Emtek Modern Electronic Keypad Deadbolt

It drops into standard door prep with a 2-1/8 inch cross bore, so a door already prepped for a conventional tubular deadbolt takes it without new boring. The latch is a tubular unit and ships standard at 2-3/8 inch backset, with 2-3/4 inch available if that is what the door is bored for. Backset is a required selection when you order, so measure from the door edge to the center of the bore before you place it: 2-3/8 and 2-3/4 are the two usual backsets and picking the wrong one means the latch will not line up with the crossbore.

Yes. The keypad deadbolt is keyed as well as coded, and there is an optional Weiser (WR5) keyway cylinder substitution at order time, ordered as the WE1020 prefix instead of E1020. That lets the key override match a house or unit already on Weiser keys. Take the standard cylinder if you are keying to something else or keying alike within an Emtek set.

No re-drilling on a standard prep. The Emtek keypad deadbolt uses a 2-1/8 inch cross bore and a tubular latch, which is the same prep a conventional tubular deadbolt sits in, so it swaps straight into the existing hole once you match the backset. If the door is not bored at all, or you do not want to bore it, a surface mounted option like the Codelocks CL2200 electronic surface deadbolt mounts on the face of the door instead.

Go to a mechanical Grade 1 deadbolt. The Accentra D111 is a Grade 1 single cylinder deadbolt in the D series with a 2-3/8 inch backset and a 1-3/8 to 1-3/4 inch door thickness range. The Falcon D111 is a Grade 1 heavy duty classroom deadbolt in the D100 series with an adjustable backset. The Design Hardware D1 is a Grade 1 extra heavy duty double cylinder deadbolt for 1-3/4 inch doors. The Emtek Modern Electronic Keypad Deadbolt is a residential brass unit, so a Grade 1 mechanical bolt is the one that answers a commercial specification.

The Delaney KP400 is the nearest code-entry equivalent. It is a Grade 2 electronic deadbolt in the KP400 series and adds a programmable remote to the keypad entry. The Emtek Modern Electronic Keypad Deadbolt is a brass tubular deadbolt with a keypad reader and a keyed cylinder, so it retains a mechanical key override at the same door; the KP400 gives you remote operation instead. Both replace a standard tubular deadbolt rather than a mortise case.

Look at the Dormakaba Nova-D, an RFID multihousing smart electronic deadbolt in the Nova series, or the Dormakaba Saffire LX-D, an RFID electronic deadbolt with BLE and Electronic Lock Override in the Saffire series. Both read a credential or phone rather than a typed code. The Emtek Modern Electronic Keypad Deadbolt is a keypad reader unit and stores its user codes in the lock, which suits doors managed one at a time rather than a credential system.

No, they solve different problems. The DynaLock 1300 is a heavy duty mortise electric deadbolt: it is driven by an access control system and has no reader of its own, and it mortises into the door or frame. The Emtek Modern Electronic Keypad Deadbolt is a self-contained tubular unit with an onboard keypad, a 9V battery, and up to 20 user codes, so it works with no wiring and no panel behind it. Choose the DynaLock when a card system or panel is already releasing the door and the Emtek when the lock itself has to hold the credentials.

Not necessarily. The Emtek Modern Electronic Keypad Deadbolt can be ordered with a Weiser WR5 keyway cylinder substitution, so the key override matches an existing Weiser key system. If the building runs on Schlage C instead, the Hager 3115 Grade 2 cylinder by thumbturn and the Hager 3118 Grade 1 classroom deadbolt both come with a Schlage C keyway, though those are mechanical bolts rather than keypad units. Confirming keyway before ordering is what keeps a retrofit from becoming a rekey.

The Emtek Modern Electronic Keypad Deadbolt fits doors from 1-3/4 to 2-1/4 inch thick with a 2-1/8 inch bore standard prep. On the mechanical side, the Corbin Russwin DL3011 Grade 1 cylindrical deadlock covers 1-3/4 to 2-1/4 inch doors, cylinder by blank. Most bored deadbolts stop well short of that; the Dexter DB2000 series runs 1-3/8 to 1-3/4 inch and the Deltana 7312KA2 Grade 3 double cylinder runs 1-3/8 to 2 inch, so check the leaf before you order.

Up to 20 user codes, and it arrives programmed with 2 unique secure codes out of the box. For a landlord that is enough to give a tenant, a cleaner, and a couple of trades their own codes and pull one without changing the rest. It is a standalone keypad, not networked, so codes are managed at the door.

It is sold as a complete set with the latch and strike plate included, so nothing extra is needed to finish a standard door. It runs on a 9V battery, which is the only consumable. If your jamb is not already prepped for a deadbolt strike you will still need to mortise the jamb for the included plate.

Four finishes: Oil Rubbed Bronze (US10B), Satin Nickel (US15), Flat Black (US19), and Polished Chrome (US26). A split finish can be specified at order time if the interior needs to match trim different from the exterior. The body is brass, which is what carries those plated and patinated finishes.

For a mechanical bolt in the same contemporary look, the Bravura 310SC Elite is a Grade 2 contemporary square deadbolt and the Bravura 310RC Elite is a Grade 2 contemporary round deadbolt, both cylinder by thumbturn. The Baldwin Reserve contemporary square and round double cylinder deadbolts cover the same trim shapes with a key on both sides. The Emtek Modern Electronic Keypad Deadbolt is a contemporary style brass deadbolt with keypad entry, so pairing it with these puts code entry on the doors that need it and a plain thumbturn or key on the rest.

Several bored deadbolts land in the same prep. The Hager 3215 is a Grade 2 single cylinder deadbolt with a 1 inch throw for 1-3/8 to 1-3/4 inch doors, fire rated, with a Schlage C keyway. The Dexter DB1000 single cylinder is Grade 1 cylinder by thumbturn for 1-3/8 to 1-7/8 inch doors. The Cal-Royal CB160 is a Grade 2 single cylinder deadbolt with a tamper-resistant cylinder guard. All three give a key outside and a thumbturn inside where the Emtek Modern Electronic Keypad Deadbolt puts a keypad and a keyed cylinder.

No. The BEST 8T is a T series tubular deadbolt tube component, meaning the bolt mechanism alone rather than a finished lock, and the Arrow 460 is a mortise lock strike for latchbolt and deadbolt functions with a straight lip, which is frame hardware. The Emtek Modern Electronic Keypad Deadbolt is sold as a complete set including the latch and strike plate, so nothing else is needed to finish the opening. Order the BEST or Arrow parts only when replacing a piece of an existing lock.

The Arrow E60 is a Grade 2 exit deadlock, non-keyed, with a blank plate outside and a thumbturn inside for 1-3/8 to 1-3/4 inch doors. The Callan Model 205S is a Grade 3 one-sided half-bore deadbolt, which uses a partial bore rather than a through bore. Either suits a door that only has to lock from the inside, where the Emtek Modern Electronic Keypad Deadbolt is built for entry from outside with a stored user code.
