Emtek Classic Pocket Door Mortise Locks (2-1/2" x 7-1/2")

Minimum door thickness is 1-3/8 inches, and the actual thickness has to be specified on the order for every function, keyed, passage, privacy, and dummy alike. The lock body and spindle length are set to the door, so ordering without a thickness stalls the order. Measure the slab itself, not the jamb, and give that number in the Door Thickness field.

Backset is 2-1/8 inches, measured from the door edge to the center of the trim. The trim plates measure 2-1/2 by 7-1/2 inches and are 1/8 inch thick, so the mortise pocket has to be routed to suit a 2-1/8 inch backset with a 2-1/2 by 7-1/2 inch face cutout. If your existing pocket door was prepped for a 2-3/8 inch backset unit, this will not drop straight into that prep.

Four functions are offered on the Emtek Classic pocket door mortise lock. Keyed takes a key from one side, for an office, storage room or anywhere you want the pocket door locked to outsiders. Privacy locks from inside only, which is the usual pick for a bath or bedroom pocket door. Passage has no lock at all, just latch and pull, for closets and hallway openings. Dummy has no latch and no working mechanism, it is trim and a pull only, used where the door does not need to catch or where a second leaf just needs matching hardware.

Emtek pocket door mortise locks can be keyed alike to each other, so a run of keyed pocket doors in one house or suite can share a single key. They may not key alike with other Emtek products, so do not plan on the same key operating your Emtek entry handleset or passage locks. Keying is chosen at order time: keyed different or keyed alike, with an optional key code field if you are matching an existing system.

Unlikely without patching. The Emtek Classic trim is 2-1/2 by 7-1/2 inches, a tall plate, while common replacements like the Deltana SDL25 privacy lock are 2-1/2 by 2-3/4 inches and the Deltana SDLA325 heavy-duty adjustable is 3-1/4 by 2-1/4 inches. Going from one of those small faces to the 7-1/2 inch Emtek plate means a longer mortise in the door edge, and the Emtek is fixed at a 2-1/8 inch backset where the SDLA325 is adjustable. If you want to stay in the existing prep, a same-size replacement is the safer path.

The Omnia 7035/A is the nearest keyed equivalent. Both are solid brass keyed entry pocket door locks: the Emtek Classic pocket door mortise lock is offered in a Keyed function with a brass body and brass trim, and the Omnia 7035/A is a keyed entry pocket door lock with modern rectangular trim and solid brass construction. The difference is the look. Emtek Classic trim is American Classic styling on a 2-1/2 inch by 7-1/2 inch plate, while the Omnia trim is a modern rectangle. If the door needs a key and the room reads traditional, the Emtek stays; if it reads contemporary, the 7035/A covers the same function.

Yes. A privacy-only pocket door lock does that job without a mortise body. The Rockwood 891 is a pocket door privacy latch, and the Deltana SDL25 is a privacy pocket door lock on a 2-1/2 inch by 2-3/4 inch plate. Orca Hardware offers the same privacy function in two trim shapes, the PDLRD round and the PDLSQ square. All four are privacy/bed/bath function only, with no key. The Emtek Classic pocket door mortise lock is a mortise lock sold as a complete set with screws and strikeplate, and it also comes in a Privacy function if you want the larger 2-1/2 inch by 7-1/2 inch trim and brass construction on the bath door.

The Emtek Classic pocket door mortise lock has a minimum door thickness of 1-3/8 inch, so a thinner slab needs a different lock. The Pamex PF1 square style sliding door lock and the Pamex PF2 round sliding door lock both cover a door thickness range of 1-5/16 inch to 1-9/16 inch, which reaches below 1-3/8 inch. Pick PF1 for square trim or PF2 for round; the PF2 uses a 2-3/8 inch backset, against 2-1/8 inch on the Emtek.

The Emtek Classic pocket door mortise lock is a fixed 2-1/8 inch backset, so an existing pocket cut to something else will not line up. Three peers adjust. The Weslock 0577 is a rectangular privacy pocket door lock with an adjustable backset and full lip strike, the Weslock 0627 is the round passage version with the same adjustable backset and full lip strike, and the Deltana SDLA325 is a heavy-duty adjustable pocket door lock on a 3-1/4 inch by 2-1/4 inch plate in privacy function. Adjustable backset lets the lock meet the existing mortise instead of recutting the door.

Five finishes across every function: Oil Rubbed Bronze (US10B), Satin Nickel (US15), Polished Chrome (US26), Polished Brass Lifetime (US3), and Unlacquered Brass (US3NL). A split finish can be requested at order time if the two rooms the door divides call for different metals, one finish on each face. Unlacquered brass is the one that will patina over time rather than hold its shine, so it is the pick when you want the finish to age.

