Mersen Class CC Time-Delay Fuse 5A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Mersen Class CC Time-Delay Fuse 5A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Professional Circuit Protection with Superior Breaking Capacity

The Mersen Class CC Time-Delay Fuse delivers reliable circuit protection for AC and DC applications with 5A current rating, 600VAC/300VDC voltage capability, and exceptional 200kA breaking capacity. Featuring ferrule terminals with tin-plated copper construction and GMG body insulating material, this Amp-Trap 2000 series fuse provides professional-grade protection in a compact 1.5-inch form factor with clip mounting for versatile installation requirements.

Professional Features & Benefits

• 200kA Breaking Capacity: Exceptional fault current interruption capability ensures reliable protection under extreme conditions and enhances system safety.
• Class CC Time-Delay Design: Provides selective coordination and allows temporary overloads while protecting against sustained overcurrent conditions.
• Dual Voltage Rating 600VAC/300VDC: Versatile voltage compatibility supports both AC and DC applications with reliable performance across diverse electrical systems.
• Ferrule Terminal Construction: Tin-plated copper terminals ensure secure connections and excellent conductivity for long-term reliability.
• GMG Body Insulating Material: High-quality insulation provides superior electrical isolation and mechanical durability in demanding environments.
• Compact 1.5-inch Length: Space-efficient design enables installation in tight spaces while maintaining full protection capabilities.
• Clip Mounting System: Simple and secure mounting method facilitates quick installation and maintenance access.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 200 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 5:00 AM
• Body Insulating Material: GMG
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Class CC
• Mounting Method: Clip
• Product Length: 1.5 in
• Product Weight: 0.017 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 300 V
• Speed Characteristic: Time Delay

Installation & Operation

1. Mount the fuse in a suitable fuse holder or clip assembly with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Control Panels and Motor Control Centers
• Commercial HVAC and Lighting Systems
• Power Distribution Equipment and Switchgear
• Electronic Equipment and Instrumentation Protection
• Renewable Energy Systems and Battery Storage
• Telecommunications and Data Center Infrastructure
• Medical Equipment and Laboratory Instrumentation

Why Choose Mersen Quality?

Mersen fuses deliver proven reliability with superior breaking capacity, precision engineering, and durable construction materials. The Class CC time-delay design ensures selective coordination while the compact form factor and clip mounting system provide installation flexibility for professional electrical applications requiring dependable circuit protection.
