Square D EM3570ENC Enclosure for PowerLogic EM357x Meters, NEMA 4X
The Square D EM3570ENC is a protective mounting enclosure built for Schneider Electric PowerLogic EM357x Series energy meters, including the PowerLogic EM3570. Rated NEMA 4X, it shields the meter from tampering, dust, and moisture in both indoor and outdoor settings. The wall-mounted enclosure includes DIN rail mounting hardware for straightforward installation and features a transparent fixed door that keeps the meter visible without exposing it to the elements. It is sized for a single meter socket, making it a clean fit for one PowerLogic EM3570 installation.
Key Features
- Meter Compatibility: Adapted to the METSEEM3570 meter range and built to house PowerLogic EM357x Series energy meters, including the EM3570.
- NEMA 4X Degree of Protection: Guards against dust, water ingress, and corrosion for durable indoor or outdoor service.
- DIN Rail Mounting Hardware Included: The enclosure ships with DIN rail mounting hardware for fast, secure meter installation.
- Wall-Mounted Enclosure: Designed for wall mounting, giving installers a flexible placement option near the metering point.
- Transparent Fixed Door: A clear front panel provides visibility of the meter display and status without opening the enclosure.
- Single Meter Socket: Configured for one meter socket to accommodate a single PowerLogic EM3570 unit.
Certifications & Compliance
- NEMA 4X Rated Enclosure
- RoHS EU Compliant (In Scope)
- Meets WEEE Collection and Disposal Requirements
Technical Specifications
- Take Back: No
- Tier: 1
- Returnability: Yes
- Sustainable Packaging: No
- Packaging Without Single Use Plastic: No
- Reach Free Shvc: Yes
- Tier Id: 1
- ROHS Eur In Scope: Yes
- Recycled Metal Content At Cr Level: 0 %
- Legacy WEEE Scope: In
- China ROHS Regulation: X
- Packaging Made With Recycled Cardboard: No
- China ROHS Label: 1
- Serviceability: No
- Number Of Meter Sockets: 1
- With Recycled Cardboard: No
- WEEE Product Category: 5
- Without Single Use Plastic: No
- Enclosure Feature: Enclosure include DIN rail mounting hardware
- ROHS Exemption Information: Yes
- Reach Free Of Svhc: Yes
- NEMA Protection Note: NEMA 4x, weather-proofing and durability
Typical Applications
- PowerLogic EM3570 Energy Meter Installations
- Commercial and Industrial Metering Points
- Outdoor and Wet-Location Meter Mounting
- Panelboard-Adjacent Metering
- Retrofit and New Construction Metering
Why Square D?
Square D by Schneider Electric engineers the EM3570ENC to keep PowerLogic EM357x metering equipment protected and code-compliant in demanding environments. With a NEMA 4X rating, included DIN rail mounting hardware, and RoHS-compliant construction, this enclosure delivers the reliable, tamper-resistant housing professionals expect for energy monitoring installations.
Manufacturer Resources
Product Specs
- Product Type:
- Equipment Enclosure
- Configuration:
- NEMA 4X Enclosure
- Series:
- PowerLogic
- Standards:
- RoHS Compliant
- Country Of Origin:
- United States
- Department:
- Electrical
- Product Group:
- Boxes & Enclosures
- Product Subgroup:
- Enclosures
Square D METSEEM3570ENC – Frequently Asked Questions
1) Which meters does the Square D EM3570ENC enclosure fit?
The EM3570ENC is built to house Schneider Electric PowerLogic EM357x Series energy meters, including the PowerLogic EM3570. It is configured for a single meter socket, so one EM3570 per enclosure. If you are metering multiple circuits with several meters, you need one enclosure per meter.
2) Can the EM3570ENC meter enclosure be mounted outdoors?
Yes. The enclosure carries a NEMA 4X rating, which covers dust, water ingress and corrosion resistance, so it is suitable for outdoor and wet-location mounting as well as indoor service. It is a wall-mount enclosure, so plan a flat surface near the metering point.
3) Do I need to buy DIN rail separately to mount the EM3570 meter in this enclosure?
No. DIN rail mounting hardware ships with the EM3570ENC enclosure, so the meter mounts without sourcing rail or clips separately. The meter itself is a separate purchase.
4) Can an Eaton ECC circuit breaker enclosure be used to house a PowerLogic EM3570 meter instead of the Square D EM3570ENC?
No. The Square D EM3570ENC is purpose-built for the PowerLogic EM357x Series energy meters, including the EM3570, with a single meter socket, DIN rail mounting hardware included, and a transparent fixed door that leaves the meter display readable with the enclosure closed. The Eaton ECC Series is a circuit breaker enclosure built around a CCV frame type breaker, so it is prepped for a breaker rather than a meter socket and does not provide the meter-specific socket or the clear viewing door. For an EM3570 installation, the EM3570ENC is the matched housing.
5) Can I read the meter display without opening the enclosure?
Yes. The EM3570ENC has a transparent fixed door, so the meter display and status LEDs stay visible with the enclosure closed. The door is fixed rather than hinged with a window cutout, which is also what keeps the NEMA 4X seal intact and the meter tamper-resistant.
6) What is the exact part number to order for the PowerLogic EM3570 enclosure?
Order Square D METSEEM3570ENC, also published as EM3570ENC. There is one configuration, a NEMA 4X enclosure, so there are no finish or size options to specify.
7) Is this meter enclosure a general-purpose electrical enclosure I can use for breakers or other gear?
No. The EM3570ENC is purpose-sized for a single PowerLogic EM357x meter socket with its own DIN rail hardware, not a blank general-purpose box. For breaker or general industrial housings, look at the Eaton ECC Series circuit breaker enclosure or the Eaton MVXENC Series industrial electrical enclosure instead.
8) What is the difference between the Square D EM3570ENC and an Eaton MVXENC industrial enclosure?
The Square D EM3570ENC is a dedicated meter enclosure: it is rated NEMA 4X for indoor or outdoor and wet-location service, holds one meter socket for a PowerLogic EM357x Series meter such as the EM3570, mounts to a wall, and ships with DIN rail mounting hardware behind a transparent fixed door. The Eaton MVXENC Series is a general industrial electrical enclosure rather than a meter-specific housing, so it is the choice when you are enclosing other electrical apparatus and the meter socket and clear door are not needed. Pick the EM3570ENC when the contents are an EM357x meter you want visible and weather-protected.
9) If I need to enclose a circuit breaker rather than an energy meter, what should I order instead of the Square D EM3570ENC?
The EM3570ENC is configured as a NEMA 4X enclosure with one meter socket sized for a single PowerLogic EM3570, so it is not the right box for a breaker. For a breaker application, the Eaton ECC Series enclosure is built for a CCV frame type circuit breaker and is UL Listed. Keep the EM3570ENC for the metering point itself.
10) Does the EM3570ENC enclosure meet RoHS and WEEE requirements for a spec submittal?
Yes. It is listed as RoHS compliant and in scope for EU RoHS, free of REACH SVHCs, and it meets WEEE collection and disposal requirements under WEEE product category 5. Country of origin is the United States.
11) Can I use this enclosure for a retrofit where the meter is going in next to an existing panelboard?
Yes, that is one of its intended uses. The wall-mount design lets you place it adjacent to a panelboard at the metering point, and it is used in both retrofit and new construction metering. For a tenant submetering fleet, standardizing on one enclosure per EM3570 keeps every point looking and wiring the same.
