Greenlee 52084913 Knockout Kit with Ratchet and SlugBuster 1/2", 3/4" and 30.5 mm

Greenlee 52084913 Knockout Kit with Ratchet and SlugBuster 1/2", 3/4" and 30.5 mm

(No reviews yet) Write a Review

Model: 52084913
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$569.66
$503.64
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Knockout Kit with Ratchet and SlugBuster 1/2", 3/4" and 30.5 mm

52084913 - spec sheet

Manufacturer Resources

Spec Sheet

Product Specs

Consist Of 1:
KRW-1 High-leverage ratchet wrench
Consist Of 2:
1/2" - 2" conduit size Slug-Buster® punches
Consist Of 3:
1/2" - 2" conduit size dies
Consist Of 4:
7/16" ball-bearing draw stud
Consist Of 5:
3/4" ball-bearing draw stud
Consists Of 6:
KCC-RW2 carrying case
Country Of Origin:
US
Packaged Weight:
11.19
Product Height:
9.675 IN
Product Length:
16 IN
Product Material:
Punch up to 10 ga mild steel
Product Type:
Knockout
Product Width:
9.675 IN
Volume:
1497.6900000000003 CI
Department:
Electrical
Product Subgroup:
Knockout Punches

Greenlee 52084913 – Frequently Asked Questions

1) Do I need a hydraulic pump or drill driver to use this Greenlee knockout kit?
No. The 52084913 is a manual set: it comes with the KRW-1 high-leverage ratchet wrench, and you drive the punch with that. No pump, no hydraulic ram, no drill adapter required. You still need to drill a pilot hole for the draw stud before you start the punch.
2) Can I use this knockout kit on a stainless steel enclosure?
No. The 52084913 punch set is rated for mild steel up to 10 gauge, plus aluminum, brass, copper, fiberglass and plastics. Stainless is not in that list, and punching it with a standard Slug-Buster set risks damaging the punch and die. For a stainless enclosure you want punches specifically rated for stainless.
3) What exactly comes in the Greenlee 52084913 knockout kit?
Six items: the KRW-1 high-leverage ratchet wrench, Slug-Buster punches in 1/2 inch to 2 inch conduit sizes, the matching dies in the same range, a 7/16 inch ball-bearing draw stud, a 3/4 inch ball-bearing draw stud, and the KCC-RW2 carrying case to hold it all.
4) Will this Greenlee kit punch a clean hole for a 30.5 mm metric device?
Yes. The 30.5 mm hole is the standard opening for pilot lights, pushbuttons and selector switches, and the kit's hole range of 0.89 inch to 2.42 inch takes in that size. Slug-Buster punches are designed to drop the slug free rather than wedge it in the die, so you are not prying scrap out between holes on a control panel with a lot of openings.
5) Is this Greenlee knockout set portable enough to carry up a ladder or into a crawlspace?
It ships in the KCC-RW2 carrying case at a packaged weight of 11.19 pounds, with the case measuring 16 inches by 9.675 by 9.675. That is a one-hand carry to the panel, but it is a case, not a pouch. Guys working out of a bag usually pull the two or three punches they need for the day rather than hauling the full set.
