LCN 900 MHz Hardwired Transmitter for 8310 Series Touchless Actuator Systems

Professional Wireless Communication Component for Automatic Door Systems

The LCN 900 MHz Hardwired Transmitter is a specialized communication component designed for hardwired applications within the 8310 Series touchless actuator system. This transmitter enables wireless communication at 900 MHz frequency for reliable signal transmission in automatic door operator installations with 12VAC/DC/24VDC/24VAC power options. Engineered as part of LCN's comprehensive touchless access control solutions, this ADA compliant transmitter supports the growing demand for contactless entry systems in commercial and institutional environments.

Professional Features & Benefits

  • 900 MHz Frequency Operation: Operates on 900 MHz frequency band for reliable wireless communication with minimal interference in commercial environments.
  • Flexible Power Options: Standard 12VAC/DC/24VDC/24VAC operation provides versatile installation compatibility for various system requirements.
  • 8310 Series Compatibility: Engineered to work seamlessly with LCN 8310 Series touchless actuators including heavy-duty, standard, close-proximity, and harsh environment models.
  • Hardwired Integration: Designed specifically for hardwired applications providing stable power and communication connections for reliable operation.
  • ADA Compliant Design: Meets ADA compliance requirements for accessible automatic door operator systems in commercial applications.
  • Touchless System Support: Enables wireless communication for touchless actuator systems that promote health and well-being by eliminating contact requirements.
  • Commercial-Grade Reliability: Built to support demanding applications in high-traffic commercial, healthcare, educational, and institutional facilities.

Technical Specifications

  • ADA Compliant: Yes
  • Battery Operated: No
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Electronic: Yes
  • Parts and Accessories Type: Installation Accessories
  • Product Attribute: Parts and Accessories
  • Product Category: Electronic Access Controls
  • Product Group: Electronic Access Controls
  • Product Model: 8310-886
  • Product Subgroup: Parts and Accessories
  • Product Type: Transmitters
  • Product Voltage: 12VAC/DC/24VDC/24VAC
  • Series: 8310 Series
  • Subcategory: Closer Parts and Accessories

Professional Applications

  • Healthcare Facility Automatic Door Systems
  • Commercial Building Touchless Entry Solutions
  • Educational Institution Access Control
  • Retail Establishment Contactless Entry
  • Industrial Facility Automated Access Points
  • Government and Municipal Building Entry Systems
  • Multi-Tenant Residential Automatic Doors

Why Choose LCN Quality?

LCN transmitter components deliver professional-grade reliability as part of the comprehensive 8310 Series touchless actuator system with ADA compliant design for commercial applications. Engineered for demanding commercial applications where dependable wireless communication at 900 MHz frequency is essential for touchless access control. LCN's proven automatic door operator technology supports the growing need for contactless entry solutions in health-conscious environments.

Product Specs

Subcategory:
Closer Parts and Accessories
Series:
8310 Series
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Type:
Transmitters
Commercial/Residential:
Commercial
Electronic:
Yes
Battery Operated:
No
ADA Compliant:
Yes
Parts and Accessories Type:
Installation Accessories
Product Attribute:
Parts and Accessories
Product Model:
8310-886
Product Voltage:
12VAC/DC/24VDC/24VAC
Product Category:
Electronic Access Controls
Department:
Door Hardware

