Emtek E4010 EMTouch Classic Style Electronic Keypad Entry Set - Dummy

No. The E4010 EMTouch Classic Style set is a dummy function, so it has no latch and no bolt. The keypad and the trim are there for appearance and matching only, and the handle is fixed. Use it on an inactive leaf of a double door, a closet, or a pantry where you want the look of the keypad entry set without any operating hardware. If you need the door to lock, you need the keyed or electronic entry version rather than the dummy.

The E4010 handleset is specified for doors 1-3/8 inches to 2 inches thick, and the set includes a door thickness field on the order so you can call out your exact measurement. 1-3/4 inches, the standard exterior door, sits in the middle of that range. Measure the leaf at the bore, not at the edge trim, before you order.

Handing is required whenever a lever is used on the inside, and the E4010 is ordered right hand or left hand. Stand outside the door: if the hinges are on your right, it is right hand. Knobs are symmetrical, so handing matters far less there, but the order still asks for it. Get this wrong on a lever and the handle points uphill.

Yes, if the door is prepped to the standard residential bored pattern. The E4010 uses a 2-1/8 inch cross bore and a 2-3/8 inch or 2-3/4 inch backset, which is the same prep almost every residential knob or lever lock in North America uses. Measure from the door edge to the center of the bore: 2-3/8 or 2-3/4 inches. Anything else and the door needs re-prepping.

Four things. Exterior finish (Oil Rubbed Bronze US10B, Satin Nickel US15, or Polished Brass Lifetime US3), the inside knob or lever style, handing, and your door thickness. A split finish can also be called out if you want the inside trim different from the outside. The knob and lever list runs to nearly ninety styles across the brass range, from the Ace Knob and Spoke Knob to the Stuttgart, Athena, and Cortina levers, so the inside trim can be matched to whatever is already on the rest of the doors.

The Kwikset 815SCEHFL-CP913CNT San Clemente Handleset pairs Halifax lever interior trim with a Contemporary SmartCode keypad electronic deadbolt, SmartKey cylinder, RCAL latch and RCS strike, for doors 1-3/4 inch thick. The Yale Real Living BYRD226NRRX Assure Lock is a standalone touchscreen deadbolt with the Ridgefield handleset for doors 1-3/4 inch to 2-1/4 inch. Both drive a deadbolt from the keypad; the Emtek E4010 is a dummy set, so its trim is fixed and does not operate a bolt.

A dummy set has no latch and no bolt, so it will not secure an opening. For a keyed entry on the same style of door, the Schlage Residential F60 Addison Single Cylinder Keyed Entry Handleset with Accent Lever is a Grade 2 entrance handleset for doors 1-3/8 inch to 1-3/4 inch thick. The Weslock 2810 Hillcrest Single Cylinder Handleset with Hudson Knob covers 1-3/8 inch to 2 inch, matching the door range the Emtek E4010 lists.

The Weslock 1411 Traditionale Colonial Handleset with Eleganti Knob is a single cylinder set rated for 1-3/4 inch to 2-1/4 inch doors, and the Yale Real Living BYRD226NRRX Assure Lock standalone touchscreen deadbolt with Ridgefield handleset covers the same 1-3/4 inch to 2-1/4 inch range. The Emtek E4010 specifications list a 1-3/8 inch to 2 inch door thickness.

They prep differently. The Baldwin Estates 6542 Tremont entry mortise trim, offered in single cylinder and double cylinder versions, is trim for a mortise lock body and lists a 1-3/4 inch door thickness. The Emtek E4010 is a bored application: it specifies a 2-1/8 inch cross bore with a 2-3/8 inch or 2-3/4 inch backset. A door prepped for one will not accept the other without rework.

It is a residential product. For an apartment front door, a single family home, or a condo it is on spec. For a commercial opening, a fire door, or anything that has to meet a Grade 1 or Grade 2 requirement on a drawing, this is the wrong hardware and you should be looking at a commercial grade handleset instead.

