Mersen Class CC Time-Delay Fus...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$94.69
$44.69

Mersen Class CC Time-Delay Fuse 1A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

(No reviews yet) Write a Review

Model: ATQR1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$94.69
$44.69
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks

Mersen Class CC Time-Delay Fuse 1A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Professional Circuit Protection with High Breaking Capacity

The Mersen Class CC Time-Delay Fuse delivers reliable circuit protection with 1A rating for both AC and DC applications. Engineered with 600VAC/300VDC voltage ratings and 200kA breaking capacity, this ferrule terminal fuse provides professional-grade overcurrent protection. The time-delay characteristic allows temporary overloads while protecting against sustained faults, making it ideal for motor and inductive load applications.

Professional Features & Benefits

  • 1A Current Rating: Precise overcurrent protection for sensitive circuits and equipment applications
  • 600VAC/300VDC Dual Voltage: Versatile protection for both AC and DC electrical systems
  • 200kA Breaking Capacity: High fault current interruption capability for demanding electrical environments
  • Class CC Design: Compact size with rejection feature prevents installation of higher-rated fuses
  • Time-Delay Characteristic: Allows temporary overloads while providing fast response to sustained faults
  • Ferrule Terminal Construction: Secure tin-plated copper connections for reliable electrical contact
  • RoHS Compliant: Environmentally responsible design meeting international standards

Technical Specifications

  • Ac Max I R Breaking Capacity I1: 200 kA
  • Ac Or Dc: AC/DC
  • Ampere Rating: 1:00 AM
  • Body Insulating Material: GMG
  • Connection Terminal Material: Tin-Plated Copper
  • Connection Terminal Type: Ferrule
  • Frequency Hz : 50/60 Hz
  • Fuse Class: Class CC
  • Mounting Method: Clip
  • Product Length: 1.5 in
  • Product Weight: 0.017 lb
  • Rated Voltage Ac Ul: 600 V
  • Rated Voltage Dc Ul: 300 V
  • Rohs Compliant: Yes
  • Speed Characteristic: Time Delay

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Motor Control Centers and Starter Applications
  • Industrial Control Panels and Equipment Protection
  • Commercial HVAC and Lighting Systems
  • Process Control and Instrumentation Circuits
  • Power Distribution and Electrical Panels
  • Renewable Energy and DC Power Systems
  • Emergency and Backup Power Applications

Why Choose Mersen Quality?

Mersen fuses deliver proven reliability with RoHS compliant construction and professional-grade materials. The GMG insulating material and tin-plated copper terminals ensure long-term performance and environmental compliance. With compact 1.5-inch length and lightweight 0.017 lb design, these fuses provide space-efficient protection for demanding electrical applications.

Manufacturer Resources

Product Specs

Ac Max I R Breaking Capacity I1:
200 kA
Ac Or Dc:
AC/DC
Ampere Rating:
1:00 AM
Body Insulating Material:
GMG
Connection Terminal Material:
Tin-Plated Copper
Connection Terminal Type:
Ferrule
Frequency Hz :
50/60 Hz
Fuse Class:
Class CC
Mounting Method:
Clip
Product Length:
1.5 in
Product Weight:
0.017 lb
Rated Voltage Ac Ul:
600 V
Rated Voltage Dc Ul:
300 V
Rohs Compliant:
Yes
Speed Characteristic:
Time Delay
