Leviton Renu Tamper-Resistant Duplex Outlet, 15A-125V, Self-Grounding

Leviton Renu Tamper-Resistant Duplex Outlet, 15A-125V, Self-Grounding

(No reviews yet) Write a Review

Model: RER15-CS

In Stock (leaves warehouse same day if ordered before 3pm ET)

$21.16
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton Renu Tamper-Resistant Duplex Outlet, 15A-125V, Self-Grounding

The Leviton Renu Tamper-Resistant Duplex Outlet is a 15A-125V receptacle in the NEMA 5-15R configuration, built around Leviton's Renu system that lets the outlet face snap off and on to update color without rewiring. It is tamper-resistant to meet the child safety requirements of the National Electrical Code®, is cULus listed, and is back and side wired for fast, reliable installation in any standard wallbox. Designed to pair with matching or contrasting Renu screwless wallplates, it turns a functional electrical device into an easily updated decorative accessory for any room.

Key Features

  • Electrical Rating: 15A-125V duplex outlet in the NEMA 5-15R configuration for standard residential and commercial circuits.
  • Tamper-Resistant Design: Built-in shutters help prevent access by foreign objects and meet NEC child safety requirements.
  • Back & Side Wired: Back and side wiring terminals allow for fast, easy installation in any standard wallbox.
  • High-Torque Terminals: Terminals are designed to withstand high torque and resist wire pullout for a secure, lasting connection.
  • Self-Grounding: Self-grounds when installed in a properly grounded metal wallbox, using a self-grounding clip and green ground screw.
  • Updatable Color System: The outlet face snaps off and on, so the color can be changed later with an RKR15 color change kit.
  • Renu Wallplate Compatible: Designed for use only with Renu wallplates; snap on a matching or contrasting screwless Renu wallplate, sold separately, to complete the look.
  • Shallow Profile: A shallow size makes the outlet easy to install in any wallbox.

Certifications & Compliance

  • cULus Listed
  • Tamper-Resistant per National Electrical Code® child safety requirements

Technical Specifications

  • Device Type: Duplex Outlet
  • Standards And Certifications: cULus
  • Amperage: 15 A
  • Grounding: Self-Grounding Clip and Green Ground Screw
  • Nema: 5-15R
  • Termination: Back & Side
  • Product Details: Duplex Receptacle

Typical Applications

  • Residential and Commercial Duplex Outlet Replacement
  • Color-Coordinated Interior Design Projects
  • Kitchens, Living Rooms, and Bedrooms Needing Renu-Matched Décor
  • New Construction and Renovation Wiring
  • Applications Requiring Tamper-Resistant, Child-Safe Receptacles

Why Leviton?

Leviton engineers the Renu Tamper-Resistant Duplex Outlet with high-torque, pullout-resistant terminals, self-grounding capability, and cULus-listed, NEC-compliant tamper resistance, giving electrical professionals a dependable device for code-driven installations. The snap-off, snap-on Renu face design adds long-term flexibility, letting a color change happen without replacing the underlying, reliable 15A-125V, NEMA 5-15R device.

Manufacturer Resources

Technical Information

Product Specs

Color Change Kit:
RKR15
Device Type:
Duplex Outlet
Standards And Certifications:
cULus
Product Group:
Outlets
Department:
Electrical
Product Subgroup:
Wiring Accessories
Amperage Rating:
15 A
Grounding:
Self-Grounding Clip and Green Ground Screw
Nema:
5-15R
Ratings:
15A-125V
Termination:
Back & Side
Product Details:
Duplex Receptacle
Product Type:
Duplex Receptacle
Listing:
cULus
Connection Type:
Back & Side Wired
Certifications:
CULus
Country of Origin:
China
Warranty Length:
5 years

Leviton RER15-CS – Frequently Asked Questions

1) Do I have to run a ground pigtail to the Renu RER15 outlet?
Not in a properly grounded metal wallbox. The RER15 has a self-grounding clip that bonds the yoke to the box through the mounting screw, plus a green ground screw if you'd rather land an equipment grounding conductor directly. In a plastic box, or any box you can't confirm is bonded, use the green screw and pigtail it.
2) Is the Leviton Renu RER15 a tamper-resistant receptacle that meets NEC child safety requirements?
Yes. The RER15 has built-in shutters that block a single foreign object from entering a slot, and it meets the National Electrical Code child safety requirement for tamper-resistant receptacles. The device is cULus listed. For dwelling-unit work where TR receptacles are required, this is the version to order; there is no non-TR selection to make on it.
3) Can I use a regular decora wallplate on the Leviton Renu outlet?
No. The Renu RER15 is built for Renu wallplates only, and the plate is a screwless snap-on. A standard decora or toggle-style plate will not fit the face. Order the Renu wallplate separately in a matching or contrasting color when you order the device, or you'll have an outlet you can't trim out.
4) If I want to change the outlet color later, do I have to rewire it?
No rewiring. The Renu face snaps off the device and a new one snaps on, so the color changes while the receptacle stays in the box and the conductors stay landed. The part to order for that is the RKR15 color change kit. For a property manager repainting units or a builder letting buyers pick trim late, that means the electrical work is done once.
5) Can I put the Renu RER15 15 amp outlet on a 20 amp circuit?
Yes, on a multi-outlet 20A branch circuit. A 15A 125V receptacle is permitted on a 20A circuit when two or more receptacles are supplied, which is the normal case in a room. Where a single receptacle sits alone on a dedicated 20A circuit, it has to be a 20A device, and the RER15 is rated 15A, so it isn't the part for that spot.
6) Is the Renu tamper-resistant outlet a GFCI, and can I use it in a kitchen or bathroom?
The RER15 is a straight duplex receptacle, not a GFCI. Tamper resistance and ground-fault protection are different things. You can install it in a kitchen or bath location as long as the GFCI protection comes from somewhere upstream, a GFCI receptacle first in the run or a GFCI breaker at the panel. If the device itself has to provide the protection, order a GFCI receptacle instead.
7) What plug configuration and voltage does the Renu RER15 outlet take?
It's a NEMA 5-15R duplex, rated 15A at 125V, which is the standard two-pole three-wire grounding outlet for general-purpose 120V branch circuits in homes and commercial interiors. Standard 5-15P cords plug straight in. It will not accept a 20A T-slot plug.
8) What colors does the Leviton Renu RER15 tamper-resistant outlet come in?
Six: Gold Coast White (RER15-GC), Corn Silk (RER15-CS), Prairie Sage (RER15-PS), Sea Spray (RER15-SE), Deep Garnet (RER15-DG), and Fresh Pink Lemonade (RER15-FP). Gold Coast White is the one to standardize on for general white-trim work; the rest are accent colors. Because the face is replaceable, picking a color now doesn't lock the opening in.
9) Can I swap a Renu outlet into an existing box without changing the wiring?
Yes, for a like-for-like replacement of a 15A 125V duplex on a standard 120V circuit. The RER15 lands on the same back or side terminals as the device coming out, self-grounds in a bonded metal box, and mounts in the existing wallbox. The one thing that doesn't carry over is the cover: the old plate won't fit, so budget a Renu wallplate for every device you swap.
10) Where can I get the spec sheet for the Leviton Renu RER15 receptacle?
Leviton publishes technical information for the Renu RER15 at https://zensupply.com/content/pdf/leviton/technical-information-e47022.pdf. That's the document to attach when a submittal package needs the device data behind the 15A 125V, NEMA 5-15R, cULus listed receptacle.
