Advance Electronic Dimmable Ballast for (3) F32T8 Lamps 120V Programmed Start

Advance Electronic Dimmable Ballast for (3) F32T8 Lamps 120V Programmed Start

(No reviews yet) Write a Review

Model: REZ3S32SC35I
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$193.54
$190.64
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Advance Electronic Dimmable Ballast for (3) F32T8 Lamps 120V Programmed Start

Professional electronic dimming ballast for versatile fluorescent lighting applications

The Advance Electronic Dimmable Ballast delivers reliable performance for three F32T8 fluorescent lamps with 120V operation and programmed start technology. This metal-housed ballast features high power factor (0.99) and ballast factor (0.97) for efficient operation, with comprehensive certifications including UL, CSA, NEMA Premium, and RoHS compliance for professional installations.

Professional Features & Benefits

  • Electronic Dimming Capability: Provides smooth dimming control for energy savings and lighting flexibility in commercial and residential applications.
  • Programmed Start Technology: Extends lamp life through controlled starting sequence, reducing maintenance costs and lamp replacement frequency.
  • High Power Factor (0.99): Maximizes electrical efficiency and reduces power consumption while meeting utility requirements for commercial installations.
  • NEMA Premium Certification: Ensures superior performance standards and reliability for demanding professional lighting applications.
  • Compact Metal Housing: Durable construction in a space-efficient 9.5" x 1.7" x 1.18" profile for versatile mounting options.
  • Low THD (10%): Minimizes electrical interference and ensures clean power delivery for sensitive electronic environments.
  • Multiple Certifications: UL, CSA, CEC, CEE, and RoHS compliance provides confidence for code-compliant installations.

Technical Specifications

  • Ballast Factor: 0.97
  • Country Of Origin: USA
  • Efficacy: 1.010416667
  • Frequency Rating: 60 Hz
  • Housing Material: Metal
  • Lamp Type: T8
  • Number Of Lamps: 3
  • Power Factor: 0.99
  • Product Height: 1.1800 IN
  • Product Length: 9.5000 IN
  • Product Type: Dimmable Fluorescent
  • Product Wattage: 32 W
  • Product Weight: 1.160 Lbs
  • Product Width: 1.7000 IN
  • Standard: CSA certificate;UL certificate;CEC Listing;CEE Rated;NEMA Premium;RoHS Compliant
  • Start Type: PROGRAMMED START
  • Total Harmonic Distortion: 10
  • Voltage Rating: 120 V
  • Wire Gauge: 18 AWG
  • Wire Type: Solid

Professional Applications

  • Commercial Office Buildings
  • Retail and Hospitality Facilities
  • Educational Institutions
  • Healthcare Facilities
  • Industrial and Warehouse Lighting
  • Residential Multi-Unit Properties
  • Energy-Efficient Retrofit Projects

Why Choose Advance Quality?

Advance ballasts deliver proven reliability with comprehensive certifications including UL, CSA, NEMA Premium, and RoHS compliance. The metal housing construction and programmed start technology ensure long-term durability and performance in demanding professional lighting applications, backed by USA manufacturing quality standards.

Manufacturer Resources

Product Specs

Ballast Factor:
0.97
Country Of Origin:
USA
Efficacy:
1.010416667
Frequency Rating:
60 Hz
Housing Material:
Metal
Lamp Type:
T8
Number Of Lamps:
3
Power Factor:
0.99
Product Height:
1.1800 IN
Product Length:
9.5000 IN
Product Type:
Dimmable Fluorescent
Product Wattage:
32 W
Product Weight:
1.160 Lbs
Product Width:
1.7000 IN
Standard:
CSA certificate;UL certificate;CEC Listing;CEE Rated;NEMA Premium;RoHS Compliant
Start Type:
PROGRAMMED START
Total Harmonic Distortion:
10
Voltage Rating:
120 V
Wire Gauge:
18 AWG
Wire Type:
Solid
Department:
Electrical

