Falcon SC60A-3077DS Dead Stop Parallel Arm for SC60A Series Door Closers

Heavy-Duty Replacement Arm Assembly

The Falcon SC60A-3077DS is a specialized dead stop parallel arm designed for SC60A Series door closers. This optional, non-handed stamped arm assembly features a positive mechanical stop and non-adjustable forearm assembly, engineered specifically for high volume traffic or potentially abusive installation conditions where standard arms may not provide adequate durability.

Professional Features & Benefits

  • Heavy-Duty Construction: Stamped design provides exceptional durability for demanding commercial applications and high-traffic environments.
  • Positive Mechanical Stop: Built-in dead stop mechanism prevents over-travel and protects door and frame from damage in abusive conditions.
  • Non-Adjustable Design: Fixed forearm assembly eliminates adjustment points that could be tampered with or require maintenance in high-abuse installations.
  • Universal Handing: Non-handed design allows installation on both left-hand and right-hand door applications without separate part numbers.
  • SC60A Series Compatibility: Specifically engineered for use with Falcon SC60A Series door closers for guaranteed fit and performance.
  • High-Volume Traffic Ready: Purpose-built for installations where standard parallel arms may experience excessive wear or abuse.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Parts and Accessories Type: Replacement Parts
  • Product Attribute: Parts and Accessories
  • Product Category: Door Controls
  • Product Group: Door Controls
  • Product Subgroup: Parts and Accessories
  • Product Type: Door Closer Arms
  • Series: SC60A Series

Installation & Operation

This replacement arm assembly is designed for use with compatible Falcon SC60A Series door closers. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • High-Traffic Commercial Buildings
  • Educational Facilities with Heavy Use
  • Healthcare Institution Service Areas
  • Retail Establishments with Frequent Door Operation
  • Industrial Facilities with Potential Equipment Contact
  • Public Buildings Subject to Abuse
  • Multi-Tenant Properties Requiring Durability

Why Choose Falcon Quality?

Falcon door closer components deliver professional-grade reliability with heavy-duty stamped construction designed for the most demanding commercial applications. The SC60A-3077DS dead stop arm provides positive mechanical protection and non-adjustable operation where standard arms may fail. Engineered for high-volume traffic and potentially abusive conditions where dependable performance and tamper resistance are essential.

Manufacturer Resources

Falcon Closers Catalog

Product Specs

Product Group:
Door Controls
Product Subgroup:
Parts and Accessories
Commercial/Residential:
Commercial
Product Type:
Door Closer Arms
Series:
SC60A Series
Parts and Accessories Type:
Replacement Parts
Product Attribute:
Parts and Accessories
Product Category:
Door Controls
Department:
Door Hardware

