Eaton CCV Tenant Main Circuit Breaker, Two-Pole, 150A

Eaton CCV Tenant Main Circuit Breaker, Two-Pole, 150A

The Eaton CCV Tenant Main Circuit Breaker is a two-pole, 150 A main breaker rated 25 kAIC at 120/240 V, engineered for tenant metering applications that use Type ECC unit enclosures. This CCV-frame breaker terminates on the load side and accepts #2/0 AWG-300 kcmil copper or aluminum conductors, making it a dependable main disconnect for multi-tenant electrical distribution systems. Backed by UL 489 listing, it delivers the fault-current interruption and code-compliant performance that electrical contractors rely on for tenant panel installations in commercial and light commercial buildings.

Key Features

• Amperage Rating: 150 A main circuit breaker rating suitable for tenant main disconnect applications.
• Interrupt Rating: 25 kAIC short-circuit interrupt rating provides reliable fault-current protection.
• Two-Pole Configuration: Two-pole design rated 120/240 V for standard single-phase tenant electrical services.
• CCV Frame Type: Type CCV circuit breaker frame purpose-built for use with Type ECC unit enclosures.
• Load Side Terminals: Load-side termination simplifies wiring within tenant metering and distribution equipment.
• Wire Range: Accepts #2/0 AWG-300 kcmil Cu/Al conductors using standard lugs (wire connectors) suitable for copper or aluminum wire.
• Compact Footprint: Measures 4.5 in wide x 7.7 in deep x 5.4 in high for a defined fit inside compatible enclosures.

Certifications & Compliance

• UL 489 Listed

Technical Specifications

• Circuit breaker frame type: CCV
• Main circuit breaker: CCV
• Warranty: Limited lifetime residential, 1 year commercial
• Voltage rating: 120/240 V
• Terminals: Load
• Number of poles: Two-pole
• Interrupt rating: 25 kAIC
• Wire size: #2/0 AWG-300 kcmil Cu/Al
• Used with: Type ECC Unit Enclosures
• Product Width: 4.5 in
• Product Length/Depth: 7.7 in
• Product Height: 5.4 in
• Certifications: UL 489

Typical Applications

• Tenant Metering and Sub-Metering Panels
• Multi-Tenant Commercial Electrical Distribution
• Main Disconnect for Type ECC Unit Enclosures
• Residential and Light Commercial Panelboards
• Panelboard and Load Center Wiring Upgrades

Why Eaton?

Eaton's CCV tenant main circuit breaker is built to UL 489 standards and backed by a limited lifetime residential warranty (1 year commercial), reflecting the durability professionals expect from Eaton circuit protection products. With defined load-side termination, a 150 A/25 kAIC rating, and compatibility with Type ECC unit enclosures, this breaker delivers dependable, code-compliant performance for tenant electrical distribution in commercial and light commercial buildings, giving contractors and property managers a trusted main disconnect solution for tenant panel upgrades and new installations alike.
