Falcon T501 Grade 1 Heavy-Duty Cylindrical Entry Lock with Keyed Lever

Falcon T501 Grade 1 Heavy-Duty Cylindrical Entry Lock with Keyed Lever

Professional-Grade Entrance Lock Solution

The Falcon T501 represents the most versatile lockset in the industry, engineered as an extra heavy-duty Grade 1 cylindrical lock designed for high-traffic commercial applications. This entrance lock features a 2-3/4" backset with adjustable door thickness from 1-3/4" to 2-1/8", accommodating most standard door preparations. Built with heavy-duty compression springs and through-bolted construction, the T501 exceeds ANSI/BHMA cycle test requirements while providing consistent lever return and preventing lever sag for long-lasting performance.

Professional Features & Benefits

• Adjustable Door Compatibility: Accommodates door thickness from 1-3/4" to 2-1/8" with 2-3/4" backset for versatile installation options.
• Heavy-Duty Construction: Compression springs behind the rose provide consistent lever return and prevent lever sag, far exceeding ANSI/BHMA cycle test requirements.
• Pressure Release Technology: Standard Pressure Release® lever rotation prevents damage to internal lock components when subjected to excessive force.
• Universal Cylinder Compatibility: Accepts most manufacturers' conventional key systems, small format interchangeable cores (SFIC), and Schlage full size interchangeable cores (FSIC).
• Vandal-Resistant Design: Inside levers are attached by Allen-head set screw to prevent tampering or vandalism in high-risk applications.
• Through-Bolted Security: Trim secured with two 10-32 screws coated with thread sealant for maximum durability and security.
• Non-Handed Installation: Does not require field disassembly for re-handing, simplifying installation and inventory management.
• Fire-Rated Certification: UL 3-hour A label certified with outer trim designed to bottom out and prevent door collapse.

Technical Specifications

• ANSI/BHMA: F82
• Backset (Distance): 2-3/4"
• Commercial/Residential: Commercial
• Cylinder and Keyways: G Keyway
• Department: Door Hardware
• Door Hand Direction: Non-Handed
• Duty Level: Heavy Duty
• Electronic: No
• Grade: Grade 1
• Handle Type: Lever
• Keyed: Yes
• Keyed Function: Single Cylinder
• Lock Function: Entrance
• Lock Type: Cylindrical
• Product Attribute: Cylindrical Locks
• Product Category: Mechanical Locks
• Product Function: Entrance
• Product Group: Mechanical Locks
• Product Model: T501
• Product Subgroup: Bored Locksets
• Product Type: Leversets
• Rose Diameter: 3-1/2"
• Series: T Series
• Standard Latch: 1/2" Throw
• Standard Strike: ANSI 1-1/4" x 4-7/8" with 1-3/16" Lip
• Subcategory: Cylindrical Locks

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness from 1-3/4" to 2-1/8", 2-3/4" backset, and standard cylindrical lock bore dimensions.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for proper alignment.
3. Prepare door by drilling required 2-1/8" bore hole and 1" edge bore according to ANSI A115 standards.
4. Install latch assembly with 1/2" throw deadlatch and secure with provided screws per manufacturer torque specifications.
5. Mount lock trim using through-bolted construction with two 10-32 screws coated with thread sealant for maximum security.
6. Test lever operation to verify proper function, Pressure Release® operation, and smooth engagement throughout the full range of motion. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Multi-Family Residential Properties
• Commercial Office Buildings
• Retail Establishments
• Educational Facilities
• Healthcare Institutions
• Government and Military Buildings
• Industrial and Institutional Facilities

Why Choose Falcon Quality?

Falcon T Series locks deliver professional-grade reliability with heavy-duty compression spring construction that exceeds ANSI/BHMA Grade 1 cycle test requirements. UL 3-hour fire rating certification and through-bolted security construction provide dependable performance for demanding commercial applications. Engineered for high-traffic institutional use where consistent operation and vandal resistance are essential for long-term facility security.