Falcon SC60A-3077DS DKB – Frequently Asked Questions

1) Do I need to order a left hand and right hand version of the Falcon dead stop parallel arm?
No. The SC60A-3077DS is non-handed, so the same part goes on left hand and right hand openings. One part number covers both, which makes it easier to stock a few on the shelf for a building with doors swinging in both directions.
2) What does the DS dead stop arm actually do that a standard parallel arm doesn't?
It carries a positive mechanical stop built into the arm, so the door is physically stopped at its open position instead of swinging into a wall or piece of equipment. The forearm is non-adjustable, which removes the adjustment points a standard parallel arm has and gives you nothing for a user to tamper with or knock out of setting. Falcon calls it out for high volume traffic and potentially abusive conditions.
3) I want a hold open feature as well as a stop. Does this Falcon arm do both?
No. The SC60A-3077DS gives you a dead stop only, with no hold open. If you need the door to stay open, look at a hold open arm such as the Sargent 25-CPSH, which pairs a compression stop with hold open, or the LCN 1250-3049/PA hold open arm assembly with an adjustable hold open. Those are different closer platforms, so match the arm to the closer body you have.
4) My closer is a Sargent 351, not a Falcon. What dead stop arm do I need?
Not this one. The SC60A-3077DS is cut for the Falcon SC60A closer. For a Sargent 351 or 281, the Sargent 25-CPS heavy duty parallel arm with compression stop is the equivalent part, and the 25-CPSH is the same thing with hold open added. Both are Grade 1 heavy duty.
5) What is the closest equivalent to the Falcon SC60A-3077DS if the closer on the door is a Sargent instead of a Falcon SC60A?
The Falcon SC60A-3077DS is a dead stop parallel arm built for Falcon SC60A Series closers, so it should not be fitted to a Sargent body. For a Sargent closer, the Sargent 25-CPS is a heavy duty parallel arm with a compression stop for 351 and 281 closers, which is the same idea of a parallel-mounted arm carrying a built-in stop. It is a Grade 1 heavy duty arm. Match the arm to the brand and series of the closer already on the door rather than to the stop feature alone.
6) I need the door to stay open at a set point, not just stop hard. Is the SC60A-3077DS the right arm?
No. The SC60A-3077DS uses a positive mechanical stop with a non-adjustable forearm, which arrests the door but does not hold it open. For hold open, the Sargent 25-CPSH is a heavy duty hold-open parallel arm with a compression stop for 351 and 281 closers, and the Sargent 25-H is a hold-open arm for 351 and 281 closers in standard and top jamb mount. On LCN closers, the 1250-3049/PA is a hold open arm assembly with a parallel arm shoe and adjustable hold open, and the 4010-3049 is a hold open arm with an adjustable elbow function. Pick the one matching the closer brand and series on the opening.
7) The LCN 1260-3077 has a similar part number ending. Can it be used in place of the Falcon SC60A-3077DS?
No. The shared 3077 digits do not make them interchangeable. The LCN 1260-3077 is a regular arm with a parallel arm bracket for LCN 1260 Series closers, and the LCN 4000T-3077T is a standard arm replacement component for the 4000T Series. The Falcon SC60A-3077DS is built for Falcon SC60A Series closers and carries a dead stop with a non-adjustable forearm, which the regular arms do not. Order by closer brand and series, not by the numeric suffix.
8) Can I use the dead stop arm instead of a floor stop or wall stop?
That's the point of it. The dead stop is integral to the arm, so it halts door travel at the closer rather than relying on a separate wall or floor bumper. It's useful where a wall stop has nothing to mount to, or where a floor stop is a trip hazard. Keep in mind the stop is not adjustable on this arm, so the open angle is what the arm gives you.
9) What finishes does the Falcon SC60A-3077DS dead stop arm come in?
Four: 689 aluminum, 695 dark bronze, 696 brass, and 622 matte black. 689 and 695 are the usual matches for existing commercial closers; 622 matte black is the one to pick if you're matching newer black hardware packages across a property.
10) I'm replacing a broken arm on an existing Falcon closer. Can I reuse the closer body?
Yes, that's exactly what this part is for. The SC60A-3077DS is sold as a replacement arm assembly, so if the closer body still holds oil and controls the door, you swap the arm and shoe rather than the whole unit. Follow the SC60A closer's own installation instructions for arm and shoe placement, and confirm the existing mounting is parallel arm rather than regular or top jamb, since this arm is a parallel arm.
11) What's the difference between a parallel arm dead stop and a regular arm on a door closer?
A parallel arm mounts the closer on the pull side with the arm running back along the face of the door, which keeps the hardware tight to the door and out of reach, and a dead stop version adds a mechanical stop at the arm. A regular arm projects out from the frame on the push side, which is more efficient mechanically but leaves the arm exposed. On abuse-prone openings the parallel arm dead stop is the usual call. If you need a regular arm for a different closer platform, the LCN 1260-3077 is a regular arm with parallel arm bracket assembly.
12) For a high-abuse opening, how does the Falcon SC60A-3077DS differ from an adjustable-elbow arm?
The SC60A-3077DS uses a stamped, non-handed arm with a non-adjustable forearm, which removes the adjustment points that can be tampered with in abusive installations, and adds a positive mechanical stop. By contrast, the LCN 4010-3049 is a hold open arm with an adjustable elbow function and the LCN 1250-3049/PA offers adjustable hold open, both of which give field adjustment at the arm. Choose based on whether you want field adjustability or a fixed, tamper-resistant assembly, and on the closer series already installed.
13) We need a top jamb mount arm. Does the Falcon SC60A-3077DS work there?
The Falcon SC60A-3077DS is a parallel arm assembly for SC60A Series closers, mounted parallel to the door. For a top jamb application the Sargent 25-H is a hold-open arm for 351 and 281 closers offered for standard and top jamb mount. Confirm the mounting arrangement against the closer body on the opening before ordering either one.
14) Is this a commercial-duty arm or is it fine for a residential door?
It's a commercial component. Falcon specifies it for high volume traffic and abusive installation conditions, with stamped heavy-duty construction, and it's classed as commercial rather than residential. Typical uses are schools, healthcare service corridors, retail entries, and multi-tenant common doors.
