Emtek Emtek Designer Brass Leverset - Elan Lever, Passage Set EMTEK-DESIGNER-LEVERSETS-ELAN-PASSAGE

Emtek Designer Brass Leverset - Elan Lever, Passage Set

(No reviews yet) Write a Review

Model: 8100.EN.RH.US15
From the Brass Collection
$240.00
$196.36
Selected Latch is
Selected Rosette is
Selected Handing is
Selected Finish is
Selected Backset is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$240.00
$196.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Emtek Designer Brass Leverset - Elan Lever, Passage Set

  • Can be ordered with any Brass rosette
  • Sold as complete set. Includes Latch and Strike Plate
  • 28 Degree Latch (included when CF Mechanism is selected)

- Fits any door between 1-3/8” to 2-1/4" thick with a 2-1/8" bore standard door prep*
- Standard latch is for 2-3/8" backset. Specify 2-3/4" backset if required


* STRETTO rosette requires a 1-1/4” diameter bore hole and 2-hole door preparation for thumbturn privacy




Specifications:

  • Backset: Adjustable 2-3/8" or 2-3/4"
  • Cross Bore: 2-1/8"
  • Door Thickness: 1-3/8" to 1-3/4"
  • Latch Faceplate: Round or Square Corner
  • Material: Brass

Product Specs

Subcategory:
Leversets
Collection:
Brass
Product Type:
Leversets
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Commercial/Residential:
Residential
Handle Type:
Lever
Lock Type:
Tubular
Series:
Elan
Theme:
American Designer
Electronic:
No
Keyed Function:
Non-Keyed
Keyed:
No
Lock Function:
Passage
Product Attribute:
Cylindrical Locks
MAP Policy:
Yes
Product Function:
Passage/Hall/Closet
Product Style:
American Designer
Product Material:
Brass
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Emtek 8100.EN.RH.US15 – Frequently Asked Questions

