FXLED78SF/PCT
FXLED78SF/PCT - spec sheet
Features
- 66% energy cost savings vs. HID
- 5-Year, No-Compromise Warranty
- NEMA Type - 6H x 6V
- Air-Flow" technology heat dissipation
- Warranty
- Equivalency
- 100,000-hour LED lifespan
- Buy American Act Compliance
FXLED78SF/PCT - spec sheet
Manufacturer Resources
Product Specs
- 208v:
- 0.45A
- 277v:
- 0.34A
- Ambient Temperature:
- Suitable for use in up to -40°C (-40°F) to 40°C (104°F)
- Color Stability:
- LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
- Efficacy:
- 127 lm/W
- Epa:
- 2
- Finish:
- Formulated for high durability and long-lasting color
- Housing:
- Die-cast aluminum housing and door frame
- Iesna Lm 79 Iesna Lm 80 Testing:
- RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
- Input Watts:
- 79W
- Lumens:
- 9,989 lm
- Note:
- All values are typical (tolerance +/- 10%)
- Photocell:
- 120-277V Twistlock photocell included. Photocell is compatible with 120-277V.
- Thd:
- 6.12% at 120V, 7.79% at 277V
- Tilt Increment:
- Rotates in 6 degree increments
- Watts:
- 78W
- Weight:
- 20.6 lbs
- Product Group:
- Lighting
- Product Subgroup:
- Flood Lights
- Department:
- Electrical
