Mersen ATQR Class CC Time-Delay Fuse 3.2A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Mersen ATQR Class CC Time-Delay Fuse 3.2A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Professional Circuit Protection with Superior Breaking Capacity

The Mersen ATQR Class CC Time-Delay Fuse delivers reliable circuit protection with 3.2A rating and dual voltage capability of 600VAC/300VDC. This Amp-Trap 2000 series fuse features ferrule terminals with tin-plated copper construction and GMG body insulating material for dependable performance in demanding electrical applications. The time-delay characteristic provides enhanced motor and inductive load protection while maintaining precise overcurrent response.

Professional Features & Benefits

• 3.2A Ampere Rating: Provides precise current protection for sensitive circuits and equipment applications.
• Class CC Design: Ensures current-limiting performance with rejection features to prevent incorrect fuse installation.
• 200 kA Breaking Capacity: Delivers exceptional fault current interruption capability for high-demand electrical systems.
• Time-Delay Characteristic: Allows temporary overloads while providing fast response to sustained overcurrent conditions.
• Dual Voltage Rating: Supports both 600VAC and 300VDC applications for versatile installation flexibility.
• Ferrule Terminal Design: Enables secure clip mounting with tin-plated copper terminals for reliable electrical connections.
• Compact 1.5 inch Length: Fits standard fuse holders while maintaining professional performance standards.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 200 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 3.2 A
• Body Insulating Material: GMG
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Class CC
• Mounting Method: Clip
• Product Length: 1.5 in
• Product Weight: 0.017 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 300 V
• Speed Characteristic: Time Delay

Installation & Operation

1. Mount the fuse in a suitable Class CC fuse holder with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire according to the provided 600VAC/300VDC voltage specifications and 3.2A current rating.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test fuse installation and verify proper performance before placing the protected circuit into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to fuse protection systems.

Professional Applications

• Motor Control Centers and Industrial Equipment Protection
• Commercial HVAC and Lighting Control Systems
• Electronic Equipment and Instrumentation Circuits
• Power Distribution Panels and Switchgear
• Process Control and Automation Systems
• Telecommunications and Data Center Infrastructure
• Medical and Laboratory Equipment Protection

Why Choose Mersen Quality?

Mersen ATQR fuses deliver proven reliability with Class CC current-limiting design and 200 kA breaking capacity. The GMG body insulating material and tin-plated copper ferrule terminals ensure long-term durability and consistent electrical performance in professional electrical protection applications.
