systems.
  • Wide Temperature Range: Rated from -49°F to 480°F operating temperature for use across varied thermal conditions.
  • Environmental Rating: NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, and IP67 for use in washdown, dusty, and wet environments.
  • Installation Note: Collar mounting cables and standard mounting cables are not interchangeable and must be coupled to the correct sensor; two cables are needed, one for the source and one for the detector.

Certifications & Compliance

  • UL Listed
  • NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13 Rated
  • IP67 Rated

Technical Specifications

  • Department: Electrical
  • Warranty: 3 year
  • Product Type: Electrical Component

Typical Applications

  • Industrial Automation and Process Sensing
  • Washdown and Wet-Location Environments
  • Dusty and Harsh Industrial Facilities
  • Fiberoptic Source and Detector Sensing Systems
  • Manufacturing and Process Control Equipment

Why Eaton?

Eaton fiberoptic sensor cables combine a stainless steel enclosure with broad NEMA and IP67 environmental ratings, delivering dependable sensing performance in harsh industrial settings. Backed by a 3 year warranty and UL Listed certification, this cable is built for code-compliant, reliable performance in professional sensing and automation applications.

Manufacturer Resources

Product Specs

Department:
Electrical
Warranty:
3 year
Certifications:
UL Listed
Sensor Type:
Fiberoptic
Product Type:
Fiberoptic Sensor Cable
Product Material:
Stainless Steel
Listing:
UL Listed
Standards:
NEMA 3,3S,4,4X,6,6P,12,13
Product Group:
Wiring Devices
Product Subgroup:
Lighting Controls & Sensors

Eaton E51KFH1 – Frequently Asked Questions

1) Do I need one Eaton E51K fiberoptic cable or two for a through-beam sensor setup?
Two. The Eaton glass fiberoptic forward viewing sensor cable is used in pairs for through-beam sensing, one cable on the source and one on the detector. Ordering a single cable leaves half the sensing path unfinished.
2) Will a collar mounting fiberoptic cable work on a sensor prepped for the standard mount?
No. Collar mounting cables and standard mounting cables are not interchangeable, and the cable has to be coupled to the correct sensor style. Confirm which mounting the sensor head uses before you pick the model.
3) Can this Eaton fiberoptic cable be used in a washdown food plant?
Yes. The stainless steel enclosure and the NEMA 3, 3S, 4, 4X, 6, 6P, 12 and 13 plus IP67 ratings cover washdown, wet, dusty and corrosive areas. NEMA 4X and 6P are the ones that matter for hosedown and temporary submersion.
4) What temperature range can these Eaton glass fiberoptic cables handle?
Minus 49 F up to 480 F. That is what makes the glass fiber version the choice near ovens, furnaces, and heat-treat lines where a plastic fiber cable would not survive.
5) How long are the Eaton E51K fiberoptic sensor cables?
The stated dimensions are .31 in width by 1.5 in length/depth by 36 in height, so plan on a 36 inch fiber run between the sensor head and the sensing point. If the amplifier sits further away than that, the run will not reach.
6) Which Eaton E51K fiberoptic cable models are available?
Four models: E51KF823, E51KFH1, E51KT573 and E51KT623. All share the stainless steel glass fiberoptic forward viewing construction; pick the model that matches the mounting style and sensor your E51 head uses.
7) Is this fiberoptic cable UL Listed for a spec-driven industrial job?
Yes, the Eaton fiberoptic sensor cable is UL Listed, alongside its NEMA 3 through 13 and IP67 environmental ratings. That combination is normally what a plant or institutional spec asks for on sensing hardware in wet or dusty areas.
8) What does forward viewing mean on a fiberoptic sensor cable, and when would I want it instead?
Forward viewing means the fiber emits and receives straight out the end of the tip, in line with the cable, so the beam points along the axis of the run. Use it when the target passes directly in front of the cable end. If your target passes alongside the cable instead of in front of it, you need a side-viewing fiber, not this one.
9) Is this a signal cable or an electrical power cable?
Neither power nor copper signal. It is a fiberoptic light guide that carries the sensing beam between the sensor head and the point of detection, so there are no conductors and no electrical noise pickup along the run.
