Ives LG11 Lock Guard for Aluminum Doors with Electric Strike Compatibility

Ives LG11 Lock Guard for Aluminum Doors with Electric Strike Compatibility

Professional Latch Protection for Aluminum Door Applications

The Ives LG11 Lock Guard is specifically designed for aluminum doors with latch-type locks or doors equipped with electric strikes. This handed security device features a unique design that provides maximum security by virtually eliminating the opening between door and frame at the latch point. Measuring 3" wide by 9-1/2" high, the LG11 includes 2 welded mounting studs with no exposed fasteners on the face of the unit for enhanced security and clean appearance.

Professional Features & Benefits

• Aluminum Door Compatibility: Specifically engineered for aluminum doors with latch-type locks or electric strike installations for optimal fit and function.
• Maximum Security Design: Unique construction virtually eliminates the opening between door and frame at latch point, preventing unauthorized access attempts.
• Handed Configuration: Unit requires hand specification when ordering - order RH for LHR door and LH for RHR door for proper installation.
• Concealed Fastener Design: Features 2 welded mounting studs with no exposed fasteners on the face of the unit for enhanced security and professional appearance.
• Heavy-Duty Construction: Available in 12 gauge steel or 13 gauge stainless steel for exceptional durability in commercial applications.
• UL Fire Rating: UL10C Listed with 3-hour fire rating for code compliance in fire-rated door assemblies.
• Electric Strike Compatibility: Designed to work with doors equipped with electric strikes for access control integration.

Technical Specifications

• ANSI/BHMA: UL10C Listed (3 hour)
• Commercial/Residential: Commercial
• Department: Door Hardware
• Door Hand Direction: Yes
• Package Includes: 2 welded mounting studs
• Product Category: Door Trim and Accessories
• Product Dimension: W: 3", H: 9-1/2"
• Product Group: Door Trim and Accessories
• Product Model: LG11
• Product Subgroup: Door Trim and Latch Protection
• Product Substrate: Steel or Stainless Steel
• Product Type: Latch Protectors
• Subcategory: Exterior Hardware

Installation & Operation

1. Verify door hand and confirm correct LG11 hand specification (RH for LHR door, LH for RHR door) before installation.
2. Position the lock guard over the latch area ensuring proper alignment with existing lock hardware and electric strike if present.
3. Mark mounting locations using the 2 welded mounting studs as guides for accurate hole placement.
4. Drill mounting holes in aluminum door frame to accommodate the welded mounting studs.
5. Secure the lock guard to the door frame using appropriate fasteners, ensuring the unit sits flush against the door surface.
6. Test door operation to verify proper clearance and function with the lock guard installed. Refer to manufacturer documentation for complete installation details and compatibility requirements.

Professional Applications

• Commercial Office Buildings with Aluminum Storefronts
• Educational Facilities with Aluminum Door Systems
• Healthcare Institutions with Access Control
• Retail Establishments with Electric Strike Systems
• Industrial Facilities with Aluminum Entry Doors
• Multi-Tenant Properties with Controlled Access
• Government Buildings with Security Requirements

Why Choose Ives Quality?

Ives lock guards deliver professional-grade security with heavy-duty construction available in 12 gauge steel or 13 gauge stainless steel. UL10C Listed with 3-hour fire rating ensures code compliance for demanding commercial applications. Engineered specifically for aluminum door applications where maximum latch protection and clean appearance are essential.
