YBLED60/PCT
YBLED60/PCT - spec sheet
Features
- Rugged die-cast aluminum housing withstands harsh environments
- Integrated dusk to dawn photocell
- Widespread light distribution illuminates large areas
- Warranty
- High-impact polycarbonate lens
- Patents
- Buy American Act Compliance
- Vandal-resistant
- 100,000-hour LED lifespan
- Equivalency
YBLED60/PCT - spec sheet
Manufacturer Resources
Product Specs
- 208v:
- 0.30A
- 277v:
- 0.22A
- Color Stability:
- LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
- Efficacy:
- 136 lm/W
- Finish:
- Formulated for high durability and long-lasting color
- Gaskets:
- High-temperature silicone
- Green Technology:
- Mercury and UV free. RoHS-compliant components.
- Housing:
- Precision die-cast aluminum housing and arm
- Iesna Lm 79 Iesna Lm 80 Testing:
- RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
- Input Watts:
- 56W
- Lumens:
- 7,661 lm
- Photocell:
- 120-277V Twistlock photocell included. Photocell is compatible with 120-277V.
- Reflector:
- High-reflectance white paint
- Thd:
- 8.8% at 120V, 8.3% at 277V
- Watts:
- 60W
- Weight:
- 8.6 lbs
- Product Group:
- Lighting
- Product Subgroup:
- LED Fixtures
- Department:
- Electrical
