LCN 2614-POWDER Concealed Pneumatic Auto Equalizer Power Operator with Powder Coat Finish for Multi-Door Applications

LCN 2614-POWDER Concealed Pneumatic Auto Equalizer Power Operator with Powder Coat Finish for Multi-Door Applications

(1 review) Write a Review

Model: 2614-689
$3,269.00
$2,330.53
Selected Finish is
Selected Handing is
  • LCN ADDER-LCN-2610 SERIES-[CYLINDER]=Cast Iron Cylinder Assembly (CYL) ADDER-LCN-2610 SERIES-[CYLINDER]=Cast Iron Cylinder Assembly (CYL)
  • LCN ADDER-LCN-2610-[CYLINDER]=DPS Cylinder Assembly (CYL-DPS) ADDER-LCN-2610-[CYLINDER]=DPS Cylinder Assembly (CYL-DPS)

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,269.00
$2,330.53
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

LCN 2614 Concealed Pneumatic Auto Equalizer Power Operator with Powder Coat Finish for Multi-Door Applications

Professional Automatic Door Operator for Multi-Door Applications

The LCN 2614 Concealed Pneumatic Auto Equalizer Power Operator delivers low-energy automatic door operation for interior doors to 4'6" and exterior doors to 3'6". This pneumatically powered multi-door solution features concealed in-frame mounting with single lever track arm design, providing ADA-compliant accessibility and ANSI/BHMA A156.4 Grade 1 certification for professional reliability in commercial applications.

Professional Features & Benefits

  • Door Size Compatibility: Non-sized cylinders accommodate interior doors to 4'6" and exterior doors to 3'6" with versatile application range for various commercial installations.
  • ANSI/BHMA Grade 1 Certification: Tested and certified under ANSI/BHMA A156.4 Grade 1 standards for commercial-grade performance and reliability in demanding applications.
  • Concealed Installation Design: Mounts concealed in frame with single lever track arm in door for clean aesthetic appearance without visible hardware disrupting architectural design.
  • Pneumatic Power System: Utilizes heavy-duty door closer with pneumatic power for quiet, low-energy automatic operation ideal for multi-door installations.
  • ADA Compliance: Meets American Disabilities Act requirements for accessibility in power mode, providing easy access for elderly and disabled users.
  • Multi-Door Cost Efficiency: Cost per door leaf decreases significantly as number of door leaves increases, making it ideal for large commercial installations.
  • All-Weather Performance: Features all-weather fluid for reliable operation in various environmental conditions and temperature ranges.
  • Manufacturer Warranty: Backed by 2-year limited warranty for added confidence and protection in commercial applications.

Technical Specifications

  • ADA Compliant: Yes
  • BAA Qualified: Yes
  • Closer Size: 4
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Opening Size: 180 Degrees
  • Finish Type: Powder Coat
  • Fluid Type: All-Weather
  • Hold Open Feature: No
  • Mounting Detail: Concealed - In Frame
  • Mounting Location: In Frame
  • Mounting Method: Concealed
  • Product Category: Door Controls
  • Product Group: Door Controls
  • Product Model: 2614
  • Product Subgroup: Power Operators
  • Product Substrate: Iron
  • Product Type: Power Operators - Pneumatic
  • Series: 2610 Series
  • Subcategory: Power Operators - Pneumatic
  • Warranty: 2 Year

Professional Applications

  • Healthcare Facilities and Hospitals
  • Educational Institutions
  • Commercial Office Buildings
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings
  • Retail and Shopping Centers
  • Industrial and Warehouse Facilities

Why Choose LCN Quality?

LCN 2614 operators deliver professional-grade reliability with heavy-duty construction and ANSI/BHMA A156.4 Grade 1 certification for demanding commercial applications. The quiet, low-energy pneumatic design with all-weather fluid and 2-year limited warranty ensures dependable automatic door operation where accessibility and performance are essential. Engineered specifically for multi-door installations where cost-effective ADA compliance is required.

