Kwikset KWI-200T Tylo Knob Passage Door Lock with 6AL Latch and RCS Strike

Kwikset KWI-200T Tylo Knob Passage Door Lock with 6AL Latch and RCS Strike

(No reviews yet) Write a Review

Model: 200T-26D
From the Tylo Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$24.10
$16.12
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Kwikset KWI-200T Tylo Knob Passage Door Lock with 6AL Latch and RCS Strike

This product is designed to fit both right-handed and left-handed doors, making it a universal solution for your home. Plus, with 3 interchangeable faceplates - you'll have the flexibility to choose the one that fits your door best. This product is ANSI/BHMA grade 3 certified, meaning it has been tested and certified for durability and performance. Installation is quick and easy - you can have it up and running in just a few minutes with a screwdriver. With a lifetime mechanical and finish warranty, you can trust that this product will last for years to come. This latch is also treated with Microban Antimicrobial product protection, which keeps door hardware 99.9% cleaner than unprotected surfaces.

PRODUCT FEATURES

  • For use on interior doors requiring no locking functionality, such as hallway or closet doors.
  • Universal handing.
  • Fits both right handed and left handed doors.
  • Latch has 3 interchangeable faceplates
  • Round corner, square corner, and drive-in collar
  • ANSI/BHMA grade 3 certified.
  • Latch has adjustable backset 2-3/8" to 2-3/4" to fit all standard door preparations
  • Easily installs in minutes with just a screwdriver.
  • Lifetime mechanical and finish warranty
  • Microban Antimicrobial product protection keeps door hardware 99.9% cleaner than unprotected surfaces

RESOURCES & DOWNLOADS

Kwikset KWI-200T Tylo Knob Passage Door Lock with 6AL Latch and RCS Strike



Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Product Subgroup:
Knobsets
Product Type:
Knobsets
Subcategory:
Knobs
Commercial/Residential:
Residential
Product Features:
Microban
Product Attribute:
Cylindrical Locks
Door Hand Direction:
Reversible
Product Category:
Mechanical Locks
Collection:
Tylo
Department:
Door Hardware

