Kwikset KWI-720AYKMDT Arroyo Knob with Midtown Rose Passage Door Lock with 6AL Latch and RCS Strike

It latches only, no locking. The Arroyo passage set is for interior openings that need no lock function, like hallway, pantry, and closet doors. If you need the door to lock from inside for a bath or bedroom, go to a privacy set instead, such as the Pamex FTF privacy knob or the Dexter C2000 privacy knob.

No handing to specify. The Arroyo Midtown rose passage set is universal handing and installs on right hand or left hand doors as shipped, so one part number covers every interior opening in the building.

The 6AL latch ships with three interchangeable faceplates: round corner, square corner, and a drive-in collar. That covers a routed mortise with radius corners, a square-corner mortise, and a bored edge with no mortise at all, so you can match what is already cut in the door instead of re-prepping it. An RCS (round corner) strike is included for the frame.

It is ANSI/BHMA Grade 2 certified but catalogued as a residential product, so it suits apartments, single family, and light multi-family interiors. For a school, hospital, or heavy commercial corridor, step up to a Grade 1 cylindrical passage knob like the Schlage D10S or the Falcon X101, which is listed heavy duty with a fire rating.

The Kwikset 720AYKMDT Arroyo is an ANSI/BHMA Grade 2 passage knob for interior doors that need no locking function. Close equivalents by grade and function include the Dexter C2000 Series Grade 2 passage cylindrical ball knob, which is non-keyed and fits doors 1-3/8 inch to 1-3/4 inch thick; the Arrow MK01 Grade 2 passage cylindrical knob, also 1-3/8 inch to 1-3/4 inch; and the Corbin Russwin CK4410 Grade 2 passage/closet cylindrical lock with Global knob, same door thickness range. The Arroyo brings a Midtown rose and a decorative Signature Series knob design, while the Dexter, Arrow, and Corbin Russwin units use plain ball or Global knob styling.

The Kwikset 720AYKMDT Arroyo is non-locking passage function. For a keyed opening, the Dexter C2000 Series Grade 2 entry/office cylindrical ball knob is keyed and fits 1-3/8 inch to 1-3/4 inch doors; the Cal-Royal BER00 is a Grade 3 entrance/office knob lock with a Kwikset keyway, which keeps you on the same key system; the Corbin Russwin CK4851 is an entrance/office cylindrical lock with a conventional cylinder for doors 1-3/8 inch to 2 inch; and the BEST 8K Series is a Grade 1 heavy duty entrance function single cylinder knob lock.

The Kwikset 720AYKMDT Arroyo is a residential Grade 2 passage knob. For a commercial corridor opening, the Falcon W101 is a Grade 2 medium duty cylindrical knob lock with passage/closet latch function, a 2-3/4 inch backset, and a fire rating; the Falcon X101 is a heavy duty Grade 1 cylindrical passage knobset with a fire rating and a 1-3/8 inch to 2-1/4 inch door thickness range. The Schlage D10S is another Grade 1 heavy duty passage latch with an Orbit knob.

The Kwikset 720AYKMDT Arroyo is a passage function knob with no locking capability, so it will not serve a bed or bath door. Privacy-function knob alternatives include the Dexter C2000 Series Grade 2 privacy cylindrical ball knob for doors 1-3/8 inch to 1-3/4 inch thick, the Pamex FTF Baron Grade 3 privacy knob lockset in the same thickness range, the Cal-Royal BER20 Grade 3 privacy knob lock with brass trim, and the Baldwin Estate 5077 Bethpage privacy knob with R027 rose.

No. The Kwikset 720AYKMDT Arroyo is a working passage set with a 6AL latch and RCS strike, so the knob retracts a latch. A dummy knob is surface-mounted trim with no latch at all, used on inactive or closet panel doors. Dummy options include the Schlage A170 Grade 2 single dummy trim for 1-3/8 inch to 1-7/8 inch doors, the BEST 6K Series Grade 2 medium duty single dummy trim, the Bravura Biloxi Grade 2 dummy knobset, and the Cal-Royal BA40 dummy knob for 1-3/8 inch to 1-3/4 inch doors. Ordering a dummy when you need a latching hallway knob leaves the door unable to stay shut.

For thicker doors, the Corbin Russwin CK4310 is a Grade 1 passage/closet cylindrical lock with a Global knob rated for 1-3/8 inch to 2 inch doors, and the Falcon X101 Grade 1 heavy duty passage knobset covers 1-3/8 inch to 2-1/4 inch. Both are non-keyed passage function like the Kwikset 720AYKMDT Arroyo. The Lockey 3830 mechanical keyless combination knob lock with auto-locking passage function fits 1 3/16 inch to 2 inch doors if you also want code entry.

The Kwikset 720AYKMDT Arroyo is a Grade 2 passage knob with no lock, so a secured storeroom needs a different function. The Sargent 8XG04 is a Grade 1 heavy duty storeroom/closet single cylinder knob lock with a 2-3/4 inch backset, and the Sargent 6G04 is a Grade 2 standard duty storeroom/closet knob lock with a single cylinder.

Three: Satin Nickel, Bright Chrome, and Matte Black. If you are standardizing a building, pick the finish that matches the hinges and the rest of the Arroyo trim, since the same three are what the set is built in.

A screwdriver, on an existing bored door. The set is a cylindrical lock, so the knob assembly, latch, and strike go into a standard 2-1/8 inch cross bore with a 1 inch edge bore for the latch. New doors need that prep drilled first.

No. The Arroyo passage set is a working latchset, so the knob turns and retracts a latchbolt. On a door held by a roller catch or a ball catch you want a dummy trim instead, like the BEST 6K single dummy, the Schlage A170 single dummy, or the Emtek Hammered Egg dummy pair for a double door.

The Kwikset 720AYKMDT Arroyo is a Signature Series Grade 2 passage knob with a decorative Arroyo knob on a Midtown rose. For plainer interior passage sets, the Bravura Albany and Bravura Lynchburg are both Grade 2 passage knobsets with round trim, the Bravura Dallas is a Grade 2 passage knobset with rectangular trim, and the Pamex FTF Baron is a Grade 3 passage knob lockset for doors 1-3/8 inch to 1-3/4 inch. The Bravura and Pamex sets trade the designer knob profile for basic trim shapes.

The Kwikset 720AYKMDT Arroyo is a Grade 2 residential passage knob with a Midtown rose, universal handing, and three interchangeable latch faceplates. On the decorative side, the Baldwin Estate 5011 Colonial passage knob uses a 5058 rose, the Baldwin Estate 5000 Baltimore passage set comes preconfigured with a 2-3/8 inch backset and full lip strike, and the Omnia 434/PA egg-shaped knob latchset is solid brass with a 3 inch projection. Those are styling and trim differences rather than function differences - all are passage sets.

The Kwikset 720AYKMDT Arroyo covers a single interior passage opening. If you want an entry and deadbolt package in one order, the Schlage Residential F500 Plymouth with Georgian knob is a combo pack with adjustable backsets and dual strikes for 1-3/8 inch to 1-3/4 inch doors. For buying interior knobs in bulk, the Sure-Loc Bergen round knob ships as a 6-pack with an adjustable backset.

Yes. Microban protection is built into the Arroyo knob and rose, which is why property managers use it on shared hallway and common-area doors in multi-family work.