Advance REZ3S32SC35I – Frequently Asked Questions

1) Will the Advance REZ3S32SC35I ballast run three F32T8 lamps on a 120V circuit?
That's exactly what it's built for. The REZ3S32SC35I drives three F32T8 lamps at 32 watts each and runs on 120V only, at 60 Hz. It is not a multi-volt ballast, so if the fixture is fed 277V it's the wrong part. Check the voltage at the fixture, not at the panel, before you pull the old one.
2) Can I use the Advance REZ3S32SC35I dimmable ballast to run only two lamps instead of three?
No. It's a three-lamp ballast, and a dimming ballast in particular needs its full lamp complement wired to dim correctly. For a two-lamp fixture, order a two-lamp F32T8 dimming ballast rather than capping a leg on this one.
3) Will the Advance REZ3S32SC35I fit in a standard 4-foot fluorescent strip fixture channel?
The ballast case measures 9.5 x 1.7 x 1.18 inches and weighs 1.16 lbs, so it drops into the wireway of most 4-foot strips and troffers. Measure the existing ballast before ordering: if the fixture was built around a longer case, you'll have new mounting hole locations to deal with, and the shallow 1.18 inch dimension is what decides whether the cover plate still closes.
4) Do I need a separate dimming control wire run for the Advance REZ3S32SC35I, or does it dim on the line voltage?
It's an electronic dimming ballast, so dimming happens over a low voltage control pair, not by chopping the 120V line. A standard incandescent wall dimmer on the hot leg will not dim it and can damage it. Plan for line, neutral, ground, and a separate control run back to the dimmer or lighting control panel.
5) What does programmed start mean on a fluorescent ballast, and do I need it?
Programmed start heats the lamp cathodes before striking the arc, which is what keeps a lamp from being chewed up every time it's switched. It matters most where lights cycle frequently: restrooms, corridors, storage rooms, and anywhere on occupancy sensors. It also matters on a dimming ballast, because a dimmed lamp still needs its cathodes maintained. If the lamps run on a timeclock and stay on all day, instant start is cheaper and does the job; the REZ3S32SC35I is the one to pick when the switching is heavy or the room is on sensors.
6) Is the Advance REZ3S32SC35I UL listed and does it meet NEMA Premium?
It carries a UL certificate and a CSA certificate, is CEC listed and CEE rated, meets NEMA Premium, and is RoHS compliant. That combination is what an inspector and an institutional spec typically want to see on a commercial fluorescent retrofit, and CEE rating is often what a utility asks for on a rebate submittal.
7) Is this ballast clean enough electrically for a hospital or data-sensitive space?
Total harmonic distortion is 10 percent and power factor is 0.99. Under 20 percent THD is the usual ceiling written into commercial and healthcare lighting specs, so 10 percent clears it with margin, and the near-unity power factor keeps the current draw down on branch circuits that are already loaded. Those two numbers together are the ones a facilities engineer asks for before approving a retrofit.
8) Which Advance part number should I order for a three-lamp F32T8 120V dimming ballast?
The part number is REZ3S32SC35I. Order by that MPN; the Advance REZ family runs across lamp counts and voltages, so a digit off in the middle gets you a two-lamp or a 277V unit.
9) What size wire do the leads on this Advance three-lamp T8 ballast take, and will they land in my existing connectors?
The leads are 18 AWG solid. Solid conductor matters for the wire nuts or push-in connectors you're using: push-ins rated for 18 AWG solid will take them directly, and if the fixture's existing leads are stranded you'll want connectors rated for a solid-to-stranded combination.
10) Is the housing metal or plastic, and can I mount it inside an enclosed fixture?
Metal housing. That's the standard case for a fluorescent ballast mounted in the wireway of a strip, troffer, or industrial fixture, where the metal case both grounds and sinks heat into the fixture body. It is a fixture-interior component, not something to mount exposed.
11) Is the Advance REZ3S32SC35I made in the USA?
Yes, country of origin is the USA. That's the answer a government, school district, or federally funded project needs on the submittal when domestic sourcing is a condition of the job.