Kwikset 200T-26D – Frequently Asked Questions

1) Will the Kwikset 200T Tylo passage knob fit a door bored for a 2-3/8 inch backset, or do I need the 2-3/4 inch version?
Either one. The 6AL latch that ships with the Tylo 200T is adjustable from 2-3/8 inches to 2-3/4 inches, so one part covers both standard bore centers. That is the practical reason to stock it across a building: you don't have to know the backset before you get to the door. 2-3/8 and 2-3/4 are the only two backsets you'll see on standard residential prep, so nothing else needs ordering.
2) Is the Kwikset Tylo 200T handed? I have doors swinging both ways down the hall.
Handing is not a factor. The Tylo 200T is reversible and works on right-hand and left-hand doors as supplied, so one part number covers every opening in the corridor regardless of swing.
3) Does the Kwikset 200T passage knob lock? I need something for a bedroom door.
It doesn't lock, and that rules it out for a bedroom. The Tylo 200T is a passage set, latch only, meant for interior openings that need no locking at all: hallways, closets, laundry rooms. For a bedroom or bath you want a privacy function with a push-button inside and an emergency release outside. In knobs, the Pamex FTF Baron in privacy function (Grade 3) or the Dexter C2000 privacy ball knob (Grade 2) are the direct counterparts.
4) Is a Grade 3 knob like the Kwikset Tylo tough enough for an apartment building corridor or an office?
Grade 3 is the residential duty tier, and the Tylo 200T is catalogued as a residential product. For unit interiors, closets and bedroom-side doors in multi-family it holds up. For a commercial corridor, an office suite, or any door a tenant or the public cycles all day, step up: the Falcon X101 passage knobset is Grade 1 heavy duty with an interchangeable core, the Schlage D10S passage knob is Grade 1 heavy duty, and the Corbin Russwin CK4310 is a Grade 1 passage/closet knob. Grade 1 is the ANSI/BHMA heavy-duty commercial tier, Grade 2 medium, Grade 3 light.
5) My door frame is prepped for a square corner faceplate. Does the Kwikset Tylo 200T latch match, or do I need to chisel?
No chiselling. The 6AL latch comes with three interchangeable faceplates: round corner, square corner, and a drive-in collar. So it drops into an existing square-corner mortise, an existing round-corner mortise, or a bare bored hole with no faceplate mortise at all using the drive-in collar. That covers every prep you'll find on a residential jamb.
6) Can I use a dummy knob in place of the Kwikset 200T Tylo passage knob?
No - a dummy knob only looks like a substitute. The Tylo 200T is a passage lock with a 6AL latch and RCS strike, so the knob turns and retracts a latch that holds the door closed. A dummy such as the Schlage A170 Grade 2 single dummy trim, the BEST 6K single dummy trim, or the Cal-Royal BA40 dummy knob is fixed trim with no latch at all, used on inactive leaves and closet doors held by a ball catch or a magnet. If the door has a latch bore and strike prep, the passage function is what the opening takes.
7) I need a fire rated passage knob - does the Kwikset 200T Tylo work?
The Tylo 200T is an ANSI/BHMA Grade 3 certified passage knob intended for interior openings that require no locking, such as hallway and closet doors. Where a fire rating is required on the opening, the Falcon W101 is a Grade 2 medium duty cylindrical passage/closet knob lock with a fire rating and a 2-3/4 inch backset, and the Falcon X101 is the Grade 1 heavy duty fire rated version of the same passage function.
8) What is the closest equivalent to the Kwikset 200T Tylo passage knob from another brand?
The Pamex FTF Baron knob lockset in passage function is the nearest match: it is a Grade 3 knob lockset with a passage/hall/closet function, the same grade and function as the Tylo 200T, and it fits doors 1-3/8 inch to 1-3/4 inch. The Bravura Albany and Bravura Lynchburg round-trim passage knobsets are also non-keyed passage knobs, both Grade 2. For an opening where a residential Grade 3 passage knob is what the spec calls for, the Pamex FTF passage is the direct swap.
9) What do I order instead of the Kwikset 200T if the door needs to lock?
The Tylo 200T is a passage knob for interior doors requiring no locking functionality. For a bed or bath door that needs a push-button lock, the Pamex FTF Baron knob in privacy function is a Grade 3 privacy/bed/bath knob for doors 1-3/8 inch to 1-3/4 inch, and the Cal-Royal BER20 is a Grade 3 privacy knob with brass trim over the same door thickness range. For a keyed opening, the Cal-Royal BER00 is a Grade 3 entrance/office knob lock cut for a Kwikset keyway, which keys into an existing Kwikset system.
10) What comes in the box with the Kwikset 200T Tylo, and do I need to buy a strike separately?
The strike is included. A Tylo 200T set ships with both knobs, the 6AL adjustable latch with its three faceplate options, and an RCS strike, plus the screws. Installation is a screwdriver job, nothing else required. A property manager doing a run of closet and hall doors doesn't need a separate strike or latch line item.
11) What finishes does the Kwikset Tylo passage knob come in? I need to match existing hardware.
Five: Satin Nickel, Bright Chrome, Satin Chrome, Bright Brass, and Antique Brass. That is the full Tylo 200T passage range, so if the rest of the building runs satin nickel or bright brass you can match the passage doors to the locking ones without mixing brands.
12) I'm replacing passage knobs across a whole building. What's the closest alternative to the Kwikset Tylo if I want to standardize on one brand?
For like-for-like residential passage knobs, the Pamex FTF Baron passage knob is Grade 3 and fits doors 1-3/8 to 1-3/4 inches, and the Bravura Albany and Lynchburg round-trim passage knobsets are Grade 2. If the run mixes passage with keyed entry doors and you want one family throughout, Schlage Residential's F Series Plymouth/Georgian combo pack carries adjustable backsets and dual strikes like the Tylo does, for 1-3/8 to 1-3/4 inch doors. Stepping up to commercial, Corbin Russwin's CK4410 passage knob is Grade 2 for 1-3/8 to 1-3/4 inch doors.
13) Which passage knobs besides the Kwikset 200T handle an adjustable backset?
The Tylo 200T latch has an adjustable backset from 2-3/8 inch to 2-3/4 inch and three interchangeable faceplates - round corner, square corner, and drive-in collar - so it drops into either standard bore. The Sure-Loc Bergen round knob ships as a 6-pack with an adjustable backset, and the Schlage Residential F500 Plymouth with Georgian knob is a combo pack with adjustable backsets and dual strikes for doors 1-3/8 inch to 1-3/4 inch. Where the backset is known and fixed at 2-3/4 inch, the Falcon W101 passage knob is built to that dimension.
14) What passage knob should I use on a door thicker than 1-3/4 inches instead of the Kwikset Tylo 200T?
For thicker doors, the Corbin Russwin CK4310 Global knob is a Grade 1 non-keyed passage/closet cylindrical lock rated for doors 1-3/8 inch to 2 inch, and the Falcon X101 heavy duty Grade 1 passage knobset covers 1-3/8 inch to 2-1/4 inch. The Corbin Russwin CK4410 Global knob passage/closet lock is the Grade 2 version and covers 1-3/8 inch to 1-3/4 inch.
15) Is there a decorative passage knob alternative to the Kwikset Tylo 200T for a period interior?
The Baldwin Estate 5011 Colonial passage knob with 5058 rose and the Baldwin Estate 5000 Baltimore 2 inch knob with 5048 rose - a preconfigured passage lock with a 2-3/8 inch backset and full lip strike - are both passage function knobs with traditional trim. The Omnia 434/PA is a traditional egg-shaped knob latchset in passage function with solid brass construction and a 3 inch projection. The Tylo 200T is a round knob offered in Satin Nickel, Bright Chrome, Satin Chrome, Bright Brass, and Antique Brass.
16) For standardizing hall and closet doors across a building, how does the Kwikset 200T compare to the Arrow and Dexter passage knobs?
All three are non-keyed passage knobs for hall and closet openings. The Tylo 200T is ANSI/BHMA Grade 3 with an adjustable 2-3/8 inch to 2-3/4 inch backset, three interchangeable latch faceplates, and Microban antimicrobial protection on the hardware. The Arrow MK01 from the MK Series and the Arrow RK01 ball knob from the RK Series are both Grade 2 for doors 1-3/8 inch to 1-3/4 inch, as is the Dexter C2000 Grade 2 passage ball knob over the same thickness range.
17) What replaces a Kwikset Tylo passage knob on a storeroom or utility door?
A storeroom door needs a knob that stays locked outside while the inside knob always releases, which the Tylo 200T does not do - it is a passage knob for interior doors requiring no locking. The Sargent 6G04 is a Grade 2 standard duty storeroom/closet knob lock with a single cylinder, and the Sargent 8XG04 is the Grade 1 heavy duty storeroom/closet single cylinder knob lock with a 2-3/4 inch backset.
18) What is Microban on a door knob and does it actually do anything?
Microban antimicrobial protection is built into the hardware surface rather than applied as a coating, and Kwikset states it keeps the door hardware 99.9 percent cleaner than unprotected surfaces. It's a hygiene claim about surface cleanliness, not a disinfectant and not a health claim. Where it gets specified: healthcare-adjacent housing, assisted living, and hospitality interiors where facilities teams want it on the touch points.