LCN 8310-886 – Frequently Asked Questions

1) What does the LCN 8310-886 transmitter actually do in a touchless door operator system?
The 8310-886 is the 900 MHz transmitter side of an LCN 8310 Series touchless actuator setup. The actuator (the wave-to-open plate or sensor) sends its signal over 900 MHz to a paired receiver, and the receiver drops the dry contact into the automatic operator. It is the radio link, not the actuator and not the operator, so it does not replace either one. It is a commercial-duty electronic component, and the 8310 system it belongs to is ADA compliant.
2) Do I need to run power to the LCN 8310-886, or does it run on a battery?
Power has to be run to it. The 8310-886 is the hardwired version, not battery operated, and it takes 12VAC/DC, 24VDC, or 24VAC. Plan a low-voltage run from the operator or a separate supply to wherever the actuator plate is mounted. If pulling wire to that location is the problem, the battery-powered transmitter is the version you want instead.
3) Will the LCN 8310-886 work with my existing 8310 Series touchless actuator?
Yes, if the actuator is an 8310 Series unit. The 886 is built for the 8310 Series touchless actuators, including the heavy-duty, standard, close-proximity, and harsh environment models. What it will not do is bridge to a different series or a different manufacturer's wireless kit, since the radio has to match on both ends.
4) Is the LCN 8310-886 the actuator itself, or do I still have to order a push plate?
You still need the actuator. Order the 8310-886 as the transmitter component only; the wave sensor or push plate the user actually triggers, plus the receiver at the operator, are separate line items. On a full touchless opening you are specifying the automatic operator, the actuator, the transmitter, and the receiver.
5) What is the difference between the LCN 8310-886 transmitter and the Falcon 8310-844 transmitter?
Both are 8310 Series transmitters, but they differ in how they are powered and wired. The LCN 8310-886 is a hardwired 900 MHz transmitter that runs on 12VAC/DC, 24VDC, or 24VAC supplied power and is not battery operated. The Falcon 8310-844 is a single channel wireless transmitter that runs on a 9-volt battery. Choose the 8310-886 when you can pull power to the transmitter location and want to avoid a battery change cycle; choose the 8310-844 when the transmitter sits somewhere you cannot run wire, such as a remote wall jamb or a finished masonry wall.
6) Can I use a Falcon 8310-844 in place of an LCN 8310-886?
They are both 8310 Series transmitters, so they cover the same job of sending the actuator signal to the operator, but they are not a drop-in swap for each other at the mounting point. The 8310-886 is wired for 12VAC/DC, 24VDC, or 24VAC and needs a power run to its location; the Falcon 8310-844 is a battery powered single channel unit with no wiring to the transmitter. If a hardwired 8310-886 was originally installed, the wall location already has power there and a battery unit will leave that conductor dead; if a battery unit was originally installed, there is no power at that box for the 8310-886. Decide on what is in the wall before ordering either one.
7) Can the LCN 8310-886 run off the 24V accessory output on my low energy operator?
It can, as long as that output is within the 12VAC/DC, 24VDC, or 24VAC range the 886 accepts. Both AC and DC are fine at those voltages, which is what lets it share a transformer or an operator's auxiliary terminals rather than needing a dedicated supply. Confirm the operator's accessory output has current left for it before you tie in.
8) Is a 900 MHz transmitter reliable in a hospital or school where there is a lot of Wi-Fi traffic?
The 900 MHz band sits well below the 2.4 GHz range that Wi-Fi and most building wireless occupies, which is the reason LCN put the 8310 link there. It is a commercial-grade component intended for healthcare, education, government, and multi-tenant residential openings where the door cycles hard all day.
9) I am standardizing touchless entries across a portfolio. Does the 8310 transmitter come in a matching Falcon version?
It does, and that matters if you buy across Allegion brands. The Falcon 8310-844 is a single channel wireless transmitter in the same 8310 Series, running on a 9-volt battery. The LCN 8310-886 is the hardwired 900 MHz unit taking 12VAC/DC, 24VDC, or 24VAC. Mixing them across a portfolio means two different maintenance stories, one with batteries on a replacement schedule and one without.
10) For a healthcare facility standardizing touchless door actuators, is a hardwired or a battery transmitter the better choice?
A hardwired transmitter such as the LCN 8310-886 draws its power from the building at 12VAC/DC, 24VDC, or 24VAC, so it has no battery on a replacement schedule. A battery transmitter such as the Falcon 8310-844 runs on a 9-volt battery, which means the mounting location needs no power run but the unit becomes part of your preventive maintenance rounds. Facilities that already conduit their actuator locations typically standardize on the hardwired 8310-886; retrofits into existing walls where fishing power is disruptive are where the battery unit earns its place.
11) Where do I find the LCN wiring and mounting instructions for the 8310-886 transmitter?
LCN publishes the templates and installation instructions index for its closers and automatic operators, and the automatic operator sensors and accessories material covers the 8310 actuator components. Both are on the product record along with the LCN automatic operator catalog section, which is where the operator-side terminal detail lives.
12) Is the Falcon 8310-844 a multi-channel transmitter like the LCN 8310-886?
The Falcon 8310-844 is a single channel transmitter, so it pairs to one receiver channel. The LCN 8310-886 is a 900 MHz hardwired transmitter for 8310 Series touchless actuator systems. If your opening needs one actuator talking to one operator, either form factor covers it; if you are laying out an installation where channel assignment matters, confirm the channel count you need before substituting the single channel Falcon unit.
