Advance Electronic Dimmable Ballast for (2) F32T8 Lamps 120V Programmed Start
Professional fluorescent lighting control with electronic dimming capability
The Advance electronic dimmable ballast delivers reliable performance for (2) F32T8 fluorescent lamps with 120V operation and programmed start technology. This metal-housed ballast features electronic dimming capability with high power factor performance and low total harmonic distortion for professional lighting applications requiring precise light level control.
Professional Features & Benefits
- Electronic Dimming Technology: Provides smooth, flicker-free dimming control for enhanced lighting flexibility and energy management in commercial and residential applications.
- Programmed Start Operation: Extends lamp life through controlled cathode preheating, reducing maintenance costs and improving system reliability.
- High Power Factor (0.99): Maximizes electrical efficiency and reduces utility demand charges while minimizing power line interference.
- Low Total Harmonic Distortion (10%): Ensures clean power operation that meets electrical code requirements and reduces interference with sensitive equipment.
- Metal Housing Construction: Provides superior durability and heat dissipation for long-term reliability in demanding environments.
- Multiple Certifications: UL, CSA, NEMA Premium, and RoHS compliance ensures safety and regulatory compliance for professional installations.
- Compact Design: 9.5" x 1.7" x 1.18" dimensions and 1.1 lb weight facilitate easy installation in standard fixture housings.
Technical Specifications
- Ballast Factor: 1
- Country Of Origin: USA
- Efficacy: 1.470588235
- Frequency Rating: 60 Hz
- Housing Material: Metal
- Lamp Type: T8
- Number Of Lamps: 2
- Power Factor: 0.99
- Product Height: 1.1800 IN
- Product Length: 9.5000 IN
- Product Type: Dimmable Fluorescent
- Product Wattage: 32 W
- Product Weight: 1.100 Lbs
- Product Width: 1.7000 IN
- Standard: CSA certificate;UL certificate;CEC Listing;CEE Rated;CSA E;NEMA Premium;NOM certificate;RoHS Compli
- Start Type: PROGRAMMED START
- Total Harmonic Distortion: 10
- Voltage Rating: 120 V
- Wire Gauge: 18 AWG
- Wire Type: Solid
Installation & Operation
- Mount the unit in a suitable location with appropriate clearance and access for connections and service.
- Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
- Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
- Configure any available load management or control features as supported by the provided specifications.
- Test automatic transfer or operational functionality and verify proper performance before placing into service.
- Complete final inspection and follow ongoing maintenance practices appropriate to the product category.
Professional Applications
- Commercial Office Buildings
- Retail Establishments
- Educational Facilities
- Healthcare Facilities
- Hospitality Venues
- Residential Applications
- Industrial Lighting Systems
Why Choose Advance Quality?
Advance ballasts deliver proven reliability with comprehensive certifications including UL, CSA, NEMA Premium, and RoHS compliance. The metal housing construction and programmed start technology ensure long-term durability and performance in professional lighting applications requiring precise dimming control and energy efficiency.
Manufacturer Resources
Product Specs
- Ballast Factor:
- 1
- Country Of Origin:
- USA
- Efficacy:
- 1.470588235
- Frequency Rating:
- 60 Hz
- Housing Material:
- Metal
- Lamp Type:
- T8
- Number Of Lamps:
- 2
- Power Factor:
- 0.99
- Product Height:
- 1.1800 IN
- Product Length:
- 9.5000 IN
- Product Type:
- Dimmable Fluorescent
- Product Wattage:
- 32 W
- Product Weight:
- 1.100 Lbs
- Product Width:
- 1.7000 IN
- Standard:
- CSA certificate;UL certificate;CEC Listing;CEE Rated;CSA E;NEMA Premium;NOM certificate;RoHS Compli
- Start Type:
- PROGRAMMED START
- Total Harmonic Distortion:
- 10
- Voltage Rating:
- 120 V
- Wire Gauge:
- 18 AWG
- Wire Type:
- Solid
