Mersen Class R Fuse Block 250VAC/250VDC 60A 3-Pole with Reinforced Clip

Mersen Class R Fuse Block 250VAC/250VDC 60A 3-Pole with Reinforced Clip

Professional electrical protection with reinforced clip-in design

The Mersen Class R Fuse Block delivers reliable electrical protection with dual voltage capability at 250VAC/250VDC and 60A capacity. This 3-pole fuse block features a reinforced clip-in installation method and glass filled polycarbonate construction for durability. With a 200 kA short circuit current rating and direct screw mount installation, this professional-grade fuse block provides dependable circuit protection for demanding applications.

Professional Features & Benefits

• 60A Amperage Rating: Handles substantial electrical loads with reliable current protection for demanding circuits.
• Dual Voltage Capability (250VAC/250VDC): Versatile operation across both AC and DC applications with consistent 250V performance.
• Class R Fuse Compatibility: Ensures proper fuse selection and rejection features for enhanced safety and code compliance.
• 200 kA Short Circuit Current Rating: Provides exceptional fault current interruption capability for high-demand electrical systems.
• Glass Filled Polycarbonate Construction: Delivers superior insulation properties and mechanical strength for long-term reliability.
• Reinforced Clip-In Design: Simplifies fuse installation and replacement while ensuring secure fuse retention.
• RoHS Compliant: Meets environmental standards for responsible electrical component manufacturing.

Technical Specifications

• Ac Or Dc: AC/DC
• Ampere Rating: 60 A
• Body Insulating Material: Glass Filled Polycarbonate
• Frequency Hz : 50/60 Hz
• Fuse Class: Class R
• Fuse Installation Method: Clip-in
• Fuse Type Class: Class R
• Installation Mounting: Direct Screw Mount
• Max Fuse Rating: 60 A
• Number Of Poles: 3-Pole
• Product Height: 2.12 in
• Product Length: 4.75 in
• Product Weight: 0.45 lb
• Product Width: 4.08 in
• Rated Voltage Ac Ul: 250 V
• Rated Voltage Dc Ul: 250 V
• Rohs Compliant: Yes
• Short Circuit Current Rating Sccr : 200 kA
• Torque Rating: 45 lb-in

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Control Panels
• Commercial Electrical Distribution
• Motor Control Centers
• Power Distribution Equipment
• Manufacturing Facilities
• Process Control Systems
• Electrical Switchgear Applications

Why Choose Mersen Quality?

Mersen fuse blocks deliver professional-grade reliability with RoHS compliant construction and precision engineering. The glass filled polycarbonate body provides exceptional insulation properties while the reinforced clip design ensures secure fuse retention. With a robust 45 lb-in torque rating and 200 kA short circuit current rating, this fuse block meets the demanding requirements of professional electrical installations.
