Eaton M22 RMQ-Titan 22.5 mm Flush Pushbutton, Red Actuator, IP67/NEMA 4X

Eaton M22 RMQ-Titan 22.5 mm Flush Pushbutton, Red Actuator, IP67/NEMA 4X

(No reviews yet) Write a Review

Model: M22S-D-B
Selected Bezel Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$8.70
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton M22 RMQ-Titan 22.5 mm Flush Pushbutton, Red Actuator, IP67/NEMA 4X

The Eaton M22 RMQ-Titan Flush Pushbutton is a 22.5 mm red-actuator momentary control device engineered for flush mounting in industrial control panels and operator stations. Built with a 1NC contact configuration and non-illuminated actuator, this M22 series pushbutton is rated NEMA 4X and NEMA 13 with IP67 and IP69K environmental protection, and it is CSA Certified for demanding indoor, outdoor, and washdown environments. Rated for 5,000,000 operating cycles, it delivers dependable momentary switching performance in commercial and industrial electrical control applications.

Key Features

  • Trade Size: 22.5 mm mounting size for standard M22 RMQ-Titan panel cutouts.
  • Product Height: 1 in, suited for compact control panel and enclosure layouts.
  • Flush Mounting: Flush mount design provides a low-profile, panel-integrated actuator face.
  • Momentary Operation: Momentary actuator function returns to normal position when released, ideal for start/stop and jog controls.
  • Contact Configuration: 1 NC contact arrangement for reliable normally-closed circuit control.
  • Non-Illuminated Actuator: Red non-illuminated pushbutton actuator for clear visual identification without a lamp module.
  • Environmental Protection: IP67 and IP69K ingress protection combined with NEMA 4X and NEMA 13 ratings for wet, dusty, and washdown-capable installations.
  • Operating Life: Rated for 5,000,000 operating cycles for long-term reliability in high-cycle control applications.

Certifications & Compliance

  • CSA Certified
  • IP67 Rated
  • IP69K Rated
  • NEMA 4X
  • NEMA 13

Technical Specifications

  • Series: M22
  • Department: Electrical
  • Mounting Method: Flush
  • Size: 22.5 mm
  • Product Height: 1 in
  • Type: Pushbutton
  • Degree of Protection: NEMA 13
  • Operating Mode: Momentary
  • Operating Cycles: 5 million
  • Contact Configuration: 1 NC
  • Illumination: Non-illuminated
  • Actuator Function: Momentary
  • Product Category: Flush pushbutton
  • Environmental Rating: IP67, IP69K, NEMA 4X, NEMA 13

Typical Applications

  • Industrial Machine Control Panels
  • HMI Operator Stations
  • Momentary Start/Stop and Jog Control Circuits
  • Panelboard and Control Panel Wiring
  • Washdown and Wet-Location Installations
  • Outdoor and Harsh-Environment Equipment

Why Eaton?

Eaton's M22 RMQ-Titan pushbutton line is CSA Certified and built to withstand demanding conditions, backed by IP67 and IP69K ingress protection alongside NEMA 4X and NEMA 13 ratings for wet, dusty, and washdown environments. With a 5,000,000 operating cycle rating, this flush-mount pushbutton delivers the long-term, code-compliant reliability professionals expect for industrial and commercial control panel installations.

Manufacturer Resources

Product Specs

Mounting Method:
Flush
Product Size:
22.5 mm
Product Height:
1 in
Degree of protection:
NEMA 13
Operating mode:
Momentary
Operating cycles:
5 million
Contact configuration:
1 NC
Certifications:
CSA Certified
Illumination:
Non-illuminated
Actuator function:
Momentary
Product category:
Flush pushbutton
Series:
M22
Environmental rating:
IP67, IP69K, NEMA 4X, NEMA 13
Configuration:
Flush Mount
Department:
Electrical
Product Color:
Red
Listing:
CSA Certified
Standards:
NEMA 4X
Product Group:
Motor Control & Automation
Product Type:
Pushbutton
Product Subgroup:
Push Buttons & Pilot Devices

Eaton M22S-D-B – Frequently Asked Questions

1) What panel cutout does the Eaton M22 flush pushbutton need?
It mounts in the standard 22.5 mm M22 RMQ-Titan cutout, so it drops into any panel already drilled for 22.5 mm operator devices. The flush actuator sits low against the panel face, and overall product height is 1 in behind/through the panel, which matters when you are stacking devices in a shallow enclosure.
2) Is the Eaton M22 red pushbutton normally open or normally closed?
It ships with a 1 NC contact block, normally closed. That suits stop, interlock and other fail-to-open circuits where opening the circuit is what stops the machine. If you need a start contact, you need an NO contact block instead, not this configuration.
3) Does the red M22 pushbutton stay pressed in or spring back?
Momentary action, so the red actuator returns to its normal position as soon as you let go. It is not a maintained or latching button, and it is not a twist-release mushroom E-stop. For an E-stop function you need a maintained, turn-to-release device.
4) Can this Eaton pushbutton be used on washdown equipment or outdoors?
Yes. The M22 RMQ-Titan flush pushbutton carries IP67 and IP69K ingress protection plus NEMA 4X and NEMA 13 ratings, which covers high-pressure, high-temperature washdown, wet and dusty areas, and corrosion-prone outdoor enclosures. Sealing is only as good as the panel cutout and gasket seating, so mount it square in a clean 22.5 mm hole.
5) Does the red M22 button light up?
No lamp in it. The red actuator is non-illuminated, so there is no LED module to specify, wire, or match to a control voltage. The red color is there for identification only. If you want an indicating button, you need an illuminated M22 actuator with a separate lamp element.
6) What is the difference between the M22-D-R-K01 and the M22S-D-B versions of this red pushbutton?
Bezel finish. M22-D-R-K01 comes with the silver (chrome) front ring, M22S-D-B with the black plastic bezel. Both are the same 22.5 mm flush red momentary device. Pick whichever matches the other operators already on the panel door, since mixing silver and black bezels on one station is the usual complaint after the fact.
7) Is this Eaton pushbutton approved for Canadian installations?
The M22 flush pushbutton is CSA Certified, so it satisfies the third-party certification an AHJ looks for on control panel components in Canada. That listing appears on the device itself for inspection.
8) Will this red button work in an existing M22 RMQ-Titan operator station?
Yes, it is part of the M22 RMQ-Titan family and uses the same 22.5 mm mounting, so it goes into an existing M22 station in place of another M22 device. Just confirm the circuit you are landing on wants a normally closed contact, since this one is supplied 1 NC.
9) How many cycles is the Eaton M22 pushbutton rated for?
5 million operating cycles, which is why it gets specified on jog and repetitive machine-control duty rather than occasional-use panels. For a station cycled a few hundred times a shift, that is years of service before mechanical wear is a factor.