1) Will the Emtek Elan passage leverset fit a standard 1-3/4 inch door with a 2-1/8 inch bore?
Yes. The Elan passage leverset drops into a standard 2-1/8 inch cross bore and covers doors from 1-3/8 inch up to 1-3/4 inch thick, which takes in both the common older interior door and standard door prep. The one exception to watch: order it with a STRETTO rosette and the prep changes to a 1-1/4 inch diameter bore with a two-hole preparation. If your doors are already bored 2-1/8 inch, stay away from that rosette option.
2) Do I need to specify a backset when ordering an Emtek Elan lever, and what happens if I get it wrong?
Backset is a required choice on the Elan passage set, 2-3/8 inch or 2-3/4 inch. The standard latch ships 2-3/8 inch, so if your doors are bored at 2-3/4 inch (common on wider commercial-width stiles) you have to call that out on the order. Measure from the door edge to the center of the bore hole before you order. Get it wrong and the latch will not reach the bore.
3) Does a passage function lever lock, or does it just latch?
Passage function means no lock at all. The Elan lever latches the door closed and both levers always retract the latch, with no key and no thumbturn anywhere on the set. It is the correct choice for a hallway, closet, or pantry door. For a bedroom or bathroom you want the privacy version with a thumbturn, and for anything that needs a key you want an entry or keyed function set instead.
4) Is the Emtek Elan lever handed, and how do I tell left hand from right hand?
Handing matters here. The Elan is ordered Left Hand or Right Hand, not reversible in the box. Stand on the outside of the door (the side you push from, the side the hinges are not visible on): if the hinges are on your left it is a left hand door, hinges on your right is right hand. Order to match, because a lever pointing the wrong way is not fixable on site.
5) Is the Emtek Elan leverset suitable for a commercial corridor or office building?
No. The Elan brass leverset is a residential tubular lockset, and it carries no commercial duty grade. For an office, school, or a multi-family common area you want a Grade 1 or Grade 2 cylindrical passage lock instead: the Falcon K101 is a Grade 1 heavy duty passage lever, the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage lever, and the Accentra 5301LN Augusta is a Grade 2 passage lever. Keep the Elan for residential interiors and model-unit finish work.
6) My doors are 2 inches thick. Will the Emtek Elan passage lever work?
Not from the standard spec. The Elan passage set is specified for 1-3/8 inch to 1-3/4 inch doors. For a 2 inch door, look at the Falcon K101 passage lever, rated 1-3/8 inch to 2-1/4 inch, or the Hager 2510 passage lever at 1-3/8 inch to 2 inch. Both are commercial cylindrical locks rather than residential brass trim, so the look changes, but they will actually fit the leaf.
7) What is the closest commercial-grade equivalent to the Emtek Elan passage leverset for a hall or closet door?
The Emtek Elan passage leverset is a non-keyed passage lever in brass, classified residential. For the same passage function in a commercial-rated lever, the Falcon K101 is a Grade 1 passage cylindrical lock with non-handed levers and a 1-3/8 inch to 2-1/4 inch door thickness range, and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet lever with a fire rating and a 1-3/4 inch to 2 inch door thickness range. Both latch and release the same way the Elan does; the difference is duty rating and material, not what the lever does.
8) What do I use on an entry or office door where the Emtek Elan passage lever will not work?
The Elan passage set is non-keyed, so it cannot take a key on an exterior or office door. For a keyed lever, the Dexter C1000 is a Grade 1 entry/office clutching cylindrical lever for 1-3/8 to 1-3/4 inch doors, the Hager 2525 is a Grade 2 commercial cylindrical entry lock with lever handle for 1-3/8 to 2 inch doors, and the Cal-Royal AG00 is a Grade 2 entrance lever with a 6-pin Schlage C keyway keyed different at 2-3/8 inch backset. In the decorative lines, Deltana offers the Manchester 6201 and Linstead 6431 lever entry sets for 1-3/8 to 2 inch doors.
9) Is a dummy lever the same as the Emtek Elan passage set?
No. The Elan passage set is a working latch - it includes the latch and strike plate and the lever retracts the bolt. A dummy lever is surface-mounted trim with no latch behind it, used on a fixed or inactive leaf. Baldwin Estate 5103 is offered as a left hand and a right hand half dummy alongside the passage version, and the BEST 9K 1DT is a Grade 1 single dummy trim lever. Order a dummy only for a door that does not latch.
10) What comes in the box with an Emtek Elan passage set, and do I need to buy a latch and strike separately?
It is a complete set. The Elan passage leverset includes the latch and the strike plate along with both levers and the rosettes, so nothing further is needed to hang it on a prepped door. You do pick your latch faceplate corner style, round or square, to match whatever is already routed into the door edge.
11) What is the CF mechanism option on Emtek levers and should I pay for it?
CF gets you rosettes with no exposed screws, so the trim reads clean from both faces. It also brings the 28 degree latch with it. If exposed screw heads on the rose do not bother you, the standard latch or the 28 degree rotation latch on its own are the other two choices. On a high-visibility opening (a client-facing entry, a hospitality corridor), CF is what you specify.
