Leviton Renu Self-Test Smartlo...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$73.28
Leviton Renu Self-Test SmartlockPro Tamper-Resistant GFCI Outlet, 20A-125V, Polycarbonate

Leviton Renu Self-Test SmartlockPro Tamper-Resistant GFCI Outlet, 20A-125V, Polycarbonate

(No reviews yet) Write a Review

Model: RGF15-PS

In Stock (leaves warehouse same day if ordered before 3pm ET)

$73.28
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton Renu Self-Test SmartlockPro Tamper-Resistant GFCI Outlet, 20A-125V, Polycarbonate

The Leviton Renu Self-Test SmartlockPro Tamper-Resistant GFCI Outlet delivers dependable ground-fault protection for residential and commercial circuits, rated 20A-125V with a Class A trip level of 5mA plus or minus 1mA. Built with a durable Polycarbonate body and Thermoplastic face, this GFCI receptacle automatically self-tests its protection circuitry and locks out power if a fault is detected. The device is cULus listed and rated to NEMA WD-6, with the Renu platform allowing the color face to be swapped after installation using an available color change kit.

Key Features

  • Self-Test SmartlockPro Protection: Renu Self-Test GFCI automatically verifies ground-fault protection and locks out power if the self-test fails, alerting users to a fault condition.
  • Tamper-Resistant Design: Internal shutters help prevent foreign objects from being inserted into the receptacle.
  • Electrical Rating: Rated 20A at 125VAC, 2-pole, 3-wire, with a Class A, 5mA plus or minus 1mA trip level and a Short Circuit Current Rating of 10KA.
  • Durable Construction: Polycarbonate body and Thermoplastic face resist impact and wear, backed by Brass Double Wipe .031 Thick line contacts and Brass clamps.
  • Grounding & Mounting Hardware: Self-Grounding Clip and Green Ground Screw pair with a Galvanized Steel strap and Zinc-Plated Steel yoke for code-compliant grounding.
  • Flexible Termination: Back & Side termination accommodates 14-10 AWG conductors for fast, versatile wiring in new construction or retrofit work.
  • Renu Color-Change System: Compatible with color change kit RKG15, allowing the device face to be updated without replacing the entire receptacle (wallplate sold separately).

Certifications & Compliance

  • cULus Listed
  • UL 498 Compliant
  • CSA C22.2 No. 42 Compliant
  • Rated to NEMA WD-6 and ANSI C-73
  • Withstands 1250VAC Dielectric Voltage per UL 943 and CSA-C22.2 No. 144.1-06
  • Residential/Commercial Specification Grade

Technical Specifications

  • Csa C22 2 No 42: Yes
  • Product Id: Ratings are permanently marked on device
  • Tamper Resistant: Yes
  • Ul 498: Yes
  • Product Group: Outlets
  • Product Subgroup: GFCI Receptacles
  • Flammability: Rated HB or better UL94
  • Nom: Yes
  • Pole: 2
  • Wire: 3

Typical Applications

  • Residential and Commercial Electrical Installations
  • Kitchens, Bathrooms, and Other GFCI-Required Locations
  • Panelboard-Fed Branch Circuit Wiring Requiring Ground-Fault Protection
  • Renovation and New Construction Projects
  • Installations Requiring Color-Customizable Devices via the Renu System

Why Leviton?

Leviton engineers the Renu Self-Test SmartlockPro GFCI Outlet with a Polycarbonate body, Brass double-wipe contacts, and Galvanized Steel strap hardware for specification-grade durability. Backed by cULus listing and compliance with UL 498, UL 943, and CSA-C22.2 requirements, this GFCI outlet gives electrical professionals confidence in consistent, code-compliant ground-fault protection.

Manufacturer Resources

Technical Information

Product Specs

At Rated Voltage:
1 HP
Body Material:
Polycarbonate
Color Change Kit:
RKG15
Csa C22 2 No 42:
Yes
Face Material:
Thermoplastic
Grounding Screw:
Plated Steel
Line Contacts:
Brass Double Wipe .031 Thick
Operating Temperature:
-35C to +66C
Product Id:
Ratings are permanently marked on device
Short Circuit Current Rating:
10KA
Standards And Certifications:
cULus
Strap Material:
Galvanized Steel
Tamper Resistant:
Yes
Terminal Accom:
14-10 AWG
Terminal Id:
Brass-Hot, Green-Ground, Silver-Neutral
Terminal Screws:
Plated Steel
Trip Level:
Class A, 5mA plus or minus 1mA
Ul 498:
Yes
Product Group:
Outlets
Department:
Electrical
Product Subgroup:
GFCI Receptacles
Amperage Rating:
20 A
Ansi:
C-73
Clamps:
Brass
Feature:
Renu Self-Test GFCI
Grade:
Residential/Commercial Specification Grade
Grounding:
Self-Grounding Clip and Green Ground Screw
Nema:
WD-6
Nom:
Yes
Ordering Notes:
Wallplate Sold Separately
Pole:
2
Termination:
Back & Side
Yoke:
Zinc-Plated Steel
Series:
Renu
Product Voltage:
125 VAC
Product Details:
GFCI
Product Material:
Polycarbonate, Thermoplastic
Product Type:
GFCI Receptacle
Listing:
cULus
Certifications:
CULus
Short Circuit Current:
10 kiloamps
Dielectric:
1250 volts
Standards:
ANSI C-73
Flammability Class:
Rated HB Or Better UL94
Country of Origin:
China
Warranty Length:
2 years
Horsepower:
1 horse power
Wire Count:
3