The Emtek Classic pocket door mortise lock is residential hardware in solid brass, aimed at homes and finished residential interiors, not commercial traffic. For a bathroom pocket door in an apartment or a hospitality room, the privacy function works and the brass trim holds up in a finished setting. For an institutional or high-traffic opening, look instead at the Rockwood 891 pocket door privacy latch or the Orca Hardware PDLRD round or PDLSQ square privacy locks, which are plainer commercial-style trims.

The Emtek Classic mortise lock is ordered to a specified door thickness, one number per lock, from a 1-3/8 inch minimum. That is fine when you know each slab, but it means a mixed fleet needs the thickness recorded door by door. If you would rather stock one part that covers a spread, the Weslock 0527 rectangular passage and 0577 rectangular privacy pocket door locks are listed for 1-3/8 to 2 inch doors, and the 0577 has an adjustable backset and a full lip strike.

The Emtek Classic is offered in a privacy function, but an outside emergency release is not part of what is documented on it. If an emergency release is a requirement, the Omnia 7012/L modern rectangular pocket door lock is a privacy function unit with emergency release. That matters most on a bathroom or a child's room where you need to get in from the hall.

A dummy set has no latch and no moving mechanism, just the trim and pull, so the door is stopped and held some other way. A passage set has a working latch and pull with no locking. On a pair of pocket doors meeting in the middle, dummy trim is the usual pick for the leaves that do not need to catch. Emtek offers both functions in the Classic pocket door line across all five finishes; Omnia's 7012/PD is sold specifically as a pair dummy set with a mortise edge pull, and the 7012/N is the passage version with the edge pull.

No. Those are the opening, not the lock. The Orca Hardware PK1200 is a pocket door frame kit for 1 inch or 1-3/4 inch doors, and the NGP SLAL250PD72 is a 72 inch aluminum pocket door track rated up to 250 pounds. Both build or hang the pocket door. The Emtek Classic pocket door mortise lock is the mortise lock and trim that latches it, sold as a complete set with screws and strikeplate. On a new pocket door you may need one of each; neither substitutes for the other.

The Weslock 0527 rectangular passage pocket door lock and the Weslock 0577 rectangular privacy pocket door lock both carry a door thickness range of 1-3/8 inch to 2 inch. The Emtek Classic pocket door mortise lock starts at the same 1-3/8 inch minimum and the actual door thickness is specified at the time of order for every function. If a run of doors mixes thicknesses in that band, all three handle it; choose Emtek where the door also needs a keyed or dummy function, since the Weslock pair is passage and privacy only.

The Emtek Classic pocket door mortise lock does all four in one trim: Keyed, Passage, Privacy and Dummy, each in Oil Rubbed Bronze, Satin Nickel, Polished Chrome, Polished Brass and Unlacquered Brass, so a whole house reads the same. Omnia covers the same spread across four separate models, the 7012/N passage with mortise edge pull, the 7012/L privacy with emergency release, the 7012/PD pair dummy set, and the 7035/A keyed entry, all on modern rectangular trim. Deltana splits it across the SDL25 privacy and SDP25 passage. Emtek pocket door mortise locks can also be keyed alike with each other.

For a bath or bedroom pocket door, an outside release matters. The Omnia 7012/L is a privacy pocket door lock with emergency release built in. The Emtek Classic pocket door mortise lock is offered in a Privacy function on the same 2-1/2 inch by 7-1/2 inch brass trim, in five finishes. If the release feature is what decides the job, the 7012/L states it; if the finish match to the rest of the brass hardware decides it, the Emtek Privacy carries the American Classic trim.

Brass, both the material and the substrate, part of Emtek's Brass collection in the American Classic style. That is what makes the unlacquered brass option behave the way it does, the patina develops on the metal itself rather than sitting on a coating. It also means the trim can be expected to take the finish evenly across a run of doors, which is what matters when you are matching several openings in the same hallway.

Trim size and function range. The Deltana SDL60 is a decorative 6 inch pocket door lock in privacy/bed/bath function only. The Emtek Classic pocket door mortise lock uses a 2-1/2 inch by 7-1/2 inch brass trim plate 1/8 inch thick, with a 2-1/8 inch backset, and covers Keyed, Passage, Privacy and Dummy. If a taller plate suits the door stile and the door only needs privacy, the SDL60 fits; if the same trim has to repeat across locking and non-locking doors, the Emtek family does that.

Three passage options and one dummy. The Weslock 0527 is a rectangular passage pocket door lock with no locking, the Weslock 0627 is the round passage version, the Deltana SDP25 is passage on a 2-1/2 inch by 2-3/4 inch plate, and the Omnia 7012/N is a passage lock with a mortise edge pull. The Emtek Classic pocket door mortise lock also comes in Passage and in Dummy, in the same five finishes as its keyed and privacy functions, if the closet door has to match the locking doors around it.