Product Specs

Series:
2610 Series
ADA Compliant:
Yes
BAA Qualified:
Yes
Mounting Detail:
Concealed - In Frame
Warranty:
2 Year
Closer Size:
4
Mounting Location:
In Frame
Subcategory:
Power Operators - Pneumatic
Product Group:
Door Controls
Product Subgroup:
Power Operators
Product Type:
Power Operators - Pneumatic
Finish Type:
Powder Coat
Fluid Type:
All-Weather
Commercial/Residential:
Commercial
Product Model:
2614
Door Opening Size:
180 Degrees
Hold Open Feature:
No
Mounting Method:
Concealed
Product Category:
Door Controls
Product Substrate:
Iron
Department:
Door Hardware

LCN 2614-689 – Frequently Asked Questions

1) Does the LCN 2614 mount on the door face or inside the frame?
In the frame. The 2614 operator body is concealed in the frame head with a single lever track arm on the door, so the only thing visible on the opening is the arm and track. That means the frame has to be deep enough and accessible to take the cylinder, which is the difference between this and a surface mounted operator you can add to an existing opening without touching the frame.
2) Do I have to specify handing when ordering the LCN 2614 power operator?
Yes, handing is a required choice on the 2614. It ships right hand by default and left hand is the alternative, so confirm the swing before you order. You also pick the cylinder assembly: the standard cast iron cylinder (CYL) or the DPS cylinder assembly (CYL-DPS).
3) Is the LCN 2614 an ADA compliant automatic door operator?
In power mode, yes. The 2614 is ADA compliant and carries ANSI/BHMA A156.4 Grade 1 certification as a low energy operator, which is the pairing an institutional spec normally calls for on an accessible entrance. It is also BAA qualified if you are buying against a Buy American requirement on a government or federally funded job.
4) Does the LCN 2614 need electricity, or is it air powered?
Air. The 2614 is a pneumatic Auto Equalizer, driven off a compressed air supply rather than an electric motor, working through a heavy duty door closer body. If your opening has no air line and you are not running one, this is the wrong family and you want an electric low energy operator instead.
5) Why would I use a pneumatic Auto Equalizer instead of one operator per door?
Cost per leaf. The pneumatic 2610 Series is built for banks of doors: one air supply drives multiple operators, so the cost per door leaf drops as the number of leaves goes up. On a single accessible entrance that advantage disappears and a standalone electric operator is the simpler buy. On a hospital or school vestibule with several powered leaves, this is the reason the type exists.
6) How far will the LCN 2614 swing the door open?
Up to 180 degrees, so the 2614 will take a leaf all the way back where the opening allows it. Check the wall, adjacent leaf, and any stop or overhead holder actually give you that swing before specifying it, since the operator will not create clearance the opening does not have.
7) Is the LCN 2614 operator suitable for an exterior door in a cold climate?
It is built for it. The 2614 uses all-weather fluid in the closer so operation stays consistent across temperature swings, and its exterior rating runs to 3'6" doors. The powder coat finish on the exposed hardware is the outdoor-appropriate option in the range.
8) What finishes can I get the LCN 2614 Auto Equalizer in to match the rest of my doors?
Six powder coat finishes: 689 aluminum, 690 statuary bronze, 691 light bronze, 693 gloss black, 695 dark bronze, and 696 brass. If you are standardizing across a building, 689 aluminum and 695 dark bronze are the two that most commonly match existing LCN closers already on the openings.
9) What closer size does the LCN 2614 use, and does that matter for my door?
Size 4 closer. That is the standard commercial sizing for a full width exterior leaf, and it is what lets the 2614 control doors out to 3'6" exterior and 4'6" interior. The cylinders are non-sized, so you are not matching a size to the door width at order time.
10) What is the LCN 2614 operator body made of?
Iron. The 2614 cylinder assembly is cast iron, and the standard cylinder option is listed as the Cast Iron Cylinder Assembly (CYL), with the DPS cylinder assembly as the alternative. It is a commercial-duty part, not a light residential operator.
