Emtek 3106 Manhattan Mortise Entrance Lockset - Dummy

It is a dummy function set, so there is no latch and no key. The knob or lever is fixed and the set is there to give an inactive leaf or a closet door the same look as the working openings. The 3106 Manhattan is non-keyed. If you need an operating latch on a mortise prep, look at a passage mortise lock like the Schlage PM010 instead.

Yes, handing is required on all Emtek mortise locks, and the 3106 is ordered as either left hand or right hand. Stand outside the door: if the hinges are on your left it is left hand. There is no field-reversible option here, so getting the hand right at order time matters.

It takes a standard mortise pocket per ANSI A115.1, with a backset of 2-1/2 or 2-3/4 inches. If the door is already prepped for a standard mortise body, the pocket should carry over; measure from the door edge to the spindle centerline to confirm which backset you have before ordering.

The Emtek 3106 Manhattan is a residential brass dummy mortise set. For a heavy duty commercial specification, the Schlage L0170 is a Grade 1 non-keyed mortise dummy trim in the L Series, rated heavy duty for 1-3/4 inch doors. The Emtek 3106 is chosen for decorative brass trim with a wide range of knob and lever styles, while the L0170 is specified where a BHMA Grade 1 heavy duty product is called for on the drawing.

The Emtek 3106 Manhattan is dummy function, meaning it is surface applied trim with no latch and no key. If the door has to latch, the Schlage PM010 is a Grade 1 non-keyed passage latch mortise lock for 1-3/4 inch doors, and the Hager 3810S is a Grade 1 passage mortise lock with rose and a 2-3/4 inch backset for doors 1-3/4 to 2-1/2 inches thick.

The Emtek 3106 Manhattan is a non-keyed dummy set. For a keyed mortise opening, the Baldwin 6301 is an entry/apartment mortise lock body with a 2-1/2 inch backset for doors 1-3/4 inches and over, available knob by knob or lever by lever, and the Baldwin 6310 is an entry/storeroom mortise lock body with a 2-1/2 inch backset for doors 1-3/8 inches and over. In a commercial spec, the Cal-Royal NM8050 is a Grade 1 office/entrance mortise lockset with auxiliary deadlatch for 1-3/4 inch doors.

Yes, and you have to. The inside trim style is a required selection, drawn from Emtek's brass knobs, crystal and porcelain knobs, and levers. That covers everything from the Ace Knob and Spoke Knob to the Stuttgart, Athena and Milano levers, plus crystal options like Bristol and Windsor. The set ships complete with the trim you choose.

It is classified residential. The brass construction and American Classic styling are aimed at homes and high-end residential work. For a commercial opening that needs a Grade 1 dummy trim, the Schlage L0170 half dummy trim is the heavy duty alternative, and Falcon's MESC600DT is a dummy escutcheon lever trim if the opening has an exit device on it.

That is exactly what it is for. The 3106 Manhattan carries the same Manhattan entrance styling and the same eight Emtek finishes, and you can order it with the same knob or lever from the Emtek trim range, so the closet or inactive leaf reads identically to the working door without a latch behind it.

Complete set. You get the mortise case and the trim on both sides in the finish and knob or lever style you select, so there is nothing else to buy. Compare that to lock bodies sold on their own, like the Baldwin 6301 2-1/2 inch backset mortise body, where the trim is a separate order.

No. The Sargent 130KB is a standard duty mortise thumbturn in the 8200 Series, a single turn piece that operates a lock from the inside. The Emtek 3106 Manhattan is a complete dummy mortise entrance set in brass, sold as a full set and ordered with a knob or lever for the inside trim. They serve different parts of the opening.

Both are dummy function. The Falcon MESC600DT is a dummy escutcheon lever trim made for M9900 Series exit devices and carries a fire rating, so it is the inactive trim side of an exit device opening. The Emtek 3106 Manhattan is a brass mortise entrance dummy set for a standard mortise prep, ordered left or right hand with a choice of knob, crystal or lever inside trim.

