Greenlee 52033580 Adjustable N...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$123.09
$73.09
Greenlee 52033580 Adjustable Non-Contact Voltage Detector

Greenlee 52033580 Adjustable Non-Contact Voltage Detector, CAT IV 1000V

(No reviews yet) Write a Review

Model: 52033580
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$123.09
$73.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Greenlee 52033580 Adjustable Non-Contact Voltage Detector, CAT IV 1000V

The Greenlee 52033580 Adjustable Non-Contact Voltage Detector gives electricians and maintenance technicians a fast, reliable way to confirm the presence of live voltage before working on wiring, panels, outlets, or cables. Rated for AC V 5 - 1000 with a Frequency range of 50 - 500Hz, this detector is built to Measurement Category CAT IV, 1000V, making it suitable for demanding commercial and industrial testing environments. Powered by a single (1) 1.5 V AAA battery, the detector is compact and portable, and it carries C/US UL Listed and CE Listed compliance for added confidence on the job. With an adjustable, non-contact detection design, this tester helps professionals verify circuit status quickly without ever making direct contact with a live conductor, supporting safer work practices across a wide range of electrical environments.

Key Features

  • Adjustable Sensitivity: Non-contact detection design (Product Type: Adjustable, Non Contact) lets users tailor detection to the task at hand, reducing false positives near sensitive circuits.
  • Broad Voltage Range: Detects AC voltage across a range of AC V 5 - 1000, covering everything from low-voltage control circuits to higher-voltage branch circuits.
  • Frequency Coverage: Operates across a Frequency range of 50 - 500Hz for use with a wide variety of AC power sources.
  • CAT IV Rated: Built to Measurement Category CAT IV, 1000V, supporting safe use in higher-energy environments such as service entrances and main panels.
  • Battery Powered: Runs on (1) 1.5 V AAA battery, keeping the unit lightweight and easy to carry in a tool pouch or pocket.
  • Compact Footprint: Measures approximately 8.900 IN in length, 1.100 IN in height, and 5.200 IN in width for easy handling and storage.

Certifications & Compliance

  • C/US UL Listed
  • CE Listed

Technical Specifications

  • Battery: (1) 1.5 V AAA
  • Country Of Origin: CN
  • Frequency: 50 - 500Hz
  • Measurement Category: CAT IV, 1000V
  • Product Height: 1.100 IN
  • Product Length: 8.900 IN
  • Product Type: Adjustable, Non Contact
  • Product Width: 5.200 IN
  • Standards: C/US UL Listed, CE Listed
  • Voltage Rating: AC V 5 - 1000
  • Volume: 50.90800000000001 CI

Typical Applications

  • Pre-Work Voltage Verification on Panels and Outlets
  • Residential, Commercial, and Industrial Electrical Troubleshooting
  • Wire and Cable Tracing
  • Lockout/Tagout Safety Checks
  • Motor Control and Circuit Testing

Why Greenlee?

Greenlee builds test instruments engineers and electricians trust for accurate, repeatable results on the job. The 52033580 Adjustable Non-Contact Voltage Detector combines a CAT IV, 1000V measurement rating with C/US UL Listed and CE Listed compliance, giving professionals a dependable tool for verifying voltage presence before they touch a circuit. Backed by Greenlee's reputation for durable, code-compliant electrical tools, this detector is built to hold up to daily use in the field, whether on a residential service call or an industrial maintenance shift.

Manufacturer Resources

Product Specs

Battery:
(1) 1.5 V AAA
Country Of Origin:
CN
Frequency:
50 - 500Hz
Measurement Category:
CAT IV, 1000V
Product Height:
1.100 IN
Product Length:
8.900 IN
Product Type:
Adjustable, Non Contact
Product Width:
5.200 IN
Standards:
C/US UL Listed, CE Listed
Voltage Rating:
AC V 5 - 1000
Volume:
50.90800000000001 CI
Department:
Electrical
Product Subgroup:
Voltage Testers

Greenlee 52033580 – Frequently Asked Questions

1) What voltage range will the Greenlee 52033580 non-contact voltage detector pick up?
The Greenlee 52033580 detects AC from 5 to 1000 volts, at frequencies between 50 and 500 Hz. That low 5 V end is what makes it usable for tracing low-voltage control and signal wiring as well as standard 120/277 V branch circuits, and the 500 Hz top end covers drive and generator frequencies above normal 50/60 Hz line power.
2) Is this Greenlee voltage detector rated for use on service entrance and utility side work?
It carries a CAT IV 1000V measurement category rating, which is the category covering the origin of the installation, service entrance, and outdoor overhead lines. That rating also covers everything below it, so panel work, feeders, and receptacle circuits are inside its envelope. It is C/US UL Listed and CE Listed.
3) Can I use this tester to verify how many volts are on a circuit before I work on it?
No. The 52033580 is a non-contact detector, so it indicates the presence of AC voltage between 5 and 1000 V but does not read a value. If you need an actual number, or a verified absence of voltage using a direct contact test, you need a multimeter or a two-lead voltage tester instead. Use the non-contact unit as a first pass and for live-wire tracing.
4) What does the adjustable sensitivity on this non-contact tester actually do for me on the job?
The 52033580 is an adjustable non-contact detector, so you can dial the sensitivity down when you are working in a crowded panel or a bundle of conductors and a fixed-sensitivity pen would light up on every wire near it. Turned up, it picks up voltage through insulation from further away, which is what you want when you are hunting a live conductor in a wall or checking a fixture whip you cannot reach. Fixed-sensitivity testers give you one setting and no way to isolate a single conductor.
5) What can I use the Greenlee 52033580 to check?
It is made for detecting voltage in outlets, lighting fixtures, wires and cables. Typical use is confirming a receptacle or fixture is dead before an electrician or maintenance tech opens it up, and tracing which conductor in a run is hot. It is a detector, not a meter, so it tells you voltage is present, not how much.
6) What battery does the Greenlee 52033580 voltage detector take?
One 1.5 V AAA cell. That is a stock battery any MRO crib or facilities cart already carries, so there is nothing special to order to keep it in service.
7) What is the Greenlee part number and UPC for this adjustable voltage detector?
Greenlee catalog number 52033580, UPC 783310127277. Country of origin is China.
8) Will this Greenlee detector fit in a tool pouch or shirt pocket?
Published dimensions are 8.900 x 5.200 x 1.100 inches, which is the packaged footprint rather than a bare pen-style barrel. Plan pouch or tool bag storage rather than a shirt pocket clip based on those numbers.
