Emtek 3134 Hailey Mortise Entrance Lockset - Dummy

The 3134 Hailey is the dummy version, so it does not latch and has no key cylinder. It is non-keyed hardware that mounts fixed to the door and gives you a handle to pull on. Use it on the inactive leaf of a double door, on a closet or pantry door that stays shut with a catch, or wherever you want the look to match a working set. If you need the operating version of the same Hailey design, that is the 3534 entryset.

Yes, handing is required on all Emtek mortise sets including the 3134 Hailey, and it is ordered as left hand or right hand for an in-swing door. Stand outside the door: if the hinges are on your left it is left hand, hinges on the right is right hand. Get it wrong and the trim orientation will not sit correctly on the door.

It takes a standard mortise pocket cut to ANSI A115.1, the same prep used for commercial mortise locks. If your door is already mortised to A115.1 and the backset matches, the Hailey set goes in without recutting the pocket. Backset is ordered as 2-1/2 inch or 2-3/4 inch, so measure from the door edge to the center of the existing cylinder or spindle hole before you pick.

1-3/4 inch is the standard build for the 3134 Hailey, which covers most exterior and commercial-weight doors. Thicker doors are handled, but the thickness has to be called out when the order is placed so the set is built to it. There is a door thickness field on the order for exactly that.

The Emtek 3134 Hailey is a residential brass dummy mortise set, so on a commercial opening where a Grade 1 dummy trim is specified, the Schlage L0170 is the direct counterpart. It is a Grade 1 heavy duty non-keyed mortise half dummy lever trim in the L Series, rated for 1-3/4 inch doors. Both are non-operating dummy trim, but the Emtek is a full residential set in brass with sandcast knob, crystal, porcelain or lever options, while the L0170 is a commercial lever trim.

The 3134 Hailey is dummy function only, meaning the trim is fixed and there is no latch or bolt behind it. For an opening that must latch and lock, the matching keyed version in the same Hailey styling is the 3534 entryset, which shares the 2-1/2 or 2-3/4 inch backset, standard ANSI A115.1 mortise prep, Schlage C keyway and UL 180 minute fire rating. If the door is commercial rather than residential, a Grade 1 entrance lockset such as the Cal-Royal NM8050 office/entrance mortise lockset with auxiliary deadlatch covers the same duty on a 1-3/4 inch door.

No. The Emtek 3134 Hailey is dummy function, so the handle does not turn and nothing retracts - it mounts on a door held closed by a ball catch or roller catch, or on the inactive leaf of a pair. A passage mortise lock such as the Schlage PM010 Grade 1 non-keyed passage latch or the Falcon MA101 Grade 1 heavy duty passage lock has a working latch that the lever retracts. If the door needs to stay shut on its own, order passage, not the 3134.

Yes. The inside trim is chosen at order time from 25 styles: Aurora, Bryce, Cimarron, Cody, Durango, Lariat, Mariposa, Montrose, Teton and Yuma levers, plus Butte, Egg, Round, Winchester, Bristol, Hampton, Lowell, Windsor, Astoria, Diamond, Georgetown, Modern Disc, Modern Square, Old Town and Providence knobs. Sandcast bronze knobs, crystal and porcelain, or levers can all be paired with this set, and it ships as a complete set rather than trim-only pieces.

Three finishes: Flat Black Bronze (FB), Medium Bronze (MB) and Tumbled White Bronze (TWB). These are living bronze finishes on solid brass, so they will patina over time on exterior openings. If you are matching across a house or a building, order the dummy in the same finish code as the working sets and specify the same trim style.

Same Hailey design, different function. 3134 is the dummy: fixed, no latch, no cylinder. 3534 is the entryset that actually operates and locks. Pairs of doors are the usual case for buying both, one working set on the active leaf and a dummy on the inactive leaf so the two openings look identical.

