Falcon K101 Grade 1 Passage Cylindrical Lock with Non-Handed Levers

Falcon K101 Grade 1 Passage Cylindrical Lock with Non-Handed Levers

Professional Grade 1 Cylindrical Lock Solution

The Falcon K101 Grade 1 Passage Cylindrical Lock delivers certified ANSI/BHMA Grade 1 performance for high-traffic commercial applications. Designed for door thickness range of 1-3/8" to 2-1/4" with standard 2-3/4" backset, this heavy-duty lock features through-bolted construction and clutching lever design for exceptional durability. UL10C 3 hour A label fire rating ensures code compliance for critical applications.

Professional Features & Benefits

• Door Compatibility: Accommodates door thickness range of 1-3/8" to 2-1/4" with standard 2-3/4" backset for versatile installation options.
• Heavy-Duty Construction: Four screws through-bolted design provides added strength and security for demanding commercial environments.
• Clutching Lever Protection: Innovative clutching lever design allows lever movement when locked without unlatching the door, preventing chassis damage from forced operation.
• Grade 1 Certification: Certified ANSI/BHMA A156.2, Series 4000, Grade 1 for proven performance in high-traffic applications.
• Fire Rating Compliance: UL10C 3 hour A label certification ensures code compliance for fire-rated door applications.
• Non-Handed Installation: Non-handed levers simplify field installation and reduce inventory requirements.
• Vandal-Resistant Features: Lever security caps help prevent undesired lever removal and lever sag after continual use.
• Manufacturer Warranty: 10-year warranty provides added confidence and long-term protection.

Technical Specifications

• ANSI/BHMA: F109-1
• Backset (Distance): 2-3/4"
• Commercial/Residential: Commercial
• Department: Door Hardware
• Door Hand Direction: Non-Handed
• Door Thickness Range: 1-3/8" to 2-1/4"
• Duty Level: Heavy Duty
• Electronic: No
• Fire Rating: Yes
• Grade: Grade 1
• Keyed: No
• Keyed Function: Non-Keyed
• Lock Function: Passage
• Lock Type: Cylindrical
• Product Attribute: Cylindrical Locks
• Product Category: Mechanical Locks
• Product Function: Passage/Hall/Closet
• Product Group: Mechanical Locks
• Product Model: K101
• Product Subgroup: Bored Locksets
• Product Substrate: Brass or Steel, Zinc plated and dichromated for rust resistance. Springs are Stainless Steel.
• Product Type: Leversets
• Series: K Series
• Standard Latch: 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" Throw, 2-3/4" backset
• Standard Strike: 1-1/4" x 4-7/8", ANSI, Square curved lip corner, no box
• Subcategory: Cylindrical Locks
• UL Listing Type: UL Listed (3 Hour A Label)

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness range of 1-3/8" to 2-1/4" and 2-3/4" backset compatibility.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for proper alignment.
3. Prepare door by drilling required holes per manufacturer specifications for cylindrical lock installation.
4. Install all mounting hardware and secure the device to door using the four through-bolt system per manufacturer torque specifications.
5. Adjust operational components for proper alignment, latching, and smooth lever operation throughout the full range of motion.
6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Falcon Quality?

Falcon K101 cylindrical locks deliver professional-grade reliability with brass or steel construction featuring zinc plating and dichromate treatment for rust resistance, plus stainless steel springs for long-term durability. Certified ANSI/BHMA Grade 1 and UL10C 3 hour A label fire rating ensure code compliance and dependable performance. Backed by a comprehensive 10-year warranty, this lock is engineered for demanding commercial applications where consistent operation and security are essential.
