Emtek 8113 Modern 9" Non-Keyed Sideplate Lockset, Passage - Brass Tubular

Yes. The 8113 uses one standard 2-1/8 inch cross bore, so it drops onto a door already prepped for a normal bored knob or lever set. The latch backset is adjustable between 2-3/8 and 2-3/4 inches, and it works on doors 1-3/8 to 1-3/4 inches thick, which covers both older interior doors and modern 1-3/4 inch doors. The 9 inch sideplate covers the face of the door around that bore.

It never locks. Passage function means both sides always retract the latch, no key and no thumbturn, so it is for hall, closet and pantry doors where you only want the door to stay shut. The 8113 is non-keyed and has no cylinder. If you need privacy on a bath or bedroom, you want the privacy version with a thumbturn instead, and if you need a key you need a keyed sideplate set.

Handing is required, right hand or left hand, and it matters for leversets in particular because the lever has to point toward the hinge side when the door is closed. Stand outside the door (the side it swings away from): hinges on the right is right hand. Get it wrong on a lever and the handle points the wrong way.

Measure from the door edge to the center of the 2-1/8 inch bore. If that is 2-3/8 inches you are on the residential standard and the standard latch ships that way; if it is 2-3/4 inches you have to specify it, since that is the commercial-style backset and it is a separate selection on the order. The 8113 covers both, but the latch is not field-swappable between them once shipped.

No. The 8113 is a passage set, so it has no lock at all. For a sideplate design with a working deadbolt, look at the Omnia D12036A single cylinder deadbolt lever lockset, or the D12036AC if you need a double cylinder with a key both sides (common on doors with glass nearby). If the door is a false or inactive leaf and you only want matching hardware that does not operate, the Omnia D12036PD is the double dummy version with a 5-1/2 inch center to center.

The Emtek 8113 is a non-keyed passage lockset, so it latches and releases from either side with no locking at all - wrong choice for an entry opening. For a keyed sideplate lever set, the Omnia D12036A is a single cylinder deadbolt lever lockset in solid brass, keyed from the outside. If the opening needs a key on both faces, the Omnia D12036AC is the double cylinder version of the same solid brass sideplate design.

The Emtek 8113 is a working passage set that includes a latch and strike plate, so it needs a bored door prep and a latch bore. On a door that only needs a pull with no latch mechanism, the Omnia D12036PD is a solid brass dummy deadbolt lever lockset with plates, spaced 5-1/2 inches center to center, and functions as a double dummy - trim on both faces with nothing operating.

Sold as a complete set: the knob or lever you pick, the latch, and the strike plate. You choose the interior trim style separately, and the same style repeats on the exterior of a passage set. Nothing else is needed to trim out a door that already has the 2-1/8 inch bore and a 1 inch edge bore for the latch.

Yes, that is the normal way these get specified. The 8113 comes in six finishes, Oil Rubbed Bronze (US10B), Satin Nickel (US15), Flat Black (US19), Polished Chrome (US26), Unlacquered Brass (US3NL) and Satin Brass (US4), and the trim can be ordered in any of Emtek's brass knob or lever styles. So you can run the same lever and finish on the passage doors, privacy doors and entry doors and have the hardware read as one set.

The 8113 is a residential lockset with a tubular latch and a brass body. It suits houses, condo interiors and light-duty unit doors. For a commercial corridor, a stairwell, or anything on a fire-rated opening or a code-driven traffic count, you want a cylindrical or mortise commercial lock, not this one.

A sideplate set puts the knob or lever on a long vertical plate instead of a small round or square rosette. On the 8113 that plate is 9 inches, which covers more of the door face, hides old rosette marks from a previous set, and gives a contemporary vertical line. Mechanically it is the same tubular bored latch as a rosette set, using the same 2-1/8 inch bore, so it is purely a trim decision.

Only if the door does not need to latch. A dummy set like the Omnia D12036PD is a surface-mounted double dummy with no latch and no bore, used on inactive leaves of a pair or on closet doors held by a ball catch. The 8113 has a working tubular latch and strike, so it is what you want on any door that has to stay closed on its own.

Yes. The latch is available with either a round corner or a square corner faceplate, so it can drop into the existing routed pocket in the door edge without recutting. Check what is in the door now: a rounded end means a router-cut pocket, a square end means it was chiseled.

They are not the same function. The Emtek 8113 is a non-keyed tubular passage lockset in brass, 9 inch sideplate, with adjustable 2-3/8 inch or 2-3/4 inch backset and a 2-1/8 inch cross bore. The Omnia D12036A is a single cylinder deadbolt lever lockset in solid brass, so it carries a keyed cylinder the 8113 does not have. Swapping one for the other changes how the door secures, and the deadbolt bore requirement is a separate prep from the 8113 passage prep.

Between the two keyed Omnia sideplate sets, the D12036A is single cylinder - keyed outside, thumbturn inside - while the D12036AC is double cylinder, requiring a key from both faces. The Emtek 8113 sits outside that decision entirely: it is a passage function with no keying at all, which is the set used on interior unit doors, not on the entry. Many jurisdictions restrict double cylinder hardware on a required egress door, so confirm the D12036AC against local code before specifying it.

Both are solid brass sideplate lever hardware, so the material and the plate-style silhouette carry across the openings. The Emtek 8113 is the residential-rated passage set for interior doors, ordered in Oil Rubbed Bronze US10B, Satin Nickel US15, Flat Black US19, Polished Chrome US26, Unlacquered Brass US3NL, or Satin Brass US4. The Omnia D12036A and D12036AC are solid brass sideplate lever locksets carrying single and double cylinder functions for the keyed openings. Lever styles and finish tones differ between the two manufacturers, so match samples before committing a full building.