Two other dummy handlesets carry the same function. The Weslock 6695 Belmont Dummy Handleset with Impresa Knob and the Weslock 2815 Hillcrest Dummy Handleset with New Heaven Lever both fit 1-3/8 to 2 inch doors, the same thickness range as the E4010. The difference is the look: the Emtek carries the touchscreen keypad face so it matches an EMTouch entry set on the active leaf, while the Weslock sets are plain traditional trim.

It ships as a complete set. The exterior handleset with the keypad face and the interior knob or lever you selected come in one box, so there is no second line to add. The interior trim choice is a required selection on the order, not an accessory.

No power is needed. The dummy has no working lock to drive, so the keypad face is cosmetic and there is nothing to program or wire. The EMTouch entry versions run on a 9V battery; the dummy does not.

The Weslock 2815 Hillcrest Dummy Handleset comes with the New Heaven Lever as its interior trim and fits doors 1-3/8 inch to 2 inch thick. The Emtek E4010 also takes a lever inside - the interior trim is ordered separately from a brass knob or lever selection, and handing is required when a lever is used on the inside.

The Yale Real Living BYRD226CBARX Assure Lock is a Wi-Fi and Bluetooth touchscreen deadbolt with the Ridgefield handleset for doors 1-3/4 inch to 2-1/4 inch thick, and the BYRD256 CBARX Assure Key Free touchscreen deadbolt with the Ridgefield passage handleset is a Wi-Fi connected version. The Emtek E4010 EMTouch reads at a touchscreen on the door itself and runs on a 9V battery.

The Kwikset 687AMD Amador and 687BW Belleview single cylinder handlesets are sold as exterior trim only, both Grade 3 entrance sets for 1-3/4 inch doors; the 687AMD is offered with SmartKey and in an SC1 keyway SmartKey version. The Emtek E4010 is sold as a complete set with the interior knob or lever ordered as part of it.

The Master Lock HDLBA0615/4D is a Grade 2 single cylinder deadbolt handleset in the HDLB Series, and the Schlage Residential F60 Addison keyed entry handleset is Grade 2 in the F Series. The Kwikset 687AMD Amador and 687BW Belleview are Grade 3 entrance handlesets. The Emtek E4010 is a residential set.

The Schlage Residential JI18/19 is an interconnected passage lock with a keyed deadbolt and Torino lever in satin stainless steel, Grade 2, for doors 1-3/8 inch to 1-3/4 inch thick. That is a different arrangement from the Emtek E4010, which is a dummy set with no latch and no bolt.

No. The Baldwin Wesley handleset is an entrance function, offered with the Alcott knob or the Carnaby knob as interior trim. The Emtek E4010 is a dummy set - fixed trim for an inactive leaf or a second door of a pair, not an operating entrance.

The Deltana 810871 Montego Handleset lists a 1-3/8 inch to 2 inch door thickness range, as do the Weslock 6695 Belmont dummy handleset, the Weslock 2815 Hillcrest dummy handleset and the Weslock 2810 Hillcrest single cylinder handleset. The Emtek E4010 specifications list the same 1-3/8 inch to 2 inch range.

Brass throughout, both the material and the substrate, and it belongs to Emtek's Brass collection in the American Classic style. That matters if you are matching it to brass hinges and other brass trim already hanging in the house, since the finishes on the brass line are made to run together.

The E4010 is not keyed. There is no cylinder in a dummy handleset, so there is nothing to key alike to the rest of the doors. If you are standardizing a house on one key, the dummy simply sits outside that keying schedule.

The Emtek E4010 is offered in Satin Nickel (US15), along with Oil Rubbed Bronze (US10B) and Polished Brass - Lifetime (US3). The Pamex FS7P31 Lexington single cylinder handleset is a satin nickel entry set for doors 1-3/8 inch to 1-3/4 inch thick.