The Emtek 3134 Hailey will not work for you, since it is a dummy with no latch at all. For a non-keyed mortise that still latches, the Schlage PM010 passage mortise lock and the Hager 3810S passage mortise are both options, and the Hager 3810S carries a 2-3/4 inch backset with a 1-3/4 to 2-1/2 inch door thickness range. If the door needs privacy rather than plain passage, the Hager 3840S is the privacy version.

Baldwin's 6301 mortise lock body is the nearest decorative-residential counterpart, offered as knob by knob or lever by lever with a 2-1/2 inch backset for doors 1-3/4 inch and over. The Emtek 3134 Hailey also uses a 2-1/2 inch backset option, though it is dummy function only while the Baldwin 6301 is entrance/apartment function with a working latch. Baldwin also lists the 6310 in entrance/storeroom function with a 2-1/2 inch backset for doors 1-3/8 inch and over.

The Emtek 3134 Hailey is built as residential brass hardware in dummy function, so it does not provide the latching, security or cycle duty an institutional opening needs. For classroom and office doors, Grade 1 mortise locksets such as the Corbin Russwin ML2003 classroom lockset, the Cal-Royal NM8070 classroom lockset with auxiliary deadlatch, or the Hager 3850E office mortise lock with lever and escutcheon on a 2-3/4 inch backset are the functional match. The Emtek is appropriate on non-latching leaves and closet or pantry doors within a residential-style project.

Yes - handing is required on the Emtek 3134 Hailey and every Emtek mortise lock, so it must be ordered left hand or right hand for an in-swing door. That differs from mortise products built field reversible, such as the BEST 45H public entrance lock body or the Falcon MA101 passage lock, both of which list field reversible operation, and from the Kaba Ilco 185 Series mortise locks, which are supplied with no handing. If you are unsure of the swing at order time, those are the products that tolerate it; the 3134 is not.

The Emtek 3134 Hailey is a non-electronic, non-keyed dummy set, so it offers no access control at all. For electronic mortise access on the same door prep, options include the Dormakaba E-Plex 2066 electronic pushbutton keyless mortise lock, the Alarm Lock DL3500CR Trilogy Grade 1 classroom lock with 300 user codes for doors 1-5/8 to 1-7/8 inch, and the Schlage CO-100 standalone electronic mortise lock in privacy function with keypad reader for 1-3/4 inch doors. These are commercial-grade products rather than decorative brass residential trim.

The Emtek 3134 Hailey uses standard mortise prep to ANSI A115.1 with a 2-1/2 or 2-3/4 inch backset, so a door bored for a cylindrical lock will not accept it without re-prep. If re-prepping is not practical, a cylindrical product such as the Schlage PC10 Grade 1 non-keyed passage lock with rose fits a bored door on 1-3/4 inch thickness. Keep the mortise route only if the pocket already exists or the door is being prepped new.

Both are dummy function, but they are not interchangeable. The Falcon MESC600DT is dummy escutcheon lever trim made for M9900 Series exit devices, so it mounts to an exit device opening. The Emtek 3134 Hailey is a complete brass dummy mortise set that installs in a standard ANSI A115.1 mortise pocket with a 2-1/2 or 2-3/4 inch backset and is ordered with a sandcast bronze knob, crystal, porcelain or lever. Choose the Falcon only where an exit device is present.

The Emtek 3134 Hailey is dummy function and offers no privacy locking. For a privacy mortise application, the Cal-Royal NM8440 is a Grade 1 privacy mortise lockset with deadbolt for 1-3/4 inch doors, and the Hager 3840S is a Grade 1 privacy mortise lock with a 2-3/4 inch backset for doors 1-3/4 to 2 inches. Both provide the inside thumbturn action the 3134 does not.

It is entirely mechanical and non-electronic, with no cylinder and no keying. If access control is what you are after on that opening, that is a different product entirely, such as the Dormakaba E-Plex 2066 pushbutton mortise lock or the Schlage CO-100 standalone electronic mortise lock.
