Leviton CS6369-P Industrial Grade California Style Single Locking Receptacle, 50A 125/250V

Leviton CS6369-P Industrial Grade California Style Single Locking Receptacle, 50A 125/250V

(No reviews yet) Write a Review

Model: LEV-CS6369

In Stock (leaves warehouse same day if ordered before 3pm ET)

$84.89
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton CS6369-P Industrial Grade California Style Single Locking Receptacle, 50A 125/250V

The Leviton CS6369-P is an Industrial Grade flush-mount, impact-resistant California Style non-NEMA single locking receptacle rated 50-Amp, 125/250-Volt in a black finish. Built for demanding commercial and industrial environments, this locking receptacle delivers a secure, vibration-resistant connection for high-amperage circuits. Also available as the CS8369-P variant, it's engineered to meet the rigorous performance demands of Industrial Grade electrical devices.

Key Features

  • Amperage Rating: 50A capacity supports high-current industrial and commercial loads.
  • Voltage Rating: 125/250-Volt configuration for dual-voltage applications.
  • Locking Design: California Style non-NEMA locking configuration prevents accidental disconnection under load.
  • Industrial Grade Construction: Impact-resistant housing built to withstand harsh industrial handling and repeated use.
  • Flush Mount Design: Flush-mount profile for a clean, low-profile installation.
  • Finish: Black housing for durability and a professional industrial appearance.
  • Model Options: Available as CS6369-P and CS8369-P configurations.

Technical Specifications

  • Amperage: 50A

Typical Applications

  • Industrial and Commercial Power Distribution
  • High-Amperage Equipment Connections
  • Manufacturing and Plant Floor Installations
  • Heavy-Duty Locking Receptacle Applications
  • Renovation and New Construction Electrical Upgrades

Why Leviton?

Leviton's Industrial Grade product line is built for reliability in demanding electrical environments, and the CS6369-P locking receptacle carries that same standard of impact-resistant, flush-mount construction. With a 50-Amp, 125/250-Volt rating and a secure California Style locking design, this receptacle delivers dependable, code-compliant performance for professional electrical installations.

Manufacturer Resources

Product Specs

Amperage Rating:
50A
Grade:
Industrial
Product Type:
Locking Receptacle
Connection Type:
Locking
Product Finish:
Black
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Receptacles & Outlets

Leviton LEV-CS6369 – Frequently Asked Questions

1) What is the difference between the Leviton CS6369 and CS8369 locking receptacles?
Both are 50A California Style locking receptacles, and the difference is the electrical system they land on. The CS6369 is rated 125/250V, which is the single-phase three-pole four-wire setup used for most shore power and portable generator feeds. The CS8369 is the 250V three-phase version. They are not interchangeable, so match the receptacle to the plug and the supply on the equipment you are feeding.
2) Is the Leviton CS6369-P suitable for a plant floor where cords get pulled and equipment vibrates?
That is the application it is built for. It is an Industrial Grade device with an impact-resistant housing, and the locking contact blades hold the plug in place so a vibrating machine or a dragged cord will not break the connection under load. Industrial Grade is the top of Leviton's device tiers, above residential and commercial spec grade.
3) Is the Leviton CS6369-P a flush-mount receptacle or does it come with its own enclosure?
It is a flush-mount device, meaning it mounts into a box or panel opening rather than arriving in its own weatherproof housing. You supply the back box, cover plate, and any enclosure the location calls for. The finish on the device itself is black.
4) Can I use the 50A CS6369 receptacle on a circuit that is smaller than 50 amps?
The 50A rating is a maximum the device can carry, so it can sit on a smaller feeder, but the mating plug configuration is what matters in practice. Anything cord-and-plug connected to a CS6369 is built expecting a 50A, 125/250V supply, so undersizing the branch circuit invites nuisance tripping or an overloaded conductor. Size the circuit to the connected load and the device rating.
