Eaton M22 Modular Pushbutton Operator, 22.5 mm, Maintained, Non-Illuminated

Eaton M22 Modular Pushbutton Operator, 22.5 mm, Maintained, Non-Illuminated

(No reviews yet) Write a Review

Model: M22-DRH-Y

In Stock (leaves warehouse same day if ordered before 3pm ET)

$15.84
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton M22 Modular Pushbutton Operator, 22.5 mm, Maintained, Non-Illuminated

The Eaton M22 Modular Pushbutton Operator is a heavy-duty pilot device built for panel-mounted control applications in industrial and commercial equipment. Part of the Eaton M22 modular platform, this 22.5 mm operator features a maintained actuator function and a non-illuminated design, finished with a silver bezel for a clean panel appearance. Rated NEMA 13 for protection against dust, oil, and coolant, and validated for 1,000,000 mechanical operating cycles, this pushbutton operator is engineered for demanding industrial control environments.

Key Features

  • Mounting Size: 22.5 mm mounting dimension compatible with standard M22 series panel cutouts.
  • Modular Construction: Part of the Eaton M22 modular pushbutton platform, allowing operator heads, contact blocks, and legend plates to be assembled to match application requirements.
  • Maintained Operation: Maintained actuator function holds its position until pressed again, suited to on/off control functions.
  • Non-Illuminated Design: Non-illuminated operator head simplifies wiring for applications that do not require indicator lighting.
  • Silver Bezel: Silver bezel finish provides a durable, professional panel appearance.
  • Rated Operating Life: Validated for 1,000,000 mechanical operating cycles for long-term reliability in control panel service.
  • Degree of Protection: Rated NEMA 13 for protection against dust, oil, and non-corrosive coolant in industrial environments.

Certifications & Compliance

  • NEMA 13 Rated

Technical Specifications

  • Actuator color: Red
  • Series: M22
  • Department: Electrical
  • Product Type: Pushbutton Operator

Typical Applications

  • Industrial Control Panels
  • Machine Start/Stop Stations
  • Panel-Mounted Operator Interfaces
  • Manufacturing and Process Control Equipment
  • OEM Equipment Control Panels

Why Eaton?

Eaton is a trusted name in industrial control and pilot devices, and the M22 modular platform is engineered for durability and flexibility across demanding panel applications. With a silver bezel, maintained actuator function, and a 1,000,000 cycle mechanical operating rating, this pushbutton operator delivers dependable, code-compliant performance for professional electrical and industrial control installations.

Manufacturer Resources

Product Specs

Product Size:
22.5 mm
Product Type:
Pushbutton
Degree of protection:
NEMA 13
Actuator color:
Red
Operating mode:
Maintained
Operating cycles:
1 million
Bezel:
Silver
Illumination:
Non-illuminated
Actuator function:
Maintained
Series:
M22
Department:
Electrical
Standards:
NEMA 13
Product Finish:
Silver
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices

Eaton M22-DRH-Y – Frequently Asked Questions

1) Does the Eaton M22 pushbutton come with contact blocks, or do I have to order those separately?
What you are buying here is the operator head only. The M22 is a modular platform: the head, the contact blocks, and the legend plate are separate pieces that assemble together behind the panel. Plan on ordering the normally open and/or normally closed contact blocks you need for your circuit, plus a mounting adapter and legend plate if the application calls for one. Nothing about the head itself determines your contact arrangement.
2) Is this a maintained or momentary pushbutton?
Maintained. The actuator latches in position when pressed and stays there until it is pressed again, which is what you want for an on/off or run/stop selector-style function. If your control scheme needs a spring-return button (a momentary start pulse into a seal-in circuit, for example), this is the wrong actuator function.
3) Will an Eaton M22 pushbutton hold up in a machine shop with coolant and oil spray?
It carries a NEMA 13 degree of protection, which covers dust, oil, and non-corrosive coolant on the panel face. That makes it suitable for machine tool and process equipment enclosures. NEMA 13 is an indoor rating, so it is not the pick for a washdown or outdoor location where you would be specifying a higher enclosure type.
4) Should I pick the extended actuator or the mushroom head on the M22 operator?
Two actuator styles are offered. The extended button sits proud of the bezel for a defined, deliberate press, which suits a routine on/off function on a machine panel. The mushroom head gives a large striking surface that can be hit with a palm or a gloved hand, typical of a stop or shutdown function. Both are maintained and non-illuminated on this operator, so the choice is about how the operator is meant to be actuated, not about the switching behavior. Extended is M22-DRH-Y; mushroom is M22-DRP-R.
5) How many cycles is this M22 operator rated for on a high-use start station?
The mechanical operating life is validated at 1,000,000 cycles. On an operator station pressed a few hundred times a shift, that is years of service before the head becomes the limiting part. Keep in mind the rating is mechanical life for the actuator; electrical life depends on the contact blocks you pair with it and the load they are switching.
6) Do I need to run a separate supply for lamp voltage with this pushbutton?
No. The operator is non-illuminated, so there is no lamp block and no control voltage to land for indication. Wiring is limited to the contact block terminals. If the panel legend calls for a lit button to show state, you would need an illuminated M22 head and the matching LED element instead.