12) Can I match the Emtek Elan lever to the rest of the hardware in my building?
Ten brass rosette shapes pair with the Elan lever: #8, Lancaster, Oval, Quincy, Rectangular, Regular, Ribbon and Reed, Rope, Watford and Wilshire. Seven finishes run across the range: French Antique (US7), Oil Rubbed Bronze (US10B), Pewter (US15A), Polished Brass Lifetime (US3), Polished Chrome (US26), Satin Nickel (US15) and Unlacquered Brass (US3NL). That is enough spread to hold a consistent look across a whole floor of doors, mixing passage sets on the closets with other functions on the bedrooms in the same rose and finish.
13) What is the closest alternative to an Emtek Elan brass passage lever if I want a similar decorative look?
The Baldwin Estate 5103 passage lever with the 5048 rose is the nearest decorative equivalent, a designer residential passage lever from the same end of the market. If you want the decorative look at a lower tier, the Bravura Miramar, Atlanta, Orlando and Tampa passage leversets are all Grade 2 residential sets with round or square trim. What none of those give you is the Elan's ten interchangeable brass rosette shapes, which is the whole reason to spec Emtek when the rose has to match the rest of a house.
14) I need a matching privacy set for the bedroom doors and a dummy for the closet. Does the Emtek Elan cover those?
The Elan passage set covers hall, closet and pantry doors only. For bedrooms and baths you need the matching Elan privacy set with a thumbturn, and note that if you choose the STRETTO rosette on a privacy application the door needs a 1-1/4 inch bore and a two-hole prep rather than the standard single 2-1/8 inch bore. If you want a non-functioning lever on a false door or an inactive leaf, the Baldwin Estate 5103 half dummy comes handed left or right.
15) What is a lower-cost passage lever to use on back-of-house doors when the Emtek Elan is going on the main rooms?
For doors that do not need the brass decorative look, the Kwikset 200BRNL Breton passage lever is a Grade 3 passage set for 1-3/8 to 1-3/4 inch doors, the Callan Asheville is a Grade 3 passage leverset, and the Bravura Atlanta and Orlando are Grade 2 passage leversets with round trim. All four are non-keyed passage like the Elan, so keying is not a consideration on any of them.
16) What passage lever should I use on a utility or storage door instead of the Emtek Elan?
A passage lever like the Elan leaves the door unsecured, which is usually wrong for storage. The Cal-Royal AG05 is a Grade 2 storeroom leverset with a deadlocking latchbolt for 1-3/8 to 1-3/4 inch doors, and the Hager 2580 is a Grade 2 storeroom cylindrical lock with the Withnell lever for 1-3/8 to 2 inch doors. For a utility or asylum function, the Dexter C1000 asylum F87 is Grade 1 for 1-3/8 to 2 inch doors.
17) Does the Emtek Elan passage lever need to be ordered handed, and which alternatives avoid that?
The Elan is ordered as Left Hand or Right Hand. If a fleet order should avoid tracking handing door by door, the Falcon B101 Grade 2 passage lever and the Falcon K101 Grade 1 passage lever both use a non-handed design, and the Kwikset 200DL Delta passage lever is reversible with an adjustable 6AL latch and RCS strike.
18) Can I get keyless keypad entry in a lever that works like the Emtek Elan passage set?
The Elan is a mechanical non-electronic leverset. For code entry on the same style of opening, the Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for 1 3/16 inch to 2 inch doors, the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination and passage function for 1-1/8 inch to 2 inch doors, and the Delaney LP250 is a Grade 2 electronic keypad leverlock. These are a different look from a brass decorative rosette set.
19) Is a lever trim for an exit device an alternative to the Emtek Elan passage set?
No, those are different parts. The Elan is a complete bored lockset with latch and strike included, installed in a 2-1/8 inch cross bore. The Corbin Russwin 585F715 is a lock lever for the ED8000 pushpad exit device and the Imperial USA ED-EL500HD is heavy duty escutcheon lever trim with entry function - both are trim that mounts to an exit device rather than a standalone latching lockset for a bored door prep.
20) Is the Emtek Elan lever solid brass or plated pot metal?
Solid brass, substrate and all, which is why it takes finishes like Unlacquered Brass (US3NL) that are meant to patina in service rather than sit under a clear coat. If you want that living finish, order US3NL; if you want the brass to stay bright, Polished Brass Lifetime (US3) is the finish that holds.
21) Does the Emtek Elan passage leverset need power or wiring?
No wiring, no batteries. The Elan is a purely mechanical tubular passage set with no electronic components, so there is nothing to fail when the power drops and no access control to integrate. If you actually want keyless on an interior opening, the Lockey 2835 mechanical pushbutton lever gives you code entry with no power either, on doors 1-3/16 inch to 2 inch thick.
22) Which passage lever matches the Emtek Elan on a square-trim door design?
The Elan latch faceplate can be specified round or square corner, and the rosette options include a Rectangular Rosette for a squared look. If the rest of the opening hardware is square-trim, the Bravura Tampa is a Grade 2 passage leverset with square trim, while the Bravura Miramar and Atlanta use round trim.