The Emtek 3106 Manhattan is dummy function, so it will not hold a door closed or provide privacy. For a bed or bath opening, the Hager 3840S is a Grade 1 privacy mortise lock with a 2-3/4 inch backset for doors 1-3/4 to 2 inches, and the Cal-Royal NM8440 is a Grade 1 privacy mortise lockset with deadbolt for 1-3/4 inch doors.

The Emtek 3106 Manhattan is a residential dummy mortise set with no latch or key, so it does not perform a classroom or dormitory function. For those openings, the Corbin Russwin ML2003 is a Grade 1 mortise classroom lockset for 1-3/4 inch doors, and the Sargent 7925 is a Grade 1 heavy duty corridor/dormitory mortise lock with rose trim and single cylinder deadbolt.

The Emtek 3106 Manhattan requires a standard mortise pocket per ANSI A115.1. If you would rather bore the door than mortise it, the Schlage PC10 is a Grade 1 non-keyed passage cylindrical lock with rose for 1-3/4 inch doors, which uses a cylindrical prep instead of a mortise pocket.

The Emtek 3106 Manhattan is a mechanical, non-electronic dummy set. For electronic access on a mortise prep, the Alarm Lock DL3500CR is a Grade 1 electronic mortise lock with 300 user codes and classroom function for doors 1-5/8 to 1-7/8 inches, the Schlage CO-100 is a Grade 1 heavy duty standalone electronic mortise lock with keypad reader in privacy function for 1-3/4 inch doors, and the TownSteel FME-2000 is a Grade 1 heavy duty classroom mortise lockset with RFID for 1-3/4 inch doors.

The Emtek 3106 Manhattan is a dummy entrance set with no bolt. For a mortise deadbolt, the Sargent 4874 is a double cylinder mortise deadbolt with a 2-3/4 inch backset, and the Kaba Ilco 185 Series is a mortise deadbolt that requires no handing.

Yes. Handing is required on the Emtek 3106 Manhattan and it is ordered left hand or right hand. Baldwin also hands its mortise bodies, with the 6310190RRLS specified as right hand reverse for entry/storeroom on doors 1-3/8 inches and over. If you want to avoid handing entirely, the Kaba Ilco 185 Series mortise lock is listed as no handing.

The Emtek 3106 Manhattan is a decorative brass residential dummy set and is not an anti-ligature product. For those openings, the TownSteel MRX-L-01 is a Grade 1 heavy duty stainless steel anti-ligature lever mortise lockset in passage function for 1-3/4 inch doors, the MRX-A-01 is the ligature resistant arch trim version, and the Marks USA 5PDN is a Grade 1 ligature resistant, ADA compliant hospital passage mortise push/pull paddleset in satin stainless steel.

The Cal-Royal NM8080 is a Grade 1 heavy duty storeroom mortise lockset for 1-3/4 inch doors with an interchangeable core option, which suits keyed storeroom openings on a master key system. The Emtek 3106 Manhattan is a non-keyed dummy set in brass, used on inactive or pull-only leaves where decorative trim is wanted. The Accentra 8805FL is another Grade 1 storeroom mortise lock, furnished with the Arcadia lever in the 8800 Series.

Eight finishes: Oil Rubbed Bronze (US10B), Satin Nickel (US15), Pewter (US15A), Flat Black (US19), Polished Chrome (US26), Polished Brass Lifetime (US3), Unlacquered Brass (US3NL), and French Antique (US7). Each is offered in both left and right hand. Unlacquered brass will patina over time, so pick it only if you want the aged look or plan to maintain it.

The BEST 45H is a heavy duty mortise lock body in public entrance function with field reversible operation, and the 45HCA is a heavy duty body with intruder function. Those are lock bodies for commercial chassis work. The Emtek 3106 Manhattan is a complete brass dummy mortise entrance set sold as a set with the inside knob or lever selected at order, for a standard mortise prep with 2-1/2 or 2-3/4 inch backset.
